KOLLMORGEN S22460-SRS Servo Motor Resolver – Product Description

Product Overview

The KOLLMORGEN S22460-SRS is a premium-grade single-speed resolver designed specifically for integration with Kollmorgen’s high-performance servo motors. As part of Kollmorgen’s precision feedback device family, this resolver delivers exceptional accuracy and reliability in demanding motion control applications across various industries.

Engineered to meet the rigorous demands of industrial automation, the S22460-SRS provides robust position feedback for servo systems operating in challenging environments. Its superior construction and advanced design make it particularly suitable for applications requiring precise motion control under conditions of high vibration, extreme temperatures, and electromagnetic interference.

The resolver’s compact form factor and optimized electrical characteristics ensure seamless compatibility with Kollmorgen’s AKM, AKM2G, and TBM series servo motors, making it an ideal choice for system integrators and OEMs developing high-performance motion solutions.

Technical Specifications

Key Features & Benefits

Enhanced Precision Performance

Delivers ±3 arc-minute electrical accuracy for superior position feedback

±1 arc-minute mechanical accuracy ensures precise shaft position detection

Optimized signal processing for minimal phase shift and distortion

Rugged Industrial Design

IP65 protection against dust and water ingress

Withstands 20G vibration and 100G shock impacts

Extended temperature range (-40°C to +155°C) for harsh environments

Robust construction with military-grade components

Advanced Signal Integrity

High signal-to-noise ratio for reliable operation in EMI-intensive environments

Stable output characteristics across the entire operating temperature range

Low harmonic distortion for accurate position detection

Simplified Integration

Direct compatibility with Kollmorgen servo motor platforms

Standardized mounting interface for easy installation

Optimized for use with Kollmorgen servo drives and controllers

Typical Applications

High-precision CNC machinery (spindles, rotary tables)

Industrial robotics (articulated arms, delta robots)

Semiconductor manufacturing equipment

Aerospace and defense systems

Medical device automation

Packaging and material handling systems

Compatible Products

AKM2G Series Servo Motors

AKD Series Servo Drives

AKD2G Servo Drives

TBM2G Series Frameless Motors

Kollmorgen Motion Controllers

Installation & Maintenance

Mounting Requirements: The S22460-SRS must be installed with proper alignment to motor shaft using specified mounting procedures. Ensure resolver rotor is properly seated and secured according to Kollmorgen’s installation guidelines.

Electrical Connections: Use shielded cables for all resolver connections. Maintain proper cable routing to minimize noise interference. Verify excitation voltage matches system requirements.

Maintenance: Periodic inspection of resolver connections and signal quality is recommended. Check for mechanical wear during routine motor maintenance. Replace resolver if signal degradation exceeds acceptable limits.

Quality Assurance

Kollmorgen provides an industry-leading 24-month warranty for the S22460-SRS resolver. Each unit undergoes comprehensive testing to ensure compliance with stringent quality standards. The resolver is manufactured in ISO 9001-certified facilities with complete traceability.

For technical support or warranty service, contact Kollmorgen’s global support network with the product serial number and installation details.
