BENTLY 170180-01-00

Description

Detailed parameter table

BENTLY 170180-01-00

Product introduction

The BENTLY NEVADA 170180-01-00 is a high-performance system configuration and diagnostic software, designed to serve as the advanced management platform for 3500 series machinery protection systems. Building on the capabilities of basic configuration tools, it provides engineers and maintenance teams with comprehensive control over system setup, real-time diagnostics, and in-depth data analysis—seamlessly integrating with the 3500/05 rack interface module and all connected 3500 series components.

As the centralized software hub, 170180-01-00 enables users to configure complex system architectures, monitor module health, and analyze machinery performance trends with greater precision. It acts as a critical link between the 3500/05 (the hardware backbone) and operational decision-makers, translating raw data from modules like the 3500/42 176449-02 (transducer signal conditioner) and 3500/60 163179-01 (relay module) into actionable insights. Whether deployed in power generation, oil and gas, or manufacturing, this software enhances the efficiency of 3500 series systems by streamlining configuration workflows, accelerating troubleshooting, and enabling predictive maintenance strategies.

Core advantages and technical highlights

Advanced configuration management: 170180-01-00 offers a sophisticated interface for configuring complex 3500 series systems, far beyond basic setup tools. It allows users to create and save multi-rack configurations, with the ability to replicate settings across multiple 3500/05 modules—saving time in large-scale installations. For the 3500/42 176449-02, it provides granular control over thermocouple types, filtering parameters, and signal scaling, with built-in validation to prevent configuration errors that could compromise data accuracy.

Real-time diagnostic dashboard: The software features a customizable diagnostic dashboard that displays the health status of all connected modules, including the 3500/05 and its associated components. It highlights issues such as communication failures, calibration drift in the 3500/42 176449-02, or relay malfunctions in the 3500/60 163179-01, with detailed troubleshooting guides embedded directly in the interface. This proactive diagnostics capability reduces mean time to repair (MTTR) by pinpointing root causes quickly.

High-resolution data logging and analysis: 170180-01-00 captures and stores high-resolution data from 3500 series modules at user-defined intervals (down to 1ms), enabling detailed trend analysis. It automatically synchronizes time-stamped data from the 3500/42 176449-02 (e.g., temperature, pressure) with vibration and speed data from other modules, using the 3500/05 as the synchronization reference. Advanced analytics tools, including FFT analysis and spectral trending, help identify early signs of machinery degradation, such as bearing wear or misalignment.

Integration with enterprise systems: The software supports APIs for seamless integration with enterprise systems such as CMMS (Computerized Maintenance Management Systems) and ERP platforms. It can automatically export alarm data from the 3500/05 and performance reports to these systems, ensuring that maintenance teams have real-time access to critical information. This integration bridges the gap between machinery protection and broader operational management, enhancing workflow efficiency.

Typical application scenarios

In a nuclear power plant, 170180-01-00 is used to manage multiple 3500 series racks monitoring turbine generators. Engineers use the software to configure redundant 3500/05 modules and set up complex alarm logic for the 3500/42 176449-02 (monitoring coolant temperatures) and vibration modules. The real-time diagnostic dashboard alerts operators to minor calibration drift in a 3500/42 176449-02 channel, allowing for scheduled recalibration during a planned outage—avoiding unplanned downtime. High-resolution data logs are analyzed to identify subtle vibration trends, enabling predictive maintenance of turbine bearings.

Within an offshore oil platform’s compressor station, the software connects to 3500/05 modules across multiple racks, aggregating data from 3500/42 176449-02 (measuring discharge pressure and temperature) and 3500/60 163179-01 (relay status). It generates compliance reports for regulatory bodies, detailing pressure fluctuations and safety system activations, with data automatically timestamped via the 3500/05’s clock synchronization. The software’s enterprise integration capabilities push critical alarms to the platform’s CMMS, triggering work orders for maintenance teams.

In a large manufacturing facility with distributed production lines, 170180-01-00 manages over 50 3500 series racks, each controlled by a 3500/05 module. It allows engineers to configure standardized settings for 3500/42 176449-02 modules across all lines, ensuring consistency in temperature and pressure monitoring. The software’s trend analysis tools identify a correlation between motor temperature spikes (from 3500/42 176449-02) and production quality issues, leading to adjustments in operating parameters that reduce scrap rates by 15%.

