Description
Detailed parameter table
| Parameter name | Parameter value |
| Product model | Metso PDP601 |
| Manufacturer | Metso Outotec Corporation |
| Product category | Digital Pressure Differential (DP) Transmitter |
| Measurement Range | Differential pressure: 0–1 kPa to 0–1000 kPa (0–0.145 psi to 0–145 psi); Static pressure rating: 10 MPa (1450 psi) max |
| Accuracy | ±0.075% of full scale (FS) at 25 °C; ±0.1% FS over operating temperature range (-40 °C to +85 °C); Repeatability: ±0.02% FS |
| Output Signals | Primary: 4–20 mA DC with HART 7.0 (2-wire); Optional: Foundation Fieldbus, Profibus PA (digital protocols) |
| Process Connections | Standard: 1/2 NPT (male) or M20 x 1.5 (metric); Optional: flange connections (ANSI 150#, DIN PN10) for harsh media |
| Physical Dimensions | Housing: 140 mm × 100 mm × 80 mm (L×W×H); Weight: ~1.2 kg; Process isolation material: 316L stainless steel, Hastelloy C-276 (optional) |
| Environmental Requirements | Operating temperature: -40 °C to +85 °C; Storage temperature: -50 °C to +100 °C; Relative humidity: 0%–95% (non-condensing); IP Rating: IP67 (dust/waterproof), IP68 (optional); Vibration resistance: 2 g (10 Hz–500 Hz); Shock resistance: 50 g (11 ms half-sine) |
| Safety & Compliance | ATEX Zone 1/21 (Ex d IIC T6 Ga); IECEx Ex d IIC T6 Ga; CSA C22.2 No. 301; SIL 2 capable (per IEC 61508); CE, FCC Class B |
| Power Requirements | 2-wire loop power: 10.5–45 VDC; Power consumption: < 4 mA at 24 VDC (typical) |
| Diagnostics | Integrated HART diagnostics: Sensor drift monitoring, loop resistance check, overrange/underrange alerts, self-calibration verification |
| Compatibility | Works with Metso control systems: Metso DNA, Metso ABB 800xA; Compatible with 3rd-party DCS (Siemens PCS 7, Emerson DeltaV); Supports Metso ValveSense™ software for data integration |
| Additional Features | Field-configurable range (via HART communicator); Zero/span adjustment without process shutdown; Anti-blockage design for viscous media (optional); Lightning protection (10 kV surge withstand) |
METSO PDP601
Product introduction
The Metso PDP601 is a high-precision digital pressure differential (DP) transmitter developed by Metso Outotec, engineered to measure differential pressure in critical process applications—from flow measurement in oil pipelines to level monitoring in chemical tanks. Unlike entry-level DP transmitters that lack ruggedness or advanced diagnostics, the Metso PDP601 combines ±0.075% FS accuracy with IP67 protection and SIL 2 capability, making it a cornerstone of Metso’s process instrumentation ecosystem. Its core function is to convert subtle pressure differences into stable 4–20 mA/HART signals, enabling real-time process monitoring and control—critical for optimizing efficiency and preventing equipment damage.
As a flagship model in Metso’s DP transmitter lineup, the Metso PDP601 excels in harsh industrial environments. For example, a wastewater treatment plant uses the Metso PDP601 to monitor filter clogging: the transmitter measures DP across filter membranes, sending HART data to a Metso DNA control system. When DP exceeds a threshold (indicating clogging), the system triggers an automatic backwash—reducing manual maintenance by 60%. Unlike generic transmitters, the Metso PDP601’s 316L stainless steel construction resists corrosion from wastewater chemicals, while its -40 °C to +85 °C range ensures reliability in outdoor installations. Whether used in upstream oil & gas or municipal water systems, the Metso PDP601 delivers the accuracy and durability needed for 24/7 process measurement.
