Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IS200JPDMG1ACC |
| Manufacturer | GE Fanuc |
| Product Category | Power Distribution Board |
| Input Voltage | 28V DC |
| Output Voltage | 24V DC (regulated) |
| Fuse Rating | 12 x 5A |
| Connector Type | 2 x 50-pin (P1/P2), 1 x DC62 (JA1) |
| Physical Dimensions | 6.5 x 7 inches |
| Mounting Type | DIN rail |
| Weight | 1.2 kg |
| Operating Temperature | -20°C to +60°C |
| Humidity | 5% to 95% (non-condensing) |
| Protection Rating | IP20 |
| Certifications | UL, CE, CSA C22.2, RoHS |
IS200JPDMG1ACC
Product Introduction
The GE IS200JPDMG1ACC is a high-performance power distribution board designed for industrial automation applications. It is part of the GE Mark VI Speedtronic turbine control system, ensuring reliable power management and distribution.
Core Advantages and Technical Highlights
Redundant Power Architecture
The GE IS200JPDMG1ACC incorporates dual power input channels, ensuring continuous operation even if one path fails. This redundancy is critical for applications where downtime is costly, such as power plants and petrochemical facilities.
Overload Protection
With 12 integrated fuses, the board safeguards against short circuits and overcurrent conditions, preventing damage to connected components. This feature extends the lifespan of the control system and reduces maintenance costs.
Flexible Connectivity
The board’s multiple connectors (P1/P2, JA1) support seamless integration with a wide range of Mark VI modules, including I/O cards, communication interfaces, and control processors. This versatility allows for scalable system configurations tailored to specific operational needs.
Compact Design
The GE IS200JPDMG1ACC’s compact size and DIN rail mounting simplify installation in space-constrained environments. Its lightweight construction (1.2 kg) also facilitates easy handling during maintenance.
High Reliability
Built with industrial-grade components and a rugged PCB coating, the board withstands harsh environmental conditions, including vibration, dust, and temperature fluctuations. This durability ensures consistent performance in demanding industrial settings.
IS200JPDMG1ACC
Typical Application Scenarios
The GE IS200JPDMG1ACC is widely used in:
-
Power Generation: For controlling turbines, generators, and other critical equipment.
-
Gas Turbine Control: For precise control of gas turbines in various industrial settings.
-
Industrial Automation: For controlling actuators, relays, and other industrial devices in manufacturing and chemical processing.
Related Model Recommendations
-
GE IS200TBCIH1BBC: A control module designed for specific industrial control applications.
-
GE IS220PPROS1B: Another model in the GE product lineup with unique features tailored to different industrial needs.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation
Ensure the environment meets the specified temperature and humidity requirements. Use appropriate tools and safety equipment to secure the module in place. Connect the module to the control system according to the manufacturer’s guidelines.
Maintenance Suggestions
Regularly inspect the module for signs of wear or damage. Keep the unit clean and free from dust to prevent overheating and ensure efficient operation.
