Description
Product Core Brief
- Model: FCP270 P0917YZ
- Brand: FOXBORO
- Series: I/A Series DCS
- Core Function: Executes continuous and sequential control logic as the central processing unit for field-level automation.
- Product Type: Field Control Processor
- Key Specs: 16MB SDRAM, 32MB Flash, 24V DC, Redundant Capable
- Condition: New Original (New Surplus)
Key Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Field Control Processor |
| Memory | 16 MB SDRAM / 32 MB Flash |
| Input Voltage | 24 Vdc (Redundant Support) |
| Power Consumption | Max 8.5 W (Non-fault-tolerant) |
| Operating Temp | 0 to +60 °C |
| Dimensions (LxWxH) | 14.7 x 5.15 x 11.4 cm |
| Weight | 0.6 kg |
| Communication | 100 Mbps Ethernet (Fiber) / HDLC Fieldbus |
| Environmental Rating | G3 Level (Harsh Environment) |
FOXBORO FCP270
Product Introduction
Reliable process control at the field level requires a processor that can handle complex logic while surviving harsh industrial environments. The is a high-performance field control processor designed for the I/A Series DCS. It executes regulatory, logic, timing, and sequence control functions while communicating with up to 32 Series 200 FBM modules over a redundant fieldbus.
This controller features a patented fault-tolerant architecture when configured in pairs, ensuring bumpless transfer during hardware faults. Field engineers specify the for its robust cast-aluminum housing and G3 environmental rating, making it ideal for continuous process applications in petrochemical, power, and manufacturing facilities where uptime is critical.
Key Selling Points & Differentiators
- Patented Fault-Tolerant Design: Supports dual-processor redundancy with automatic failover; not recommended for simplex-only installations requiring zero redundancy.
- High-Density FBM Support: Connects up to 32 Series 200 FBMs natively, or 128 with FEM100 expansion, eliminating the need for separate communication modules.
- Rigorous Live Bench Testing: Every unit undergoes a 24-hour continuous load test with fieldbus communication verification and control logic simulation before shipping.
- New Surplus Availability: Factory-sealed condition with verified source traceability, bypassing typical OEM lead times for discontinued I/A Series hardware.
- Anti-Counterfeit Verification: Serial numbers are checked against manufacturer databases during incoming inspection to guarantee authenticity.
FOXBORO FCP270
FAQ
The is designed for the I/A Series platform, but compatibility with specific sub-platforms depends on firmware and backplane revision. Always verify your system’s exact configuration and check the I/A Series hardware compatibility matrix before ordering. Mixing incompatible processor revisions can cause control network communication failures.
The is the specific part number for this processor variant. While base modules share the same architecture, the suffix may indicate firmware version, memory configuration, or regional certifications. Always match the exact part number to ensure drop-in compatibility with your existing control strategy and redundant pair.
Do I need to configure the control strategy before installing?
Yes. The processor requires loading your control strategy, configuring fieldbus addresses, and setting up redundant pairing (if applicable) in the I/A Series control builder. I always recommend backing up your database, verifying firmware compatibility, and running a full hardware scan after installation to confirm communication with all connected FBMs.
What happens if the primary processor fails?
When configured in a fault-tolerant pair, the backup processor automatically assumes control with bumpless transfer, ensuring zero process disruption. The system maintains synchronization between primary and secondary processors in real-time. However, this requires both modules to be properly configured and communicating over the integrated fault-tolerant connector.
Is there a warranty on this new surplus unit?
Yes. All new surplus modules come with a standard 12-month functional warranty. If the unit fails during normal operation within that period, we provide a direct replacement. We also include our internal test report with every shipment so you can verify the 24-hour load test and control logic results before installation.
