Honeywell Terminal Plate F860-CA
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | Honeywell F860-CA |
| Manufacturer | Honeywell |
| Product Category | Terminal Plate / Connection Interface |
| Material | High-strength, flame-retardant polymer |
| Terminal Type | Screw-type clamping terminals |
| Wire Size Range | 0.2–2.5 mm² (AWG 24–12) |
| Voltage Rating | 300V AC/DC |
| Current Rating | 10A per terminal |
| Operating Temp. | -40°C to +105°C |
| Protection Rating | IP20 (higher with enclosure) |
| Mounting Type | DIN Rail (35mm) or direct panel mount |
| Certifications | UL 94V-0, RoHS, CE, IEC 60947 |
HONEYWELL TERMINAL PLATE F860-CA
Product Introduction
The Honeywell F860-CA Terminal Plate is a high-quality electrical connection interface designed for secure and reliable wiring in industrial automation, control panels, and instrumentation systems. This terminal plate provides a robust and organized solution for distributing power and signals within Honeywell control systems, ensuring stable and vibration-resistant connections.
Engineered for durability, the Honeywell F860-CA features flame-retardant polymer housing and screw-type terminals that maintain a firm grip on conductors, preventing loosening due to mechanical stress or thermal cycling. Its compact design allows for efficient space utilization in control cabinets, while its wide operating temperature range ensures performance in harsh industrial environments.
Compatible with various Honeywell automation devices, the F860-CA simplifies wiring management and enhances system reliability, making it ideal for applications in power distribution, signal conditioning, and control circuit interfacing.
Core Advantages & Technical Highlights
Secure & Reliable Connections
Screw-type terminals ensure tight and stable wire clamping, even in high-vibration environments.
High-strength polymer housing resists heat, chemicals, and mechanical stress.
Versatile & Space-Efficient
DIN rail (35mm) or panel mounting for flexible installation.
Compact design optimizes control cabinet space.
Wide Compatibility
Supports 0.2–2.5 mm² (AWG 24–12) wires, accommodating both thin signal cables and thicker power conductors.
300V AC/DC rating for use in low-voltage control circuits.
Safety & Compliance
UL 94V-0 flame-retardant material ensures safety in electrical applications.
RoHS & CE compliant, meeting international environmental and electrical standards.
Durability in Harsh Conditions
-40°C to +105°C operating range for reliable performance in extreme temperatures.
Vibration-resistant design prevents terminal loosening over time.
Typical Application Scenarios
Control Panel Wiring: Distributing power and signals in PLC, DCS, and relay control systems.
Industrial Automation: Interfacing sensors, actuators, and I/O modules in manufacturing equipment.
Power Distribution: Safe and organized terminal connections in motor control centers (MCCs).
HVAC & Building Automation: Wiring terminal blocks for thermostats, actuators, and control units.
Instrumentation Panels: Reliable signal termination for transmitters and measurement devices.
HONEYWELL TERMINAL PLATE F860-CA
Related Model Recommendations
Honeywell F860-CB – Higher current-rated version (16A).
Honeywell F860-CC – Spring-clamp terminal alternative.
Honeywell F861-Series – Modular terminal blocks with pluggable connectors.
Honeywell TK-TRM – Terminal adapter for relay modules.
Honeywell Z-TERM – Barrier terminal blocks for hazardous areas.
Honeywell 8C-TB01 – Terminal board for I/O modules.
Installation, Commissioning & Maintenance
Installation Guidelines
Mount on 35mm DIN rail or secure directly to a panel using screws.
Ensure proper wire stripping length (7–9mm) for optimal terminal contact.
Tighten screws to 0.4–0.6 Nm torque to prevent over-tightening or loosening.
Maintain proper spacing between terminals to avoid short circuits.
Maintenance Recommendations
Annual inspection of terminal tightness (retorque if necessary).
Check for oxidation or corrosion on conductors in humid environments.
Replace if housing shows cracks or deformation due to overheating.
Service & Warranty Commitment
Honeywell provides a 36-month warranty for the F860-CA Terminal Plate, including:
Technical support for installation and troubleshooting.
Replacement for manufacturing defects.
Long-term availability of spare parts (minimum 10 years).
Compliance documentation (test reports, certifications).
For optimal performance, always follow Honeywell’s installation guidelines and environmental specifications.
