Description
Product Core Brief
- Model: FCM2F2 P0914YZ
- Brand: Foxboro (Invensys / Schneider Electric)
- Series: I/A Series 200 Series Distributed Control System (DCS)
- Core Function: Acts as a fiber optic fieldbus extender to remotely install 200 Series FBM modules up to 2 km from the main control node.
- Product Type: Fiber Optic Communication Module (FCM)
- Key Specs: 2 km Max Distance | Multimode Fiber | Redundant Ready | Part Number
- Condition: New Original (New Surplus) | Factory Sealed
Key Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Fiber Optic Fieldbus Extender (FCM) |
| System Platform | Foxboro I/A Series 200 Series DCS |
| Max Fiber Distance | 2 km (1.24 miles) per segment |
| Fiber Type | Multimode, Graded Index (62.5/125 µm) |
| Connector Type | ST Connector |
| Redundancy | Supports Redundant Pair Configuration |
| FBM Capacity | Up to 8 FBMs per Baseplate |
| Operating Temp | -40°C to 85°C (with G3 Enclosure) |
| Environmental Rating | G3 Harsh Environment (ISA S71.04) |
| Condition | New Original (New Surplus) |
| Warranty | 1-Year Functional Warranty |
FOXBORO FCM2F2
Product Introduction
Extending your I/A Series control system to remote field locations without sacrificing reliability requires a robust fiber optic link, and the is engineered for exactly this purpose. This fieldbus communication module allows you to install 200 Series FBM modules up to 2 km away from the main control node, effectively decentralizing your I/O while maintaining centralized control.
Designed for harsh industrial environments, the uses multimode fiber optic cabling that is completely immune to electrical noise, EMI, RFI, and lightning surges. Whether you are monitoring rotating machinery, arc welders, or outdoor process skids, this module provides galvanic isolation and reliable high-speed data transmission. It supports redundant configurations for maximum availability and can be hot-swapped without powering down the baseplate.
Key Selling Points & Differentiators
- 2 km Remote Extension: Extends the I/A Series fieldbus up to 2 km (1.24 miles) using multimode fiber, enabling remote I/O placement in hazardous or electrically noisy areas.
- EMI/RFI Immunity: Fiber optic connection provides complete galvanic isolation, eliminating ground loops, voltage differences, and electromagnetic interference from motors, welders, or high-voltage cables.
- Redundant Ready: Supports redundant FCM pairing on the baseplate to ensure continuous communication if one module or fiber link fails.
- High FBM Density: A single remote baseplate can host up to 8 FBM modules, maximizing remote I/O density and reducing field wiring costs.
- Verified Functionality: Every undergoes a 24-hour live load test on a dedicated I/A Series test rack before shipping, complete with a signed test report.
- Not Recommended For: Do not use this module for copper fieldbus extension beyond 60 meters; use FCM2F4 for 4 km or FCM2F10 for 10 km distances.
- Stock Availability: Current inventory is factory-sealed new surplus with traceable lot numbers; typically ships within 48 hours of order confirmation.
- Warranty Backed: Includes a 1-year functional warranty covering manufacturing defects and DOA conditions, with no restocking fees for verified failures.
FOXBORO FCM2F2
FAQ
Yes. All units in stock have passed our 24-hour live bench test and include a signed test report. We ship same-day for orders placed before 2 PM EST, so you’ll have tracking before end of day.
The is designed specifically for 200 Series FBM baseplates. Verify your baseplate revision and node processor firmware first to ensure proper recognition of the fiber optic extender. Send us your baseplate part number, and we’ll confirm compatibility within 30 minutes.
The requires multimode, graded-index fiber with a 62.5 µm core and 125 µm cladding (NA 0.275). It uses ST connectors. Do not use single-mode cable with this module; use FCM2F10 for single-mode applications.
No. Both ends of a fiber optic segment must use the same FCM type. You can use two FCM2F2s for a 2 km link, or two FCM2F4s for a 4 km link, but you cannot mix them on the same segment.
Do I need to reconfigure the module after installation?
No. The retains its configuration in the I/A Series node processor. Simply plug it into the same slot, and the system will recognize it. However, always verify the fiber link status LEDs and redundancy settings in your DCS configuration tool after replacement.
What if one module in the redundant pair fails?
The healthy FCM will automatically maintain the fieldbus communication while reporting the fault. You can hot-swap the failed module without removing fiber cables or interrupting remote I/O operation.
Is this a refurbished or new surplus unit?
This is New Original (New Surplus) – factory sealed, never installed, with full traceability to the original manufacturing lot. It is not refurbished, repaired, or pulled from a decommissioned system. We provide the original manufacturer’s lot code upon request for your quality records.
Quality Transparency SOP
- Incoming Verification: Source traceability confirmed via lot code; anti-counterfeit visual inspection; serial number cross-referenced with OEM records; accessories verified.
- Live Bench Test: Dedicated I/A Series test rack; power-on self-check; fiber optic link handshake test; 2 km distance simulation; redundant failover validation; 24-hour continuous load test; signed test report generated.
- Electrical Tests: Insulation resistance verified at 500V megger (>10 MΩ); ground continuity confirmed; fiber port optical power level validated.
- Firmware Verification: Firmware version recorded; communication stack configuration backed up and documented.
- Final QC & Packaging: QC sign-off; anti-static seal applied; shock protection installed; QC Passed label affixed with date and inspector ID.
Test photos and video available upon request. We never claim “100% failure-free” – we provide verified, tested units with documented performance.
Technical Risk Avoidance
- Fiber Type Mismatch: Risk: Link failure. Prevention: Verify you are using multimode 62.5/125 µm fiber with ST connectors. Field Note: We’ve seen FCM2F2s fail to link because a technician used single-mode cable. Always verify fiber specs.
- Mixed FCM Types: Risk: Communication failure. Prevention: Ensure both ends of the fiber segment use the same FCM model. Field Note: Mixing and FCM2F4 on the same link caused persistent link faults. Match the models.
- Baseplate Seating: Risk: Intermittent remote I/O dropouts. Prevention: Ensure the module is fully seated and locked onto the baseplate. Field Note: A partially seated FCM caused random remote FBM failures during vibration. Push firmly until the latch clicks.
- Fiber Bend Radius: Risk: Signal attenuation. Prevention: Maintain minimum bend radius for fiber cables; do not kink or crush. Field Note: A sharp bend in the fiber trunk caused intermittent link loss that mimicked a bad FCM. Check cable routing.
- ESD Damage: Risk: Silent fiber port failure. Prevention: Use grounded wrist strap and anti-static mat during handling. Field Note: We’ve tested modules that passed power-on but had dead fiber ports after 48 hours due to ESD. Handle with care.
