Description
Product Overview
The KOLLMORGEN CB06551 PRD-B040SSIB-63 is a high-performance brushless servo motor from Kollmorgen’s PRD (Power Range Drive) series, designed for precision motion control in demanding industrial automation applications. This PRD-B040SSIB-63 model integrates seamlessly with Kollmorgen servo drives, offering exceptional torque density, dynamic response, and energy efficiency. With a frameless design and high-resolution feedback, the KOLLMORGEN CB06551 PRD-B040SSIB-63 is ideal for applications requiring precise positioning, speed control, and repeatability.
Engineered for rugged industrial environments, this servo motor features a robust construction with high-quality materials, ensuring long-term reliability even under continuous operation. The PRD-B040SSIB-63 supports various feedback options, including resolver and encoder configurations, making it compatible with multiple motion control systems. Its compact and lightweight design allows for easy integration into space-constrained machinery while delivering high torque-to-inertia ratios for superior acceleration and deceleration performance.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | CB06551 PRD-B040SSIB-63 |
| Manufacturer | Kollmorgen |
| Product Type | Brushless Servo Motor |
| Frame Size | 65 mm |
| Rated Power | 400 W |
| Rated Speed | 3000 RPM |
| Peak Torque | 1.27 Nm |
| Rated Torque | 0.42 Nm |
| Voltage Rating | 230 VAC |
| Feedback Type | Single-turn Resolver (standard) |
| Protection Class | IP65 (dust-tight & protected against water jets) |
| Insulation Class | Class F (155°C) |
| Ambient Temperature Range | 0°C to +40°C (optional -20°C to +60°C) |
| Shaft Type | Smooth shaft with keyway |
| Weight | 2.5 kg |
KOLLMORGEN CB06551 PRD-B040SSIB-63
Main Features and Advantages
The KOLLMORGEN CB06551 PRD-B040SSIB-63 delivers outstanding performance with its optimized electromagnetic design, ensuring minimal cogging and smooth operation even at low speeds. Its high torque density allows for compact machine designs without sacrificing power, making it ideal for robotics, packaging, and CNC applications.
High dynamic response: The motor’s low rotor inertia enables rapid acceleration and deceleration, improving cycle times in high-speed automation processes. The PRD-B040SSIB-63 also features low electrical time constants, ensuring precise control in servo applications.
Durability and reliability: Built with high-grade materials and advanced thermal management, the motor operates efficiently under continuous loads. The IP65-rated housing protects against dust and water ingress, making it suitable for harsh industrial environments.
Flexible integration: With multiple mounting options and compatibility with Kollmorgen’s servo drives (such as AKD and S700 series), the CB06551 PRD-B040SSIB-63 ensures seamless system integration. Its resolver feedback provides accurate position sensing, while optional encoder feedback enhances precision for high-end applications.
KOLLMORGEN CB06551 PRD-B040SSIB-63
Application Field
The KOLLMORGEN CB06551 PRD-B040SSIB-63 is widely used in industries requiring high-precision motion control, including:
Industrial Automation: High-speed pick-and-place robots, conveyor systems, and automated assembly lines benefit from the motor’s fast response and accuracy.
Packaging Machinery: Servo-driven filling, labeling, and sealing machines leverage the PRD-B040SSIB-63 for smooth, repeatable motion.
CNC & Machine Tools: Precision milling, grinding, and laser cutting applications rely on its high torque and low vibration characteristics.
Medical Equipment: Automated diagnostic devices and surgical robots use this motor for its reliability and precise positioning.
Semiconductor Manufacturing: Wafer handling and inspection systems require the CB06551 PRD-B040SSIB-63 for its clean operation and high dynamic performance.
Related Products
AKD Series Servo Drives: Ideal companion drives for the PRD-B040SSIB-63, offering advanced tuning and control features.
PRD-B060SSIB-63: Higher torque variant (60 mm frame) for more demanding applications.
CB06551 PRD-B040SSIB-64: Same motor with multi-turn absolute encoder feedback.
S700 Servo Drive: A high-performance alternative for complex motion control tasks.
RBE Series Resolvers: Additional feedback options for enhanced precision.
Installation and Maintenance
Pre-installation preparation: Ensure proper alignment between the motor shaft and driven load to prevent excessive radial or axial forces. Verify electrical connections match the motor’s voltage and feedback requirements. Use appropriate mounting hardware to secure the KOLLMORGEN CB06551 PRD-B040SSIB-63 firmly, avoiding misalignment.
Maintenance recommendations: Regularly inspect motor cooling fins and ventilation paths for dust accumulation. Check resolver/encoder connections for signal integrity. Monitor bearing noise and replace if abnormal wear is detected. Avoid exposure to corrosive chemicals, and ensure environmental conditions remain within specified limits.
Product Guarantee
Kollmorgen provides a 24-month warranty for the CB06551 PRD-B040SSIB-63, covering manufacturing defects under normal operating conditions. Global technical support is available for troubleshooting and optimization. The motor undergoes rigorous testing to ensure compliance with industry s
