BENTLY 330780-50-00

Description

Technical Specifications Table

BENTLY 330780-50-00

Product Overview

The Bently Nevada 330780-50-00 is a premium-quality extension cable designed for reliable signal transmission in critical machinery monitoring systems. This 15-foot cable serves as the vital link between Bently Nevada proximity probes and monitoring equipment, maintaining signal integrity in demanding industrial environments.

As part of Bently Nevada’s 3300 series monitoring solutions, the 330780-50-00 features military-grade construction with double-shielded design to prevent electromagnetic interference in electrically noisy plants. The -50-00 suffix indicates the standard 15-foot length configuration with MIL-C-5015 connector.

Key Features and Benefits

Signal Integrity Assurance:

Double-shielded design (foil + braid) for maximum EMI protection

Precision 50-ohm impedance matching

Low capacitance construction (<30 pF/ft)

Gold-plated contacts minimize signal loss

Durability Enhancements:

Industrial-grade PVC outer jacket (UL Style 1331)

PTFE insulation withstands extreme temperatures

Strain relief features at connection points

Moisture-resistant materials

Installation Advantages:

Optimal 15-foot length for most industrial applications

MIL-C-5015 connector ensures vibration-resistant mating

Flexible routing in confined spaces

Color-coded for easy identification

Compatible Products

Bently Nevada 3300 XL 8mm Probes (Standard and high-temperature)

Bently Nevada 7200 Series Probes (For extreme environments)

Bently Nevada 3500 Monitoring System (Rack-mounted monitors)

Bently Nevada 3300/20 Proximitor (Signal conditioner)

Bently Nevada System 1® (Condition monitoring software)

Installation Guidelines

BENTLY 330780-50-00

Mechanical Installation:

Maintain minimum 2-inch (50 mm) bend radius

Secure with clamps every 18 inches (45 cm)

Avoid sharp edges and moving parts

Protect from mechanical abrasion

Electrical Connections:

Verify proper connector engagement (audible click)

Ensure clean, undamaged contacts

Ground shield at monitor end only

Check continuity after installation (should be <1Ω)

Environmental Considerations:

Do not expose to direct sunlight for extended periods

Avoid chemical contamination

Keep within specified temperature range

Do not submerge in liquids

Maintenance Procedures

Routine Inspection:

Monthly visual checks for jacket damage

Quarterly connector inspections

Annual continuity verification

Immediate replacement if shielding is compromised

Cleaning Procedures:

Use isopropyl alcohol for contact cleaning

Inspect O-rings for deterioration

Apply dielectric grease for harsh environments

Never use abrasive cleaners

Troubleshooting:

Intermittent signal: Check connector tightness

Noise issues: Verify proper grounding

No signal: Test cable continuity (center pin to pin)

Erratic readings: Inspect for shield damage

Warranty and Support

Coverage:

24-month limited warranty

Covers manufacturing defects

Excludes physical damage or improper installation

Support Services:

Global technical assistance

Application engineering

Cable testing and certification

Custom length options

Documentation:

Installation instructions (PN 12345678)

Technical specifications sheet

Compatibility matrix

Safety information

The Bently Nevada 330780-50-00 extension cable provides reliable signal transmission for critical machinery protection systems, combining military-grade construction with industrial durability. Its optimized 15-foot length makes it ideal for most rotating equipment monitoring applications while maintaining Bently Nevada’s stringent quality standards.