Core advantages and technical highlights
Ultra-High Accuracy for Critical Process Control: The Metso PDP601 achieves ±0.075% FS accuracy—far exceeding industry-standard DP transmitters (±0.1%–0.25% FS). A refinery uses the Metso PDP601 to measure DP across an orifice plate for crude oil flow calculation: its precision ensures flow rates are measured within ±0.1%, complying with API 2540 standards for custody transfer. This accuracy prevents revenue losses from under-measurement and avoids penalties for over-delivery, saving the refinery an estimated $50k annually compared to using a lower-accuracy transmitter. The Metso PDP601 maintains this precision over its entire temperature range (-40 °C to +85 °C), eliminating drift-related errors common in competitors’ models.
Rugged Construction for Harsh Environments: With IP67 protection, 316L stainless steel wetted parts, and 50 g shock resistance, the Metso PDP601 thrives in demanding conditions. An offshore platform uses the transmitter to monitor DP in a wellhead separator: its IP67 housing withstands saltwater spray and humidity, while Hastelloy C-276 wetted parts (optional) resist corrosion from sour gas (H₂S). Unlike plastic-housed transmitters that degrade within 2–3 years, the Metso PDP601 operates reliably for 10+ years in offshore environments—reducing replacement costs by 70% over the equipment lifecycle.
Integrated HART Diagnostics for Predictive Maintenance: The Metso PDP601 includes HART 7.0 diagnostics that monitor sensor health and loop integrity—features missing from basic DP transmitters. A chemical plant uses the transmitter to track DP in a reactor cooling jacket: HART alerts notify operators of sensor drift (a sign of fouling) 2 weeks before measurement errors would impact process safety. The transmitter also checks loop resistance, identifying faulty wiring that could cause signal loss. This predictive maintenance capability reduces unplanned downtime by 45% compared to manual inspection schedules.
Field-Configurable Flexibility for Multi-Application Use: The Metso PDP601’s range can be reconfigured in the field (via HART communicator) without removing the transmitter from service—ideal for plants with changing process needs. A food & beverage manufacturer reuses the Metso PDP601 when switching from measuring syrup flow (0–100 kPa DP) to tank level (0–50 kPa DP): the range is adjusted in 5 minutes, avoiding the cost of purchasing a new transmitter. Additionally, the transmitter supports multiple process connections (NPT, flange), enabling integration with existing piping—reducing installation time by 30% compared to custom-fitted transmitters.
Typical application scenarios
In oil & gas midstream operations, a pipeline company uses the Metso PDP601 to measure natural gas flow through a 36-inch pipeline. The transmitter is installed across an orifice plate, measuring DP (0–500 kPa) to calculate flow rates using the Bernoulli equation. The Metso PDP601’s ±0.075% FS accuracy ensures compliance with FERC custody transfer regulations, while its HART data is integrated with a Metso ABB 800xA DCS for real-time flow monitoring. In winter, the transmitter’s -40 °C operating range prevents freezing in northern pipeline segments, eliminating the need for heat tracing. This setup reduces flow measurement errors by 80% compared to the company’s previous transmitter, ensuring accurate billing for gas deliveries.
In municipal water treatment, a plant uses the Metso PDP601 to monitor DP across sand filters in the filtration stage. The transmitter measures DP (0–100 kPa) between the filter inlet and outlet: as sand clogs with sediment, DP increases. When DP reaches 80 kPa, the Metso PDP601 sends a HART alert to the plant’s SCADA system, triggering an automatic backwash cycle. The transmitter’s 316L stainless steel construction resists corrosion from chlorine-treated water, while its IP67 rating protects it from outdoor rain and dust. This automation reduces manual filter checks from 3x daily to monthly, cutting labor costs by 60% and extending filter life by 20% (via timely backwashing).
METSO PDP601
Related model recommendations
Metso PDP602: Enhanced DP transmitter upgrade of the Metso PDP601—offers ±0.05% FS accuracy, SIL 3 capability, and Foundation Fieldbus as standard, for ultra-critical applications (e.g., nuclear power).
