Description
Product Core Brief
- Model: AMS 6500 ATG
- Brand: EMERSON
- Series: Machinery Health Management
- Core Function: Provides API 670 compliant protection and predictive diagnostics for rotating assets.
- Product Type: Machinery Protection & Monitoring System
- Key Specs: SIL 2 Rated | PeakVue Technology | OPC UA / Modbus
(Condition: New Original / New Surplus)
EMERSON 1C31132G01
Product Introduction
EMERSON AMS 6500 serves as the critical safety brain for turbines and compressors. This protection system continuously monitors vibration, temperature, and process parameters to prevent catastrophic failures.
The AMS 6500 ATG integrates PeakVue technology for early bearing fault detection. It operates reliably across a -20°C to +70°C range with SIL 2 certification. This industrial automation unit bridges the gap between simple tripping and advanced predictive maintenance.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | EMERSON |
| System Type | AMS 6500 ATG Protection |
| Compliance | API 670 / SIL 2 / ATEX / IECEx |
| Sampling Rate | Up to 18.75 kHz (UM Card) |
| Communication | OPC UA / Modbus TCP / RTU |
| Key Technology | PeakVue™ Impact Detection |
| Power Supply | 24V DC / 125V DC Options |
| Mounting | Standard 19″ Rack or Compact Panel |
| Design Life | > 25 Years |
| Diagnostics | Embedded Prediction & Trending |
Quality Control Process
Every EMERSON AMS 6500 channel undergoes rigorous signal validation. Technicians inspect backplane connectors and card seating for oxidation. We then perform a functional loop test on a live vibration simulator. A signal generator verifies trip logic at exact alarm thresholds. An oscilloscope checks the PeakVue impact signal integrity for noise. Finally, the rack is sealed in anti-static shielding to prevent ESD damage during transit.
Replacement Pitfall Guide
❗ Verify Card Compatibility. The AMS 6500 uses specific card slots. Inserting an A6500-UM into a TP-only slot will cause communication faults. Always match the card type to the chassis slot designation.
❗ Never Hot-Swap Protection Cards. Pulling a monitor while energized can trigger a nuisance trip or damage the backplane. Always bypass the protection logic or isolate power before swapping modules.
❗ Check Grounding & Shielding. Vibration signals are micro-volt level. A floating ground will inject 60Hz hum into your spectra, masking real bearing faults. Ensure the rack ground strap is tight and sensor cables are shielded.
❗ Confirm Firmware Revision. The AMS 6500 ATG requires specific firmware for PeakVue features. Mixing old CC cards with new UM cards without updating the CC firmware will result in “Card Not Recognized” errors.
Keep these in mind and you’ll cut 90% of rework time.
EMERSON 1C31132G01
Compatibility Matrix & Benchmarks
| Original Model | Replacement / Successor Model | Compatibility Level (Direct/Needs Adaptation) | Migration Notes |
|---|---|---|---|
| AMS 6500 | AMS 6500 ATG | Direct | ATG adds embedded prediction; same rack |
| AMS 6500 | A6500-UM Card | Direct | Universal Measurement; replaces legacy UM |
| AMS 6500 | A6500-TP Card | Direct | Temperature/Process; requires CC firmware update |
- Fault Detection: PeakVue identifies bearing spalls 3-6 months before vibration
- Reliability: SIL 2 Certified for Safety Instrumented Functions
