KOLLMORGEN S21260-SRS

Description

Product Overview

The KOLLMORGEN S21260-SRS is a high-performance servo motor resolver designed for precision motion feedback in demanding industrial automation applications. As a critical component of Kollmorgen’s motion control ecosystem, this single-speed resolver provides accurate angular position detection for servo motors, ensuring reliable performance in closed-loop control systems.

Engineered for seamless integration with Kollmorgen’s AKM, AKM2G, and TBM series servo motors, the S21260-SRS delivers exceptional signal accuracy and noise immunity. Its rugged construction and high-temperature tolerance make it suitable for use in harsh industrial environments, including robotics, CNC machinery, and automated manufacturing systems.

Technical Specifications

KOLLMORGEN S21260-SRS

KOLLMORGEN S21260-SRS

Main Features and Advantages

Precision Position Feedback

The S21260-SRS delivers ±5 arc-minute accuracy, providing reliable angular position data for precise servo motor control. Its robust design ensures stable signal output even in high-vibration environments, making it ideal for CNC and robotic applications.

Rugged Industrial Design

With IP54 protection and an operating temperature range of -40°C to +155°C, this resolver performs reliably in harsh conditions. The 20G vibration resistance and 100G shock rating ensure durability in demanding industrial applications.

Seamless Motor Integration

Designed specifically for Kollmorgen servo motors, the S21260-SRS features optimized mechanical and electrical interfaces for plug-and-play installation. Its compact design minimizes space requirements while maintaining high performance.

Noise-Immune Operation

The resolver’s analog signal output provides inherent noise immunity compared to digital encoders, ensuring reliable operation in electrically noisy industrial environments.

KOLLMORGEN S21260-SRS

Application Field

The KOLLMORGEN S21260-SRS is widely used in precision motion control applications including:

CNC Machinery: Spindle positioning and axis control

Industrial Robots: Joint position feedback for articulated arms

Packaging Equipment: Precise motion control for filling and sealing machines

Semiconductor Manufacturing: Wafer handling and inspection systems

Military/Aerospace: Rugged applications requiring reliable position feedback

• KOLLMORGEN S21260-SRS

Related Products

AKM Series Servo Motors: High-performance motors compatible with the S21260-SRS

AKD Series Drives: Advanced servo drives for complete motion solutions

S21260-MRS: Multi-speed resolver variant for specialized applications

RBE Series Resolvers: Alternative resolver options for different motor sizes

TBM Series Motors: High-torque motors using compatible resolver technology

Installation and Maintenance

Installation requirements: The S21260-SRS must be properly aligned during motor assembly to ensure accurate signal output. Follow Kollmorgen’s specified mounting procedures and torque specifications. Verify electrical connections match the resolver’s pinout configuration.

Maintenance recommendations: Periodically inspect resolver connections for integrity. Check signal quality using diagnostic tools. Replace if signal degradation or mechanical wear is detected. Keep the resolver clean from excessive dust and contaminants that could affect performance.

Product Guarantee

Kollmorgen provides an 18-month warranty for the S21260-SRS, covering manufacturing defects under normal operating conditions. The resolver undergoes extensive quality testing to ensure reliable performance in industrial environments. Global technical support is available for troubleshooting and application assistance.
