GE IC695CRU320CA

Description

Detailed Parameter Table

GE IC695CRU320CA

Product Introduction

The GE IC695CRU320CA is a high-reliability rack-mounted power supply module designed exclusively for GE’s RX3i series PLC systems, serving as the “power core” to deliver stable electrical energy to the entire automation control system. As a critical infrastructure component of the RX3i ecosystem, the GE IC695CRU320CA ensures consistent power supply to key devices such as RX3i CPU modules (e.g., IC695CPU315CA), analog/digital I/O modules, and communication modules—preventing system downtime caused by voltage fluctuations or power interruptions.

Equipped with dual-input compatibility (100-240V AC / 120-300V DC), the GE IC695CRU320CA adapts to diverse industrial power grids worldwide, eliminating the need for additional voltage converters. It provides two independent output channels: a 5V DC main output (20A max) to power the RX3i backplane and connected modules, and a 24V DC auxiliary output (2A max) for external devices like sensors or small actuators. With built-in overcurrent, overvoltage, and overtemperature protection, the GE IC695CRU320CA safeguards both itself and connected equipment from electrical damage, making it a trusted choice for mission-critical industrial applications.

Core Advantages and Technical Highlights

Dual-Input Flexibility: Unlike single-input power supplies, the GE IC695CRU320CA supports both AC (100-240V) and DC (120-300V) input, enabling seamless deployment in regions with varying power standards (e.g., 110V AC in North America, 220V AC in Europe) or in DC-powered environments (e.g., solar-powered remote monitoring stations). This flexibility reduces inventory costs for global manufacturers and simplifies system integration across different sites.

High Output Capacity and Stability: The GE IC695CRU320CA delivers a total of 120W continuous power, with its 5V DC main output (20A) capable of supporting fully loaded RX3i backplanes (e.g., a 16-slot chassis with multiple I/O and communication modules). Its advanced voltage regulation technology ensures output voltage ripple of less than 50mV, preventing data corruption or module malfunctions caused by unstable power—critical for sensitive components like the IC695CPU315CA CPU module.

Comprehensive Protection Mechanisms: The GE IC695CRU320CA integrates three layers of protection to enhance system resilience. Overcurrent protection (OCP) triggers when output current exceeds safe limits (e.g., due to a short circuit in an I/O module), cutting off power to prevent component burnout. Overvoltage protection (OVP) safeguards connected modules from voltage spikes (e.g., from grid surges). Overtemperature protection (OTP) shuts down the unit if internal temperature exceeds 75°C, avoiding damage from overheating in enclosed cabinets.

Intuitive Status Monitoring: The GE IC695CRU320CA features four LED indicators that provide real-time visibility into power supply status: green LEDs confirm normal AC/DC input, 5V DC output, and 24V DC output, while a red fault LED alerts operators to issues like overcurrent or overtemperature. This allows maintenance teams to quickly identify and resolve power-related problems without specialized test equipment, minimizing troubleshooting time.

Typical Application Scenarios

The GE IC695CRU320CA is indispensable in industrial environments where stable power is critical for PLC operation. In automotive manufacturing plants, for example, the GE IC695CRU320CA powers a RX3i PLC system (including IC695CPU315CA and I/O modules) that controls robotic assembly lines. Its dual-input capability adapts to the plant’s 480V AC three-phase grid (via step-down to 240V AC), while its 20A 5V DC output supports multiple I/O modules monitoring part presence and robot position. The overcurrent protection prevents damage to expensive robotic controllers if a sensor short circuit occurs, ensuring uninterrupted production.

In oil and gas refineries, the GE IC695CRU320CA is installed in hazardous area-rated cabinets (with appropriate enclosures) to power RX3i PLCs managing distillation processes. Its wide operating temperature range (0°C to 60°C) withstands the heat generated by nearby processing equipment, while the 24V DC auxiliary output powers explosion-proof sensors that monitor hydrocarbon levels. The module’s overtemperature protection prevents failures during summer months when cabinet temperatures rise, avoiding costly shutdowns of critical refining operations.