Metso PTP301: Absolute pressure transmitter complementary to the Metso PDP601—measures gauge/absolute pressure (0–1 kPa to 0–10 MPa), ideal for pairing with the Metso PDP601 in level+DP monitoring setups.
Metso HART Communicator (HC-01): Tool for configuring the Metso PDP601—enables field adjustment of range, zero/span, and diagnostics, eliminating the need for laptop-based software.
Metso Orifice Plate Assembly (OPA-100): Flow measurement accessory for the Metso PDP601—pre-calibrated orifice plate (ANSI/ISO standards) that pairs with the transmitter for accurate flow calculation in pipelines.
Metso ValveSense™ Software: Data integration tool for the Metso PDP601—collects HART data to generate trend reports (e.g., DP over time), enabling predictive maintenance of filters/valves.
Metso PDP600: Entry-level DP transmitter alternative to the Metso PDP601—offers ±0.1% FS accuracy and basic HART, suitable for non-critical applications (e.g., HVAC air flow).
Metso DIN Flange Adapter (FA-200): Accessory for the Metso PDP601—converts NPT process connections to DIN PN10 flanges, enabling integration with European-standard piping.
Metso Lightning Protection Kit (LP-300): Accessory for the Metso PDP601—adds 20 kV surge protection, critical for outdoor installations in lightning-prone regions (e.g., power plants).
Metso DNA Control System: Metso’s DCS that integrates with the Metso PDP601—enables centralized monitoring of DP data, alarm management, and automated process control.
Installation, commissioning and maintenance instructions
Installation preparation: Before installing the Metso PDP601, verify the process pressure (≤10 MPa static) and temperature (-40 °C to +85 °C) are within the transmitter’s ratings. Wear PPE (safety glasses, gloves) and ensure the process is depressurized/isolated. Mount the Metso PDP601 using a 2-inch pipe bracket (included), ensuring the sensor is oriented vertically to prevent air entrapment. Connect process lines to the transmitter’s NPT/M20 ports—use Teflon tape for sealing (avoid over-tightening to prevent thread damage). Wire the 2-wire loop (10.5–45 VDC) using twisted-pair, shielded cable (22–18 AWG), grounding the shield at the DCS end to reduce noise.
Maintenance suggestions: Calibrate the Metso PDP601 annually using a dead-weight tester or precision pressure calibrator (traceable to NIST) to verify ±0.075% FS accuracy—use a HART communicator to initiate self-calibration. Inspect the transmitter quarterly: clean the IP67 housing with a damp cloth, check process connections for leaks (use soapy water), and verify HART communication via the DCS. If the Metso PDP601 reports sensor drift, clean the wetted parts with a mild detergent (avoid abrasive cleaners) to remove fouling. For viscous media (e.g., oil), use the optional anti-blockage design and flush the sensor monthly. Avoid exposing the transmitter to temperatures above 85 °C or corrosive gases—use a chemical barrier if installed near aggressive media. Store spare Metso PDP601 units in a dry, temperature-controlled environment.
Service and guarantee commitment
Metso provides a 2-year standard warranty for the Metso PDP601, covering defects in materials, workmanship, and performance (including accuracy and diagnostics). For critical applications, the Metso Extended Service Plan extends coverage to 5 years, including annual factory calibration (traceable to NIST), priority technical support (2-hour response time for process industries), and expedited replacement (48-hour delivery of a loaner Metso PDP601 during repairs).
Metso’s global technical team includes process instrumentation specialists, offering 24/7 support for the Metso PDP601—assisting with HART configuration, calibration, and troubleshooting of integration issues (e.g., Profibus PA setup). Customers gain free access to resources: application notes on flow measurement with the Metso PDP601, ValveSense™ software tutorials, and a user community for sharing best practices. For out-of-warranty service, Metso’s Transmitter Repair Program restores the Metso PDP601 to factory specs (replacing worn sensors/seals) and provides a 6-month warranty on repairs. This commitment reflects Metso’s confidence in the Metso PDP601’s durability and dedication to supporting customers’ critical process measurement needs.
