Honeywell DCP71150C012010H0

Description

Detailed parameter table

Honeywell DCP71150C012010H0

Product introduction

The Honeywell DCP71150C012010H0 is a high – precision pressure transmitter engineered to meet the demanding requirements of industrial process control. As part of Honeywell’s extensive range of sensing solutions, it is designed to accurately measure and transmit pressure values, making it an essential component in systems where reliable pressure monitoring is crucial.

This pressure transmitter features a measuring range of 0 – 150 psi (0 – 10.34 bar), suitable for a wide variety of applications, from general industrial processes to more specialized applications in the oil and gas, chemical, and water treatment industries. With an accuracy of ±0.1% of span, it ensures that the pressure data it provides is highly reliable, enabling operators to make informed decisions based on precise measurements. The 4 – 20 mA output signal is a standard in the industry, allowing for easy integration with existing control systems, such as PLCs (Programmable Logic Controllers) and DCSs (Distributed Control Systems).

Core advantages and technical highlights

High accuracy: The ±0.1% of span accuracy of the Honeywell DCP71150C012010H0 is a standout feature. In applications where even a slight deviation in pressure measurement can lead to significant process inefficiencies or product quality issues, such as in pharmaceutical manufacturing or high – pressure hydraulic systems, this level of accuracy is essential. It helps maintain tight control over processes, reducing waste and improving overall productivity.

Robust construction: The use of 316L stainless steel for wetted materials ensures excellent corrosion resistance. This makes the transmitter suitable for use in harsh environments, including those with exposure to chemicals, saltwater, or abrasive substances. In the oil and gas industry, for example, where pipelines and storage tanks may contain corrosive fluids, the Honeywell DCP71150C012010H0 can operate reliably without the risk of degradation due to corrosion.

Wide temperature range: Operating from -40°F to 250°F (-40°C to 121°C) and with a storage temperature range of -55°F to 275°F (-48°C to 135°C), this pressure transmitter can withstand extreme temperature conditions. It can be deployed in outdoor applications in cold climates, like Arctic oil fields, or in high – temperature industrial processes, such as in steam generation plants or hot water heating systems.

IP67 protection: The IP67 rating means that the Honeywell DCP71150C012010H0 is dust – tight and protected against temporary immersion in water. This level of protection is beneficial in environments where there is a risk of water splashing, high humidity, or exposure to dust, such as in mining operations or food and beverage processing plants.

Typical application scenarios

In the oil and gas industry, the Honeywell DCP71150C012010H0 is used to monitor the pressure of pipelines transporting crude oil, natural gas, or refined products. By accurately measuring the pressure, operators can detect leaks, blockages, or abnormal flow conditions. For example, in a long – distance natural gas pipeline, a sudden drop in pressure may indicate a leak, and the high – accuracy measurements provided by this transmitter can help in quickly identifying and addressing the issue.

Within chemical processing plants, it is employed to measure the pressure in reaction vessels, storage tanks, and distillation columns. In a chemical reaction process, maintaining the correct pressure is critical for the success of the reaction. The Honeywell DCP71150C012010H0 ensures that the pressure is continuously monitored, allowing for adjustments to be made in a timely manner to optimize the chemical reactions and ensure product quality.

In water treatment facilities, the pressure transmitter is used to monitor the pressure in water supply pipelines, pumps, and filtration systems. In a large – scale water distribution network, knowing the pressure at different points helps in managing the flow of water, ensuring that there is sufficient pressure for customer use while also preventing over – pressurization that could lead to pipe bursts.

Related model recommendations

Honeywell DCP71025C012010H0: A similar pressure transmitter with a lower measuring range of 0 – 25 psi (0 – 1.72 bar), suitable for applications where lower pressure ranges are required, such as in low – pressure air systems or some laboratory equipment.

Honeywell DCP71300C012010H0: This model has a higher measuring range of 0 – 300 psi (0 – 20.68 bar), which can be used in applications that involve higher pressures, like some high – pressure hydraulic systems or certain industrial cleaning equipment.

Honeywell PLC – 500: A programmable logic controller that can be integrated with the Honeywell DCP71150C012010H0 to process the pressure data and control various industrial processes based on the measured pressure values.

Honeywell DCS – 1000: A distributed control system that can manage multiple Honeywell DCP71150C012010H0 units across a large – scale industrial plant, providing centralized monitoring and control of pressure – related processes.

Honeywell Signal Conditioner – 200: This device can be used to condition the 4 – 20 mA output signal from the Honeywell DCP71150C012010H0 for better compatibility with some sensitive control equipment or for long – distance signal transmission.

Honeywell Mounting Bracket – 50: A specialized mounting bracket designed to securely install the Honeywell DCP71150C012010H0 in different industrial settings, whether it’s a direct – mount application on a pipe or a remote – mount setup using a cable extension.

Honeywell DCP71150C012010H0

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the Honeywell DCP71150C012010H0, ensure that the process connection (1/2″ NPT male) is compatible with the pipeline or equipment where it will be installed. Verify that the power supply is within the 12 – 36 VDC range and properly grounded. Gather the necessary tools, such as a pipe wrench for installing the process connection and a screwdriver for electrical connections. Check the ambient temperature and humidity conditions to ensure they are within the operating range of the transmitter.

Maintenance suggestions: Regularly inspect the Honeywell DCP71150C012010H0 for any signs of physical damage, such as cracks in the housing or leaks around the process connection. Clean the exterior of the transmitter periodically, especially in dusty or dirty environments, using a soft, dry cloth. Check the electrical connections for tightness and signs of corrosion. Use a calibrated pressure source to periodically check the accuracy of the transmitter. If the accuracy deviates beyond the specified ±0.1% of span, the transmitter may need to be recalibrated or repaired.

Commissioning steps: After installation, power on the Honeywell DCP71150C012010H0 and check the output signal. Connect it to a compatible display or control device to verify that the measured pressure values are being correctly transmitted. Slowly introduce pressure to the process connection and observe the output signal response. Ensure that the signal changes linearly with the applied pressure within the specified measuring range. If there are any issues, check the installation, electrical connections, and calibration settings.

Service and guarantee commitment

The Honeywell DCP71150C012010H0 comes with a 24 – month warranty from the date of purchase. During this period, if the product fails due to manufacturing defects, Honeywell will repair or replace the unit free of charge.

Honeywell offers comprehensive technical support for the Honeywell DCP71150C012010H0. Our technical experts are available via phone and email to assist with installation, calibration, and troubleshooting. We also provide online resources, including installation manuals, technical specifications, and calibration procedures. For customers who require more in – depth support, optional extended service contracts are available, which can include on – site maintenance, priority response times, and regular calibration services to ensure the long – term reliable operation of the pressure transmitter.