In water and wastewater treatment facilities, the GE IC695CRU320CA powers a RX3i system controlling pump stations and chemical dosing units. Its DC input compatibility allows it to connect to backup batteries, ensuring the PLC remains operational during grid outages—critical for maintaining chemical dosing and preventing untreated water from being released. The 24V DC auxiliary output directly powers level sensors in pump wells, eliminating the need for separate power supplies and simplifying system design.

GE IC695CRU320CA

Related Model Recommendations

GE IC695CRU310CA: A lower-capacity variant of the GE IC695CRU320CA (5V DC: 10A, 24V DC: 1A, 60W total power), ideal for small RX3i systems (e.g., 3-slot chassis with IC695CPU310CA) in applications like packaging lines.

GE IC695CPU315CA: RX3i series CPU module, directly powered by GE IC695CRU320CA’s 5V DC output—relies on the power supply’s stability for fast program execution.

GE IC695ALG600: 4-channel analog input module, paired with GE IC695CRU320CA to ensure accurate sensor data collection (stable 5V DC prevents signal noise).

GE IC695PWR120: A 24V DC power supply accessory that complements GE IC695CRU320CA—provides additional 24V DC current (10A) for large numbers of external sensors (e.g., in food processing plants).

GE IC695LRE001: Remote I/O adapter, powered by GE IC695CRU320CA’s 5V DC output via the RX3i backplane, enabling distributed I/O in remote locations (e.g., outdoor pump stations).

GE IC695COMM301: Ethernet/IP communication module, depends on GE IC695CRU320CA for stable power to maintain continuous data transfer between the RX3i PLC and GE IC754VBF15CTD HMI.

GE IC695MEM200: Memory expansion module for RX3i CPUs, powered by GE IC695CRU320CA’s 5V DC output—ensures reliable storage of large program files.

GE IC695CHS016: 16-slot RX3i backplane, designed to work with GE IC695CRU320CA—the power supply plugs into the backplane to distribute 5V DC to all installed modules.

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing GE IC695CRU320CA, power off the RX3i backplane and wear an ESD wrist strap to protect internal components. Verify that the backplane is an RX3i series model (3-slot to 20-slot) and that the input voltage (AC or DC) matches the module’s specifications. Inspect the module’s backplane pins for bending or corrosion—damaged pins can cause short circuits. Align GE IC695CRU320CA with the backplane’s guide rails (it occupies 1 slot), push firmly until it clicks into place, and secure with the side locking screws to resist vibration. Connect the input power cable to the module’s terminal block (ensure correct polarity for DC input) and route cables away from high-voltage wires to avoid interference.

Maintenance suggestions: Conduct monthly visual inspections of GE IC695CRU320CA’s LED indicators—all green LEDs indicate normal operation, while a red fault LED requires immediate attention (check for overcurrent, overvoltage, or overtemperature). Every 3 months, clean the module’s vents with compressed air to remove dust (blocked vents cause overheating). Use a multimeter to verify output voltages (5V DC should be 4.95V-5.05V, 24V DC 23.4V-24.6V) to ensure stability. If the module faults, disconnect input power, check for short circuits in connected modules, and reset the unit by power cycling. Replace GE IC695CRU320CA only with genuine GE modules to maintain compatibility—back up the PLC program before replacement to avoid data loss during system restart.

Service and Guarantee Commitment

The GE IC695CRU320CA comes with a 36-month warranty from the date of purchase, covering defects in materials, workmanship, and electrical performance under normal industrial use. GE’s global technical support team is available 24/7 via email, online chat, and phone to assist with installation, troubleshooting, and commissioning—critical issues (e.g., power supply failure causing PLC downtime) receive priority support, with a response time of less than 2 hours and on-site assistance (if needed) within 48 hours in major industrial regions.

For customers requiring extended support, GE offers customized service agreements tailored to GE IC695CRU320CA, including annual preventive maintenance (cleaning, voltage testing), firmware updates (if applicable), and expedited spare parts delivery. All genuine GE IC695CRU320CA units undergo rigorous testing to meet international safety standards (UL 508, IEC 61131-2) and EMC immunity requirements (EN 61326-1), ensuring reliable operation in harsh industrial environments. In the event of a warranty claim, GE provides a replacement power supply within 48 hours (for stock items) to minimize system downtime, reflecting our commitment to product quality and customer operational continuity.
