KOLLMORGEN S30301-NA S300 DANAHER Servo Drive – Product Description
Product Overview
The KOLLMORGEN S30301-NA from the S300 Danaher series represents a high-performance digital servo drive designed for precision motion control applications. This advanced drive combines robust power handling with sophisticated control algorithms to deliver exceptional performance in industrial automation systems.
As part of Kollmorgen’s legacy Danaher Motion product line, the S30301-NA maintains the renowned reliability and performance characteristics that made the S300 series an industry standard. The drive offers seamless integration with a wide range of servo motors while providing the flexibility needed for complex motion applications.
Technical Specifications
| Parameter | Specification |
| Model Number | S30301-NA |
| Series | S300 Danaher |
| Input Voltage | 200-480VAC, 3-phase |
| Output Current | 30A continuous, 60A peak |
| Power Rating | 7.5kW |
| Control Modes | Torque, Velocity, Position |
| Feedback Options | Encoder, Resolver, Hall |
| Communication | Analog ±10V, Step/Direction, RS-232 |
| Switching Frequency | 8kHz (standard) |
| Protection Class | IP20 |
| Operating Temperature | 0°C to 55°C |
| Dimensions (W×H×D) | 150 × 220 × 60 mm |
| Weight | 2.1 kg |
Key Features & Benefits
Advanced Motion Control
Triple-loop control (position, velocity, torque) for precision motion
Auto-tuning algorithms for optimal servo performance
Advanced vibration suppression technology
S-curve acceleration for smooth motion profiles
Robust Power Architecture
30A continuous/60A peak current output
Regenerative braking capability
Dynamic stiffness adjustment for varying loads
Overload protection with automatic recovery
Flexible Integration
Multiple command interfaces (Analog, Step/Dir, RS-232)
Compatible with Danaher/Kollmorgen motors
Programmable I/O (4 inputs, 2 outputs)
Electronic gearing and camming functions
System Diagnostics
Comprehensive fault monitoring system
Real-time performance tracking
Waveform capture for troubleshooting
LED status indicators for quick diagnostics
Typical Applications
Industrial robotics
Machine tool axes
Packaging machinery
Material handling systems
Printing and converting equipment
Test and measurement systems
Compatible Products
Danaher S600/S700 series motors
Kollmorgen AKM servo motors
TBM series frameless motors
MCH brushless motors
Kollmorgen AKD compatible drives
Installation & Maintenance
Electrical Installation:
Requires proper 3-phase power connection
Must be installed in IP20 or better enclosure
Ensure proper grounding and shielding
Follow specified cable routing guidelines
Configuration:
Use WorkBench software for setup
Perform auto-tuning with connected motor
Configure I/O and safety functions
Set motion profile parameters
Maintenance:
Regularly check cooling fans
Monitor DC bus capacitors
Inspect power connections
Update firmware as needed
Quality Assurance
The S30301-NA is backed by Kollmorgen’s 18-month warranty, covering manufacturing defects. The drive undergoes extensive testing to ensure reliable operation in industrial environments. For technical support, contact Kollmorgen’s global service network with the drive’s serial number and application details.
Note: This product is part of Kollmorgen’s legacy Danaher Motion series. For new installations, consider Kollmorgen’s AKD2G series as a modern alternative with enhanced features.
