Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | HONEYWELL 05704-A-0144 |
| Manufacturer | Honeywell |
| Product Category | Four-Channel Control Card Catalytic Input |
| Operating Voltage | 18-32V DC |
| Power Consumption | 12.8W (maximum at 200mA sensor current), 8.5W (typical) |
| Drive Type | Constant Current |
| Initial Accuracy | ±1% |
| Current Adjustment | 90 to 315mA in 1mA electronic steps |
| Maximum Drive Voltage | 10V |
| Signal Range | 15mV to 300mV (full scale) |
| Bridge Imbalance Default Limits | ±100mV from center at 2V bridge voltage |
| Protection | Short circuit and open circuit protection |
| Maximum Line Resistance | 40 ohms (including sensor) at 200mA |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Dimensions | 10.8 cm x 6.7 cm x 8.4 cm |
| Weight | 0.2 kg |
| Certifications | UL/CUL, CE |
HONEYWELL 05704-A-0144
Product Introduction
The HONEYWELL 05704-A-0144 is a high-performance four-channel control card designed for Honeywell’s System 57 gas detection systems. It offers precise control and monitoring for industrial automation in harsh environments。
Core Advantages and Technical Highlights
High Precision and Reliability
The HONEYWELL 05704-A-0144 features high precision with an accuracy of ±1%, ensuring reliable operation in industrial environments。
Robust Design
The module is designed to withstand harsh industrial conditions, with an operating temperature range of 0°C to +60°C and a storage temperature range of -40°C to +85°C。
Versatile Communication Capabilities
The module supports multiple communication protocols, facilitating seamless integration with existing industrial systems。
User-Friendly Interface
The module includes a user-friendly interface and clear documentation, making installation and maintenance straightforward。
HONEYWELL 05704-A-0144
Typical Application Scenarios
The HONEYWELL 05704-A-0144 is widely used in:
-
Oil and Gas: For managing drilling operations, pipeline control, and refinery processes。
-
Power Generation: Control systems for turbines, boilers, and auxiliary equipment。
-
Chemical Processing: Monitoring and controlling chemical reactions and flow processes。
-
Manufacturing: For automation in assembly lines, robotics, and material handling。
-
Water and Wastewater Treatment: Managing pumps, valves, and filtration systems。
Related Model Recommendations
-
HONEYWELL 05701-A-0312: A related model with different specifications。
-
HONEYWELL 05701-A-0313: Another model in the same series with unique features。
Installation, Commissioning, and Maintenance Instructions
Installation Preparation
Ensure the environment meets the specified temperature and humidity requirements. Use appropriate tools and safety equipment to secure the module in place. Connect the module to the control system according to the manufacturer’s guidelines。
Maintenance Suggestions
Regularly inspect the module for signs of wear or damage. Keep the unit clean and free from dust to prevent overheating and ensure efficient operation。