BENTLY 170180-01-00

Relationship with 3500/05 and other modules

170180-01-00 acts as the software counterpart to the 3500/05 hardware hub, forming the core of the 3500 series management ecosystem:

With 3500/05: The software communicates directly with the 3500/05 via Ethernet, using it as the gateway to configure and monitor all modules in the rack. It uploads complex system configurations to the 3500/05’s non-volatile memory and retrieves real-time data, including aggregated alarms and module statuses. 170180-01-00 also synchronizes its clock with the 3500/05 to ensure time-stamped data accuracy across the system.

With 3500/42 176449-02: The software provides advanced configuration options for the signal conditioner, such as custom thermocouple linearization curves and dynamic filtering profiles. It retrieves high-resolution conditioned data from the 3500/42 176449-02 via the 3500/05, storing it for trend analysis and correlation with other parameters (e.g., vibration, speed).

With 3500/60 163179-01: 170180-01-00 configures relay logic for the module, including latching conditions and interlock settings, and monitors relay activation status via the 3500/05. It logs all relay actions with time stamps and associated sensor data, enabling post-event analysis of shutdowns or alarms.

With 3500/50 133388-02: The software allows users to design custom display screens for the local display module, defining which parameters from the 3500/42 176449-02 and other modules are shown. It also retrieves operator actions logged by the 3500/50 133388-02 (e.g., manual overrides) for audit trails.

Related model recommendations

170180-02-00: A premium variant with AI-powered predictive analytics and cloud integration capabilities for large enterprise deployments.

3500/05: Rack interface module that serves as the hardware gateway for 170180-01-00 to communicate with 3500 series components.

3500/42 176449-02: Advanced transducer signal conditioner whose data is analyzed and configured via 170180-01-00.

3500/60 163179-01: Relay module whose logic is configured and monitored by the software.

3500/50 133388-02: Display module that visualizes data configured through 170180-01-00.

3500/93: Communication gateway that extends 170180-01-00’s reach to remote 3500 racks via industrial networks.

149992-01: High-performance Ethernet cable for reliable communication between 170180-01-00 workstations and 3500/05 modules.

Installation, configuration and maintenance instructions

Installation steps: Install 170180-01-00 on a compatible Windows workstation meeting the minimum hardware requirements. Run the installation wizard, accept the license agreement, and select the installation directory. After installation, activate the software using the provided license key. Configure firewall settings to allow inbound/outbound communication on TCP port 502 (Modbus) and port 443 (HTTPS) for secure communication with 3500/05 modules.

Initial configuration: Launch the software and use the “Rack Discovery” tool to scan the network for 3500/05 modules. Add detected racks to the software dashboard, then import or create system configurations. For each rack, configure 3500/05 network settings (IP address, subnet mask) and define communication parameters. Set up module-specific configurations for the 3500/42 176449-02 (e.g., thermocouple types, input ranges) and 3500/60 163179-01 (relay logic), using templates for consistency across multiple racks.

Data logging setup: Configure data logging parameters, including sample rate (1ms to 1 minute), storage location, and retention period. Define key parameters to monitor from the 3500/42 176449-02 and other modules, and set up automatic data backup to a network server. Enable real-time data streaming to the dashboard for critical parameters, with color-coded indicators for alarm thresholds.

Maintenance suggestions: Schedule bi-annual software updates via the built-in update manager to ensure compatibility with the latest 3500/05 firmware and new 3500 series modules. Perform monthly backups of configuration files and historical data to prevent loss. Calibrate software diagnostic tools annually using reference data from a known good system to ensure accuracy. If communication with 3500/05 modules is lost, verify network connectivity, check IP address settings, and confirm that the 3500/05 firmware version is compatible with the software release.

Service and guarantee commitment

170180-01-00 comes with a 18-month warranty covering software functionality issues, including configuration errors and communication failures with 3500/05 modules. During this period, users receive free technical support, software updates, and access to online training resources. Our 24/7 support team specializes in troubleshooting integration with 3500 series hardware, including the 3500/42 176449-02 and 3500/60 163179-01.

Optional premium support plans (1-5 years) include priority technical assistance, on-site training, and custom report development. Backed by BENTLY NEVADA’s expertise in industrial software and machinery protection, 170180-01-00 is guaranteed to deliver reliable performance, maximizing the functionality and lifespan of your 3500 series system.
