Honeywell LG1093AC01

Product introduction

The Honeywell LG1093AC01 is an advanced industrial process controller designed to handle complex multi-variable processes in demanding manufacturing environments. As a premium model in Honeywell’s Experion series, it builds on the capabilities of controllers like the EG1033AC01 with expanded I/O capacity, advanced control algorithms, and enhanced connectivity—making it ideal for large-scale production lines and precision-critical applications.

Honeywell LG1093AC01 excels in regulating interrelated process variables such as temperature, pressure, flow, and level, where changes in one parameter affect others. Its 7-inch multi-touch screen provides comprehensive process visualization, while support for advanced communication protocols enables seamless integration with enterprise systems. Whether deployed in petrochemical refining, semiconductor manufacturing, or high-volume pharmaceutical production, Honeywell LG1093AC01 delivers superior control precision, helping to maximize yields, ensure regulatory compliance, and reduce operational costs.

Core advantages and technical highlights

Multi-loop control capability: LG1093AC01 features 9 universal inputs and 6 outputs, enabling simultaneous control of up to 6 independent loops or complex interlocked processes. Unlike single-loop controllers, it can manage interacting variables—for example, in a distillation column, it regulates reboiler temperature, column pressure, and overhead product flow, adjusting each parameter to maintain product purity. This integrated approach eliminates the inefficiencies of separate controllers and reduces system complexity.

Advanced control algorithms: Beyond standard PID, LG1093AC01 incorporates Model Predictive Control (MPC), which uses mathematical models to anticipate process behavior and adjust outputs proactively. This is particularly valuable for processes with dead times or nonlinear responses, such as batch reactors or extrusion lines. MPC reduces overshoot by up to 50% compared to conventional PID, ensuring tighter control of critical parameters like chemical reaction temperatures or polymer melt viscosity.

Regulatory compliance features: With FDA 21 CFR Part 11 certification, LG1093AC01 includes audit trails, electronic signatures, and secure data storage—essential for regulated industries like pharmaceuticals and biotechnology. It automatically logs process data with time stamps, generating reports that simplify compliance with FDA, EMA, and other regulatory bodies. The controller’s access control system restricts parameter changes to authorized personnel, preventing unauthorized modifications to critical process settings.

Enhanced connectivity and scalability: LG1093AC01 supports Modbus, BACnet/IP, and optional Wi-Fi, enabling integration with SCADA, MES, and ERP systems. It can communicate with up to 32 remote I/O modules, expanding its monitoring capacity to over 100 points for large facilities. In a chemical plant, this allows the controller to coordinate operations across multiple reactors, sharing data with the enterprise resource planning system to optimize raw material usage and production scheduling.

Typical application scenarios

Petrochemical refineries utilize LG1093AC01 to control distillation units, where it regulates column temperature, pressure, and reflux flow across multiple stages. The controller’s MPC algorithm adjusts these variables in real-time to maintain product specifications (e.g., octane levels in gasoline) despite fluctuations in feedstock composition. Its 7-inch screen displays trending data for each loop, while Ethernet connectivity sends key metrics to the plant’s DCS for centralized monitoring.

Semiconductor manufacturing facilities deploy LG1093AC01 in chemical vapor deposition (CVD) processes, where precise control of temperature (±0.1°C), pressure (±0.1 torr), and gas flow is critical for wafer quality. The controller’s 9 inputs monitor process variables and chamber conditions, while outputs adjust heaters, vacuum pumps, and mass flow controllers. Its FDA 21 CFR Part 11 compliance ensures detailed process records are maintained for quality control audits.

Food processing plants use LG1093AC01 in large-scale pasteurization systems, where it coordinates heating, cooling, and flow rates across multiple processing stages. The controller’s auto-tune function adapts to varying product volumes, while relay outputs manage pumps and valves to maintain consistent pasteurization times. Integration with plant-wide MES via Modbus TCP/IP allows for recipe management, enabling quick product changeovers with minimal downtime.

Honeywell LG1093AC01

Related model recommendations

Honeywell EG1033AC01: A compact alternative to LG1093AC01 with 3 inputs/outputs, ideal for smaller processes or as a satellite controller in distributed systems.

Honeywell UDC4000: High-performance process controller that integrates with LG1093AC01 in multi-loop systems requiring redundant control for critical processes.

Honeywell STT850: Smart temperature transmitter that pairs with LG1093AC01, providing enhanced accuracy for RTD/thermocouple measurements in high-precision applications.

Honeywell HC900: Hybrid controller that works with LG1093AC01 to handle both regulatory and safety instrumented functions in process plants.

Honeywell PM500: Advanced power monitor that communicates with LG1093AC01 via Modbus, enabling energy optimization alongside process control.

Honeywell T9000: Remote I/O module that expands LG1093AC01‘s input capacity by 16 points, useful for monitoring dispersed process variables.

Installation, commissioning and maintenance instructions

Installation preparation: Mount LG1093AC01 in a panel cutout of 202 mm x 202 mm, ensuring a minimum of 100 mm clearance above and below for ventilation. Connect to a 100-240 V AC power supply with a 1 A fuse, using an isolated circuit to prevent electrical noise. For hazardous areas (ATEX Zone 2), install in a certified enclosure with appropriate cable glands. Route analog and digital wiring separately to minimize interference, and label all connections with process variable identifiers.

Commissioning and maintenance: Configure LG1093AC01 via its touchscreen or Honeywell’s ControlEdge configuration software, setting input types, control algorithms, and communication parameters. Use the auto-tune function for initial PID setup, then refine with MPC for complex processes. Verify data logging and audit trail functionality to ensure regulatory compliance. Perform monthly inspections to clean the screen and check connections. Calibrate inputs quarterly using NIST-traceable standards. Update firmware semi-annually via Ethernet to access new control features and security patches.

Service and guarantee commitment

Honeywell LG1093AC01 comes with a 5-year warranty covering manufacturing defects and ensuring compliance with published specifications. Honeywell’s process control technical support team provides 24/7 assistance, with a 2-hour response time for critical issues, including remote diagnostics and on-site support for complex installations.

Customers receive dedicated training for LG1093AC01 configuration, including advanced courses on MPC implementation. Extended warranty options up to 7 years include annual calibration verification and priority access to replacement parts. Honeywell maintains global inventory of LG1093AC01 units, enabling 48-hour delivery for emergency replacements. All repairs use genuine components, with post-repair testing to validate performance and regulatory compliance, ensuring reliable operation in critical processes.
