Description
Honeywell SPS5710-2-LF Industrial Pressure Sensor
Technical Specifications
| Parameter | Specification |
| Model Number | SPS5710-2-LF |
| Manufacturer | Honeywell |
| Type | Gauge/Sealed Gauge Pressure Sensor |
| Pressure Range | 0-100 psi (other ranges available) |
| Output Signal | 0.5-4.5V ratiometric (3-wire) or 4-20mA (2-wire) |
| Accuracy | ±0.25% FS (typical), ±0.5% FS (maximum) |
| Long-Term Stability | ±0.2% FS per year |
| Operating Temperature | -40°C to +125°C (-40°F to +257°F) |
| Media Compatibility | Non-corrosive gases and liquids |
| Wetted Materials | 316L stainless steel |
| Power Supply | 5V DC ±10% (ratiometric), 8-30V DC (4-20mA) |
| Response Time | <1 ms |
| Process Connection | 1/4″ NPT male (other options available) |
| Electrical Connection | Integrated cable or DIN 43650 connector |
| Protection Rating | IP67 |
| Certifications | CE, RoHS, REACH |
Honeywell SPS5710-2-LF
Product Overview
The Honeywell SPS5710-2-LF is a high-performance pressure sensor designed for demanding industrial applications. With its robust 316L stainless steel construction and exceptional accuracy, this sensor is ideal for precise pressure measurement in harsh environments. The sensor features both ratiometric voltage (0.5-4.5V) and current loop (4-20mA) output options, providing flexibility for integration with various control systems.
Key advantages include:
High accuracy (±0.25% FS typical)
Excellent long-term stability (±0.2% FS/year)
Fast response time (<1 ms)
Wide operating temperature range (-40°C to +125°C)
Multiple electrical and process connection options
Key Features
Precision Measurement
High accuracy across full pressure range
Minimal long-term drift for consistent performance
Rugged Construction
316L stainless steel wetted parts
IP67 protection for harsh environments
Vibration and shock resistant
Flexible Output Options
0.5-4.5V ratiometric output (3-wire)
4-20mA current loop output (2-wire)
Fast Dynamic Response
<1 ms response time
Suitable for rapidly changing pressure conditions
Easy Integration
Multiple process connection options
Choice of cable or connector electrical interface
Honeywell SPS5710-2-LF
Applications
The Honeywell SPS5710-2-LF is suitable for a wide range of industrial applications, including:
Hydraulic systems monitoring and control
Industrial automation and process control
Mobile equipment (construction, agricultural)
Compressed air systems
Test and measurement equipment
HVAC/R systems
Water and wastewater treatment
Installation and Maintenance
Installation Guidelines:
Ensure proper process connection (1/4″ NPT standard)
Verify media compatibility with 316L stainless steel
For electrical connections:
Ratiometric: Red (+5V), Black (GND), White (Signal)
4-20mA: Connect in series with power supply and load
Avoid excessive mechanical stress during installation
Maintenance Recommendations:
Periodic inspection of electrical connections
Check for signs of media leakage
Verify calibration annually for critical applications
Clean process connection if contaminated
Ordering Information
Standard Model: SPS5710-2-LF
Alternative Options:
Different pressure ranges available
Various process connections (G1/4, etc.)
Custom output configurations
For specific requirements, please consult Honeywell’s product documentation or contact technical support.
Warranty and Support
Honeywell provides a 24-month warranty for the SPS5710-2-LF pressure sensor. Comprehensive technical support is available through Honeywell’s global service network, including:
Application engineering assistance
Custom calibration services
Repair and replacement programs
