DS3800HVDB1K1G: Product Overview
The DS3800HVDB1K1G is a daughterboard-grade video driver that occupies a 6BA06 slot in the GE Speedtronic Mark IV rack. It receives digital video data from the CPU over the VME back-plane, converts it to analog RGB or composite video, and drives local CRT or LCD monitors mounted on the turbine deck, control room, or remote pendant. The card is hardware-configured (no firmware) and deterministic, making it suitable for safety-related local display when triple-redundant.
Physical implementation includes video DACs, output amplifiers, 1500 V AC galvanic isolation, and TVS surge suppressors. A modular keyed connector on one edge and retention levers ensure blind-mate insertion in crowded card cages. Front-edge LEDs (green = sync active, red = loss of video) give real-time display health—no oscilloscope required during commissioning.
Environmental qualification meets –20 °C to +70 °C and IEEE 344 form-factor, permitting installation directly on the turbine deck with no extra HVAC. MTBF is >250 000 h at 55 °C, giving >20-year service life in baseload duty.
DS3800HVDB1K1G
DS3800HVDB1K1G: Technical Specifications
-
Model Number: DS3800HVDB1K1G
-
Manufacturer: General Electric (GE Energy)
-
Product Type: Video Driver Card
-
System Compatibility: Speedtronic Mark IV (6BA06 slot)
-
Input: Digital video bus from CPU (VME back-plane)
-
Output: Analog RGB or composite video (jumper-selectable)
-
Resolution: Up to 640 × 480 @ 60 Hz (Mark IV native)
-
Isolation: 1500 V AC board-to-ground, 500 V channel-to-channel
-
Connectors: Modular keyed, retention levers, gold-plated
-
Surge Protection: TVS diodes on every line, >500 V clamp
-
Indicators: Green = sync active, Red = video loss / fault
-
Temp Range: -20 °C to +70 °C operational, -40 °C to +85 °C storage
-
Certifications: CE, RoHS, IEEE 344 form-factor compatible
Core Features & Customer Value
Hardware-Only Video Generation
No firmware means no download, no scan jitter, and no risk of display freeze during CPU resets—critical for local overspeed, temperature, or trip indications during start-ups.
No firmware means no download, no scan jitter, and no risk of display freeze during CPU resets—critical for local overspeed, temperature, or trip indications during start-ups.
Hot-Swappable in TMR Strings
Daughterboard form allows online replacement in <3 min; remaining two legs continue displaying vital signs, achieving >99.97 % availability on combined-cycle fleets.
Daughterboard form allows online replacement in <3 min; remaining two legs continue displaying vital signs, achieving >99.97 % availability on combined-cycle fleets.
Field-Selectable Video Format
Jumpers choose RGB or composite output and 60 Hz / 50 Hz refresh—technician can match any CRT or LCD on site without software tools, reducing commissioning time by >50 %.
Jumpers choose RGB or composite output and 60 Hz / 50 Hz refresh—technician can match any CRT or LCD on site without software tools, reducing commissioning time by >50 %.
Surge-Hardened for Turbine Deck
TVS diodes clamp >500 V spikes from exciter flash-over or lightning. 1500 V isolation prevents ground-fault propagation to CPU cards, reducing unplanned replacement by >60 % compared with commercial graphics cards.
TVS diodes clamp >500 V spikes from exciter flash-over or lightning. 1500 V isolation prevents ground-fault propagation to CPU cards, reducing unplanned replacement by >60 % compared with commercial graphics cards.
DS3800HVDB1K1G
Typical Applications
Gas Turbine Local Display
Drives 19-inch CRT on turbine deck for speed, temperature, and trip status during Frame 7/9 start-ups—hardware-only output survives CPU reboots, ensuring operators never lose vital signs.
Drives 19-inch CRT on turbine deck for speed, temperature, and trip status during Frame 7/9 start-ups—hardware-only output survives CPU reboots, ensuring operators never lose vital signs.
Steam Turbine Control Room Monitor
Remote composite output feeds CCTV matrix in central control room, allowing shift engineers to observe steam temperature trends without entering the turbine hall.
Remote composite output feeds CCTV matrix in central control room, allowing shift engineers to observe steam temperature trends without entering the turbine hall.
Black-Start & Island Mode Operation
Local display remains active during grid loss and battery-only operation, providing critical speed and voltage indications when remote SCADA is unavailable .
Local display remains active during grid loss and battery-only operation, providing critical speed and voltage indications when remote SCADA is unavailable .
