Technical Specifications Table
| Parameter | Specification |
| Model Number | Bently Nevada 330709-000-050-10-02-00 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Type | Proximity Transducer System |
| Measurement Range | 0.08 to 0.236 in (2 to 6 mm) |
| Output Signal | -2 to -18 VDC |
| Frequency Response | 0 to 10 kHz |
| Temperature Range | -40°C to +120°C (-40°F to +248°F) |
| Power Requirement | 18-30 VDC, 10 mA typical |
| Probe Diameter | 8 mm |
| Cable Length | 5 m (16.4 ft) |
| Sensitivity | 200 mV/mil (7.87 V/mm) |
| Environmental Rating | IP67 |
| Compliance Standards | API 670, ISO 10816 |
| Connector Type | Integral MIL-C-5015 |
BENTLY 330709-000-050-10-02-00
Product Overview
The Bently Nevada 330709-000-050-10-02-00 represents a complete proximity transducer system designed for critical machinery monitoring applications. This high-precision system consists of a rugged probe, high-temperature cable, and driver electronics to provide accurate measurement of shaft vibration and position in rotating equipment.
Engineered for reliability in demanding industrial environments, this configuration features 316 stainless steel construction and is specifically designed for integration with Bently Nevada’s 3500 series monitoring systems. The 330709-000-050-10-02-00 variant includes a 5-meter cable length, making it ideal for installations requiring extended reach between the probe and monitoring equipment.
Key Features and Benefits
Advanced Measurement Capabilities:
High-resolution displacement measurement (0.08 to 0.236 in range)
Excellent linearity (±1% of full scale)
Wide frequency response for capturing dynamic motion
Stable output across temperature variations
Robust System Design:
Corrosion-resistant 316 stainless steel probe housing
High-temperature rated cable (up to 120°C continuous)
IP67 environmental protection
Vibration-resistant construction (up to 20 g)
Installation and Integration Advantages:
Standard 5-meter cable length reduces signal loss
MIL-C-5015 connector ensures secure mating
Compatible with Bently Nevada 3500 series monitors
Pre-calibrated for plug-and-play installation
BENTLY 330709-000-050-10-02-00
Industrial Applications
The Bently Nevada 330709-000-050-10-02-00 is specifically designed for:
Power Generation: Turbine shaft vibration monitoring
Oil & Gas: Compressor train protection
Petrochemical: Critical pump monitoring
Heavy Industry: Large motor and gearbox protection
The system provides essential measurements for:
Radial vibration monitoring
Axial position measurement
Eccentricity monitoring
Differential expansion
Phase reference
Compatible Monitoring Systems
Bently Nevada 3500/42: Radial Vibration Monitor
Bently Nevada 3500/40: Proximitor® Monitor
Bently Nevada System 1®: Condition monitoring software
Bently Nevada 3500/92: Communication Gateway
Bently Nevada 3500/15: Power Supply Module
Installation and Maintenance Guidelines
Installation Requirements:
Proper grounding of all system components
Recommended gap voltage setting: -10 VDC ± 0.5 V
Minimum bend radius of 50 mm for cables
Use of anti-rotation devices on probes
Verify proper clearance between probe tip and target
Maintenance Schedule:
Quarterly gap voltage verification
Annual comprehensive system check
Biannual cable integrity inspection
Immediate replacement if physical damage observed
Warranty and Support
Bently Nevada provides:
24-month standard warranty
Global technical support network
Application engineering assistance
Comprehensive documentation
Calibration services
The 330709-000-050-10-02-00 system is backed by Bently Nevada’s extensive experience in machinery protection systems, ensuring reliable performance in critical monitoring applications.
This technical product description provides comprehensive information about the Bently Nevada 330709-000-050-10-02-00 proximity transducer system, highlighting its technical specifications, features, and proper usage in industrial monitoring systems. The format is optimized for both maintenance technicians and procurement specialists in industries requiring reliable machinery condition monitoring solutions.
