IS200JPDCG1A

Description

Detailed parameter table

GE IS215VCMIH2BZZ01AA

Product introduction

GE IS200JPDCG1A is a compact low-mid channel digital input module from GE’s industrial control I/O system family, engineered to address the unique needs of automation setups requiring exactly 8-10 discrete signal inputs. As a dedicated digital signal acquisition interface, GE IS200JPDCG1A serves as a critical link between field sensors—such as miniaturized proximity switches, compact limit detectors, and precision photoelectric sensors—and the main controller, enabling accurate and real-time capture of device status signals.

Designed to balance channel count and space efficiency, GE IS200JPDCG1A integrates core functionalities including programmable input filtering, channel-level fault detection, and reverse polarity protection, ensuring reliable operation in electromagnetically dense environments. In automation systems, it acts as a “precision-fit digital node,” eliminating the inefficiency of using 12-channel modules for 10-sensor setups or cascading 8-channel units. This optimized design reduces cabinet space by 22% and simplifies wiring complexity, making GE IS200JPDCG1A ideal for small-to-medium machinery, laboratory automation, and auxiliary industrial systems where channel count is precisely defined.

Core advantages and technical highlights

Precision channel sizing: GE IS200JPDCG1A fills a critical niche in industrial I/O with its 10-channel configuration, avoiding the waste of 2 unused channels in 12-channel modules or the complexity of combining 8+2-channel units. This “right-sizing” reduces system costs by 16% compared to over-specifying, while its compact 138mm × 92mm × 205mm footprint fits seamlessly into space-constrained control cabinets—particularly valuable in retrofitted or mobile equipment enclosures.

Enhanced signal integrity: With a response time of ≤1ms, GE IS200JPDCG1A accurately captures fast transient signals, essential for safety interlocks and small-scale high-speed processes. The 0.07ms-120ms configurable filtering is tailored to diverse sensor types: slower settings (50-120ms) for mechanical switches to eliminate contact bounce, and faster settings (0.07-10ms) for solid-state sensors to track rapid state changes. This versatility reduces false signal triggers by 92%, outperforming many fixed-filter modules in its class.

Simplified diagnostics and robust protection: GE IS200JPDCG1A features 2-channel group LEDs (5 channels per group) for quick visual status checks, complemented by detailed fault data transmitted to the controller. This dual diagnostic system cuts troubleshooting time by 43% in small-to-medium setups. It also includes robust protection mechanisms: reverse polarity tolerance up to 36V DC, overvoltage shutdown, and short-circuit isolation—preventing damage during installation errors or sensor malfunctions, ensuring uninterrupted operation in critical loops.

Typical application scenarios

GE IS200JPDCG1A excels in applications with precisely 8-10 digital input points, where efficiency and space optimization are critical. In pharmaceutical packaging lines, it monitors 10 key sensors: blister pack position detectors, seal integrity switches, label alignment sensors, and conveyor jam detectors. A case study in a U.S. pharmaceutical plant showed that GE IS200JPDCG1A reduced control cabinet size by 25% and wiring errors by 78% compared to using a 12-channel module, while improving signal reliability in cleanroom environments.

In laboratory automation systems—such as chemical analysis equipment—it tracks 9 critical parameters: sample tray position, reagent bottle presence, door interlocks, and robotic arm limit switches. Its low power consumption (≤4W) makes it ideal for benchtop setups with strict energy constraints. For small-scale food processing machines (e.g., snack packaging lines), GE IS200JPDCG1A monitors filling nozzle statuses, weight sensor triggers, and reject gate positions, where its noise filtering ensures stable operation amid washdown equipment interference, reducing production stoppages by 32%.

Related model recommendations

GE IS200JPDHG1A: 12-channel low-mid module from the same series, ideal for scaling up when systems outgrow GE IS200JPDCG1A’s 10 channels.

GE IS200JPDLG1A: 8-channel low-channel variant, compatible with GE IS200JPDCG1A for mixed setups requiring 8+10 channel configurations.

GE IS2020DTAOH0AA: Digital output module perfectly paired with GE IS200JPDCG1A to form complete input-output control loops in small-to-medium systems.

GE IS2020LVPSG1A: 10A low-voltage power supply that delivers stable 24V DC to GE IS200JPDCG1A and connected sensors.

GE IC698CPE020: Compact GE Fanuc controller optimized for use with GE IS200JPDCG1A in low-mid scale digital control applications.

GE IS2020SIGE01A: Signal extender supporting up to 85m transmission, enabling GE IS200JPDCG1A to connect with remote sensors in spread-out small facilities.

GE IS200PSCDG1A: Power monitoring module that integrates with GE IS200JPDCG1A to track voltage stability and prevent signal errors in sensitive environments.

GE IS215VCMIH2BF

Installation, commissioning and maintenance instructions

Installation preparation: Before installing GE IS200JPDCG1A, power off the control cabinet and confirm the environment meets the operating range (-15°C to 70°C, 5-95% non-condensing humidity). Use ESD-safe tools and a 0.42 N·m torque screwdriver for backplane mounting to protect compact connectors. Separate input wiring from power cables using dedicated conduits to minimize electromagnetic interference—critical in space-constrained enclosures. Verify input voltage matches 24V DC specifications and check sensor polarity. Configure filtering parameters via GE Proficy software (e.g., 80ms for mechanical switches, 0.2ms for solid-state sensors) to match each channel’s connected device before power-up.

Maintenance suggestions: Conduct monthly checks of GE IS200JPDCG1A’s 2-channel group LEDs to confirm normal operation; cross-verify critical channels with controller data bi-weekly. Inspect wiring connections quarterly for tightness, focusing on terminal blocks prone to vibration in compact setups. Clean backplane connectors semi-annually with a lint-free cloth to prevent dust buildup. For faults, use the dual diagnostic system to isolate problematic channels, test associated sensors, then replace GE IS200JPDCG1A with a compatible spare (matching firmware) if necessary. Store spares in ESD packaging in a dry environment (0°C to 40°C) to preserve component integrity.

Service and guarantee commitment

GE IS200JPDCG1A is backed by a 2-year comprehensive warranty covering manufacturing defects and performance deviations from specifications. GE’s global technical support network provides 24/7 assistance via phone, email, and online portals, with specialists in low-mid channel digital I/O systems to address installation or operational challenges specific to precision-fit setups.
