Description
Detailed parameter table
| Parameter name | Parameter value |
| Product model | TIOC-555HD |
| Manufacturer | CCC Certified Manufacturer |
| Product category | High-density industrial I/O controller |
| I/O capacity | 64 digital inputs, 32 digital outputs, 16 analog inputs |
| Digital input type | 24V DC, sinking/sourcing (configurable) |
| Digital output type | 24V DC, 2A per channel |
| Analog input range | 4-20mA, 0-10V DC (configurable per channel) |
| Processor | 32-bit ARM Cortex-A9, 1GHz |
| Memory | 2GB RAM, 8GB flash storage |
| Communication protocols | Modbus TCP/IP, Ethernet/IP, PROFINET |
| Operating temperature | -30°C to 70°C |
| Protection rating | IP20 |
| Mounting type | DIN rail (35mm) |
| Dimensions | 180mm × 120mm × 80mm |
| Certifications | CCC, CE, UL 508, RoHS |
CCC TIOC-555HD
Product introduction
The TIOC-555HD is a high-performance industrial I/O controller designed to serve as the backbone of distributed control systems in complex automation environments. As a flagship product from CCC, TIOC-555HD integrates robust processing capabilities with extensive I/O connectivity, making it ideal for applications requiring precise monitoring and control of diverse industrial equipment.
With its 64 digital inputs, 32 digital outputs, and 16 analog inputs, TIOC-555HD eliminates the need for multiple standalone modules, reducing cabinet space and wiring complexity. The controller’s multi-protocol support ensures seamless integration with PLCs, SCADA systems, and HMI panels from major manufacturers. Whether deployed in automotive production, packaging lines, or material handling systems, TIOC-555HD acts as a central hub for data acquisition and control execution, enabling real-time decision-making and improving process efficiency.
Core advantages and technical highlights
High-density integration: TIOC-555HD packs 112 I/O points into a compact enclosure, delivering 30% more connectivity than comparable controllers in its class. This density is particularly valuable in space-constrained environments like mobile machinery or compact production cells, where every centimeter of cabinet space matters. The 16 analog inputs, each configurable for 4-20mA or 0-10V signals, eliminate the need for external signal converters when connecting pressure, temperature, or level sensors.
Flexible I/O configuration: Each digital input on TIOC-555HD can be individually set to sinking or sourcing mode via software, eliminating the need for hardware jumpers. This flexibility allows the controller to interface with diverse field devices—from NPN sensors to PNP actuators—without additional adapters. Digital outputs support up to 2A per channel, enabling direct control of small motors or solenoid valves without external relays, simplifying system design.
Rapid processing and communication: Powered by a 1GHz ARM Cortex-A9 processor, TIOC-555HD executes control logic in under 1ms, ensuring timely response to critical events. Its triple-protocol support (Modbus TCP/IP, Ethernet/IP, PROFINET) allows simultaneous communication with multiple systems—for example, sending real-time data to a SCADA via Modbus while receiving setpoints from a PLC over PROFINET. This multi-tasking capability reduces network traffic and improves system responsiveness.
Extreme environment resilience: TIOC-555HD operates reliably in temperatures ranging from -30°C to 70°C, making it suitable for cold storage facilities, outdoor installations, and high-heat industrial zones like foundries. Its rugged design includes conformal coating on circuit boards to resist moisture and chemical exposure, a critical feature in food processing or chemical manufacturing plants. The controller’s MTBF exceeds 150,000 hours, ensuring long-term reliability in mission-critical applications.
Typical application scenarios
In semiconductor manufacturing cleanrooms, TIOC-555HD monitors and controls wafer handling systems, using its 64 digital inputs to track sensor data from robotic arms and positioning stages. The 16 analog inputs measure air pressure and temperature in the controlled environment, while digital outputs regulate valves and actuators. Its compact size fits into the limited space of cleanroom enclosures, and multi-protocol support integrates with both the facility’s Siemens PLCs (via PROFINET) and supervisory systems (via Modbus TCP/IP), ensuring precise coordination of complex processes.
In logistics automation centers, TIOC-555HD manages conveyor systems and sorting machines, processing input signals from photoelectric sensors (detecting package presence) and controlling motor drives via digital outputs. The analog inputs monitor conveyor belt tension, enabling predictive maintenance alerts when values deviate from set ranges. Mounted in industrial cabinets exposed to temperature fluctuations, TIOC-555HD maintains consistent performance, ensuring packages are sorted and routed accurately—even during 24/7 operation.
CCC TIOC-555HD
Related model recommendations
TIOC-550HD: A mid-range variant of TIOC-555HD with 32 digital inputs, 16 outputs, and 8 analog inputs, ideal for smaller-scale applications.
TIOC-666HD: An upgraded model with 128 digital I/O and 32 analog inputs, offering expanded capacity for TIOC-555HD users scaling their systems.
TIOX-100: An expansion module that adds 16 relay outputs to TIOC-555HD, suitable for controlling high-voltage devices like heaters or pumps.
COMM-300: A communication gateway that extends TIOC-555HD’s protocol support to include BACnet, enabling integration with building management systems.
PWR-24V-10A: A redundant power supply optimized for TIOC-555HD, ensuring uninterrupted operation during mains failures.
TIOC-555HDR: A ruggedized version of TIOC-555HD with IP65 protection, designed for direct machine-mounting in harsh environments.
HMI-700: A 7-inch touchscreen panel that pairs with TIOC-555HD for local monitoring and control, displaying real-time I/O status and allowing parameter adjustments.
Installation, commissioning and maintenance instructions
Installation preparation: Mount TIOC-555HD on a 35mm DIN rail in a clean, dry control cabinet, ensuring at least 100mm clearance on all sides for ventilation. Verify the supply voltage is 24V DC ±10% before wiring. Use 0.5mm² twisted-pair cables for analog signals and 0.75mm² cables for digital I/O, with shielded wiring for analog channels to minimize noise. Required tools include a torque screwdriver (0.4-0.6Nm), wire strippers, and a laptop with configuration software. Power off all connected equipment during installation, and connect the protective earth terminal to the cabinet ground.
Maintenance suggestions: Inspect TIOC-555HD quarterly for dust accumulation, cleaning with compressed air (maximum 50PSI) if needed. Check Ethernet and power connections monthly to ensure secure seating. Calibrate analog inputs annually using a precision signal generator to maintain accuracy within ±0.1% of full scale. If communication faults occur, verify network settings and cable integrity before resetting the controller. Replace the unit if I/O channels become unresponsive or processing errors persist, using only CCC-certified spares to ensure compatibility and safety.
Service and guarantee commitment
TIOC-555HD comes with a 5-year warranty from the installation date, covering manufacturing defects and ensuring compliance with published performance specifications. We guarantee technical support response within 2 hours for critical issues, with on-site service available in 48 hours for qualified applications. Our global support team provides assistance with configuration, troubleshooting, and integration with third-party systems. Extended service contracts include annual preventive maintenance, firmware updates, and priority access to technical resources, ensuring TIOC-555HD delivers reliable performance throughout its 10-year design lifespan. Customers receive access to online portals with software tools, user manuals, and application notes specific to TIOC-555HD.
