Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200BPPBH2CAA |
| Manufacturer | GE (General Electric) |
| Product Category | Discrete I/O Module |
| Series | Mark VIe Control System |
| Input Voltage Range | 100-240 VAC |
| Output Voltage | 24 VDC |
| Maximum Output Current | 10 A |
| Operating Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (L×W×H) | 100 mm × 260 mm × 50 mm |
| Weight | 0.9 kg |
| Certifications | CE, UL, IEC 61508 |
GE IS200BPPBH2CAA
Product Introduction
The GE IS200BPPBH2CAA is a high-performance discrete I/O module designed for the GE Mark VIe control system. It is a key component in turbine control systems, providing accurate signal processing, data processing, and communication functions. This module is widely used in power plants, oil and gas industries, and other environments where high performance and reliability are required.
Core Advantages and Technical Highlights
High Reliability: The IS200BPPBH2CAA is built with high-quality electronic components, ensuring stable operation in harsh industrial environments. It includes six metal oxide varistors (MOVs) for protection against overvoltage, overcurrent, and short circuits.
Versatile I/O Options: The module supports digital inputs and outputs, with configurable types such as relays, transistors, and dry contacts. It can handle multiple discrete signals, making it suitable for complex control systems.
Redundancy Support: The IS200BPPBH2CAA supports both simplex and triple modular redundancy (TMR) configurations, ensuring continuous operation even during single-point failures.
Wide Operating Range: The module operates reliably within a temperature range of -40°C to +85°C and a humidity range of 5% to 95% non-condensing.
Standard Modular Design: The IS200BPPBH2CAA features a standard modular design for easy installation and replacement.
GE IS200BPPBH2CAA
Typical Application Scenarios
The GE IS200BPPBH2CAA is widely used in various industrial sectors, including:
-
Power Plants: For managing critical control functions such as turbine monitoring and power generation optimization.
-
Oil & Gas Industry: For high-precision control and monitoring of industrial processes.
-
Water Treatment Facilities: For process control and automation.
Related Model Recommendations
-
IS210REAS1A: A trip terminal board that works seamlessly with the IS200BPPBH2CAA, providing additional configuration options.
-
IS200AEPAH1BKE: An analog output module, suitable for precise control of analog signals.
-
IS200WEMAH1ACA: A turbine control system circuit board, suitable for advanced control applications.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation: Ensure the installation environment is clean and free of interference. Check the compatibility of the module with the existing system, especially ensuring it is suitable for the specific GE Mark VIe control system used. Prepare the necessary tools and follow the installation manual carefully.
Maintenance Suggestions: Regularly inspect the module for physical damage, monitor output voltages using a multimeter, and check for abnormal heat generation or noises. Clean the module’s surface periodically to prevent dust accumulation, which can affect heat dissipation. If any issues are detected, refer to the troubleshooting guide in the manual for inspection and repair.
Service and Guarantee Commitment
The GE IS200BPPBH2CAA comes with a comprehensive warranty, ensuring customer satisfaction and peace of mind. GE provides technical support and service to assist with installation, troubleshooting, and maintenance, ensuring the stable operation of the industrial automation system.
