GE Fanuc F650NFLF2G5HIP6E Feeder Protection & Bay Controller
Product Overview
The F650NFLF2G5HIP6E is a high-performance feeder protection and bay controller developed by GE Fanuc, tailored for the precise monitoring and reliable control of modern power systems. As a core component of GE’s Multilin F650 series, F650NFLF2G5HIP6E integrates comprehensive protection functions, high-precision measurement capabilities, and robust communication interfaces, serving as a “safety guardian” for power distribution networks. It effectively identifies and responds to faults such as overcurrent, overvoltage, and ground faults, ensuring the stable operation of power equipment and minimizing downtime losses.
What sets F650NFLF2G5HIP6E apart is its ability to balance advanced technology with practical applicability. Whether in industrial substations, commercial power grids, or renewable energy projects, it provides real-time data support for operation and maintenance personnel through accurate measurement and flexible communication protocols. Its user-friendly design and robust environmental adaptability make it an ideal choice for both new power system construction and old equipment upgrading, delivering tangible value in enhancing power supply reliability and operational efficiency.
Technical Specifications
Parameter Name | Parameter Value ———|——– Product Model | F650NFLF2G5HIP6E Manufacturer | GE Fanuc Product Type | Feeder Protection & Bay Controller Power Supply | DC 24-48V, AC 110/120/230V (selectable) Voltage Input Range | 2 to 275VAC Analog Input Accuracy | ±0.2% full scale Digital Input Response Time | < 1ms Communication Protocols | Modbus RTU/DNP 3.0, IEC 60870-5-104, IEC 61850 Operating Temperature | -20°C to +60°C Humidity Range | 5% to 95% non-condensing Protection Rating | IP52 Mounting Type | Flush or rack-mounted Weight | 2000g (approx.) Output Continuous Current | 16A (60A for 1 second)
F650NFLF2G5HIP6E
Main Features and Advantages
Comprehensive protection capabilities: F650NFLF2G5HIP6E covers a full range of protection functions for power feeders, including overcurrent, overvoltage, undervoltage, and ground fault protection. It features precise setting thresholds and fast response mechanisms, which can quickly isolate faulty components within milliseconds to prevent fault expansion. The built-in load relay with ultra-low burden (0.05VA at 120VAC) ensures no interference with the accuracy of the main protection circuit.
High-precision measurement and synchronization: Equipped with a high-performance measurement chip, F650NFLF2G5HIP6E achieves ±0.2% full-scale accuracy for analog inputs, accurately capturing current, voltage, power, and other key electrical parameters. It supports IRIG-B time synchronization (TTL level, demodulated) and a real-time clock with 20ppm accuracy and over 1 week of backup, ensuring consistent time stamps for fault events and facilitating post-fault analysis.
Flexible communication and integration: F650NFLF2G5HIP6E is equipped with an RS-232 front port (up to 115200 baud rate) and supports multiple mainstream communication protocols. This enables seamless integration with SCADA systems, HMI panels, and other automation equipment, realizing centralized monitoring and remote control of power systems. The compatibility with IEC 61850, the international standard for substation communication, ensures its adaptability in global projects.
Robust and reliable performance: With an IP52 protection rating and an operating temperature range of -20°C to +60°C, F650NFLF2G5HIP6E can operate stably in harsh industrial environments such as dusty workshops and outdoor substations. Its output relays can withstand 60A current for 1 second, meeting the instantaneous load requirements of circuit breaker tripping, while the 260VAC permanent voltage withstand capability ensures long-term reliability under voltage fluctuations.
Application Field
In industrial substations, F650NFLF2G5HIP6E plays a core role in protecting and controlling feeders connected to heavy machinery. For example, in an automotive manufacturing plant, it monitors the power supply lines of welding robots and assembly lines in real time. When an overcurrent fault occurs due to equipment overload, F650NFLF2G5HIP6E quickly trips the circuit breaker and sends an alarm signal to the central control room, avoiding equipment damage and production line shutdowns. Its rack-mounted design allows for easy integration into the substation’s control cabinet, saving installation space.
In commercial power distribution systems, such as large shopping malls and data centers, F650NFLF2G5HIP6E ensures continuous power supply to critical loads. It accurately measures the power consumption of each feeder, providing data support for energy management, while its undervoltage protection function prevents sensitive equipment (such as servers and HVAC systems) from being damaged by voltage sags. The flush-mounted option makes it suitable for installation in tight control rooms without affecting operational accessibility.
In renewable energy projects, such as solar farms and wind power plants, F650NFLF2G5HIP6E is used to protect the feeders connecting renewable energy generators to the grid. It monitors the output current and voltage of the generators, and in case of grid faults, it quickly disconnects the generators to avoid reverse power flow. Its compatibility with IEC 61850 ensures smooth communication with the grid’s dispatching system, meeting the grid-connection requirements for renewable energy.
Related Products
F650NFLF2G5HIP5E: A sibling model in the same F650 series, with identical protection functions but supporting only AC 120-230V power supply, suitable for single-power-supply scenarios.
F650NFLF2G5HIP7E: An upgraded version of F650NFLF2G5HIP6E, adding Ethernet communication ports and supporting IEEE 1588 PTP time synchronization for high-precision application requirements.
GE IC695CMU310: A multi-protocol communication module that matches F650NFLF2G5HIP6E, extending its communication capabilities to connect with legacy RS-485 devices.
GE F650LCD001: A dedicated LCD display module for F650NFLF2G5HIP6E, providing a larger screen and more intuitive operation interface for on-site monitoring.
GE F650PWR002: A redundant power supply module compatible with F650NFLF2G5HIP6E, ensuring uninterrupted power supply for the protection device.
GE F650CAB003: A special communication cable for F650NFLF2G5HIP6E, with shielded design to reduce electromagnetic interference in industrial environments.
GE F650REL004: A replacement output relay for F650NFLF2G5HIP6E, facilitating quick maintenance and reducing downtime.
