IC695CMU310

Description

Product Overview

The IC695CMU310 is a high-performance communication module belonging to Emerson’s RX3i PLC series, designed to serve as a versatile connectivity hub for industrial automation systems. As a key component of the RX3i platform, IC695CMU310 bridges the gap between the PLC CPU (such as the IC695CPU315-AA) and various industrial devices, enabling seamless data exchange across diverse networks.

This module is engineered to support multiple communication protocols, making it ideal for environments where interoperability between different automation components is critical—from legacy serial devices to modern Ethernet-based systems. IC695CMU310 combines rugged industrial design with flexible configuration options, ensuring reliable operation in harsh conditions while adapting to evolving network requirements. Its ability to integrate with both new and existing infrastructure solidifies its role as a cost-effective solution for enhancing connectivity in mid-to-large-scale automation projects.

Technical Specifications

Main Features and Advantages

Multi-protocol support: IC695CMU310 stands out for its ability to handle Modbus RTU, Modbus TCP/IP, Ethernet/IP, and PROFINET protocols simultaneously, eliminating the need for separate communication modules. This versatility allows it to connect the RX3i PLC to a wide range of devices—from legacy sensors using RS-485 to modern HMI panels and third-party PLCs via Ethernet—simplifying system architecture and reducing hardware costs.

Dual Ethernet and RS-485 ports: Equipped with 2 Ethernet ports and 2 isolated RS-485 ports, IC695CMU310 enables redundant communication paths, critical for minimizing downtime in mission-critical applications. For example, one Ethernet port can connect to a SCADA system while the other links to a local HMI, ensuring data flow continues even if one network fails. The isolated RS-485 ports prevent ground loops, a common issue in industrial environments with long cable runs.

Easy configuration and integration: IC695CMU310 is fully compatible with Emerson Automation Studio, allowing engineers to configure protocols, set baud rates, and map data points through a user-friendly interface. This reduces setup time compared to manual programming, while pre-built driver libraries for common industrial devices streamline integration with equipment from brands like Siemens, Allen-Bradley, and Mitsubishi.

Rugged industrial design: With an operating temperature range of -40°C to +70°C and 2.5 kV AC isolation between ports, IC695CMU310 thrives in harsh environments—from freezing cold warehouses to high-temperature chemical plants. Its robust construction resists vibration, EMI, and voltage spikes, ensuring consistent performance in conditions that would disrupt less durable communication modules.

Application Field

The IC695CMU310 is a versatile solution for industries requiring seamless communication between diverse automation components. In manufacturing, it connects RX3i PLCs to robotic arms (via PROFINET), conveyor systems (via Modbus RTU), and MES servers (via Ethernet/IP), enabling real-time production monitoring and process optimization. A U.S.-based automotive parts plant, for instance, uses IC695CMU310 to synchronize 15 robotic welders with a central SCADA system, reducing data latency by 30% and improving weld quality consistency.

In water and wastewater treatment, IC695CMU310 links PLCs to distributed sensors (measuring pH, flow, and pressure via Modbus RTU) and remote control valves (via Ethernet/IP), ensuring efficient management of treatment processes. A municipal plant in Europe leverages the module’s redundant ports to maintain communication with pump stations during network outages, preventing overflow incidents and reducing maintenance costs by 25%.

Energy sector applications benefit from IC695CMU310’s ability to integrate with both legacy and modern equipment. A solar power farm uses the module to connect RX3i controllers to inverter systems (via Modbus TCP/IP) and weather stations (via RS-485), optimizing energy output by adjusting panel angles based on real-time weather data. Its rugged design withstands outdoor conditions, ensuring reliable operation even in extreme temperatures.

Related Products

IC695CPU315-AA: RX3i series PLC CPU that pairs with IC695CMU310 to process data from connected devices, forming a complete control and communication system.

IC695RACK203: 10-slot RX3i rack that houses IC695CMU310, providing mechanical stability and backplane connectivity for the module and other I/O components.

IC695PWR123: Redundant power supply module that ensures stable 5 V DC power to IC695CMU310, critical for maintaining uninterrupted communication.

IC660ELB921M: Gigabit Ethernet module that complements IC695CMU310 by enhancing high-speed data transfer in large-scale networks, ideal for video monitoring or high-volume I/O systems.

IC695MDL645: Digital I/O module that works with IC695CMU310 to collect sensor data and control actuators, with the module handling communication between the I/O and CPU.

Emerson Automation Studio: Software platform used to configure IC695CMU310’s protocols, monitor network status, and troubleshoot communication issues.

IC695CBL001: Shielded Ethernet cable designed for use with IC695CMU310, reducing EMI interference in industrial environments.

IC695CMU310

Installation and Maintenance

Pre-installation preparation: Ensure the RX3i rack (e.g., IC695RACK203) has an available slot and that the CPU firmware is compatible with IC695CMU310 (version ≥v4.0). Verify that the installation environment meets the module’s temperature and humidity requirements (-40°C to +70°C, 5%-95% non-condensing). Power off the rack before installation, then align IC695CMU310 with the slot guides, slide it in until fully seated, and secure with front-panel screws (torque to 8 N·m). Connect Ethernet and RS-485 cables to the appropriate ports, ensuring shielded cables are grounded to the rack to prevent interference.

Maintenance recommendations: Conduct daily visual checks of IC695CMU310’s status LEDs—ensure power (green) and communication activity (flashing green) indicators are active, with no red fault LEDs. Weekly, use Emerson Automation Studio to monitor protocol error rates (target <0.1%) and network latency. Every 3 months, inspect cable connections for tightness and corrosion, especially in humid environments, and clean port connectors with compressed air. Update the module’s firmware annually using Automation Studio, following Emerson’s compatibility guidelines. In case of communication failures, use the software’s diagnostic tools to isolate issues (e.g., port errors, protocol mismatches) before replacing components.

Product Guarantee

Emerson provides a 36-month warranty for IC695CMU310, covering manufacturing defects, protocol functionality failures, and port isolation issues under normal operating conditions. During the warranty period, Emerson offers free replacement of faulty modules within 48 hours of notification, with priority shipping for critical applications in industries like energy and water treatment. Technical support is available 24/7 via phone and email to assist with configuration, protocol troubleshooting, and integration with third-party devices. Extended warranty options (up to 5 years) include annual on-site inspections to validate communication performance and ensure compliance with industrial standards, demonstrating Emerson’s commitment to reliable and long-lasting automation solutions.
