Description
Detailed parameter table
| Parameter name | Parameter value |
| Product model | 1701/10 24В |
| Manufacturer | BENTLY NEVADA |
| Product category | Signal conditioner |
| Electrical performance | 24V DC power supply; 10-channel input; 4-20mA output per channel; Power consumption: 12W max |
| Physical size | Width: 100mm, Height: 160mm, Depth: 220mm |
| Interface type | Terminal blocks for sensor inputs, power, and outputs; DIN rail mounting clips |
| Communication protocol | Analog signal transmission (4-20mA); Compatible with standard industrial control systems |
| Environmental requirements | Operating temperature: -20°C to +60°C; Humidity: 10% – 90%, non-condensing; IP20 protection rating |
| Installation method | DIN rail mounting; Suitable for standard 35mm DIN rails in control cabinets |
| Performance indicators | Signal linearity: ±0.1% FS; Noise rejection: >80dB at 50/60Hz; Response time: <50ms |
BENTLY 1701/10 24В
Product introduction
The BENTLY NEVADA 1701/10 24В is a compact, high-performance signal conditioner designed to process and standardize sensor signals in industrial monitoring systems. As a versatile component in BENTLY NEVADA’s portfolio, it bridges the gap between raw sensor outputs and control systems, ensuring accurate data transmission in various industrial environments.
This 10-channel module excels at conditioning signals from vibration, temperature, and pressure sensors, converting them into standardized 4-20mA outputs. The BENTLY NEVADA 1701/10 24В is ideal for applications where sensor signals require amplification, filtering, or isolation before reaching monitoring or control systems. In automation setups, it enhances signal integrity, enabling reliable measurement and control of critical machinery parameters.
Core advantages and technical highlights
Multi-channel efficiency: With 10 independent channels, the 1701/10 24В provides centralized signal conditioning for multiple sensors, reducing cabinet space requirements compared to single-channel devices. This makes it perfect for monitoring systems with numerous measurement points, such as production lines with multiple motors or pumps, where space in control cabinets is limited.
Superior noise rejection: The module’s advanced filtering technology achieves >80dB noise rejection at 50/60Hz, ensuring accurate signal processing even in electrically noisy environments. This capability is crucial in factories with heavy machinery or power distribution systems, where electromagnetic interference can corrupt sensor signals and lead to incorrect measurements.
High precision conversion: Boasting ±0.1% full-scale linearity, the 1701/10 24В maintains signal accuracy across the entire measurement range. This precision ensures that subtle changes in sensor inputs—such as minor temperature fluctuations or vibration increases—are accurately reflected in the output signals, providing reliable data for process control and condition monitoring.
Flexible integration: The 1701/10 24В features universal input compatibility, accepting signals from various sensors including thermocouples, RTDs, strain gauges, and accelerometers. Its standardized 4-20mA outputs seamlessly integrate with PLCs, DCS, and SCADA systems, making it a versatile solution for retrofitting existing systems or building new monitoring setups.
Typical application scenarios
In water treatment plants, the 1701/10 24В conditions signals from pressure transducers and flow meters across multiple filtration stages. It processes these signals to provide consistent 4-20mA outputs to the plant’s SCADA system, enabling precise control of pump speeds and valve positions. Its noise rejection capabilities ensure accurate measurements despite the electrical noise from water pumps and aeration systems.
Within food and beverage production facilities, the 1701/10 24В monitors temperature and pressure in pasteurization units. It conditions signals from RTDs and pressure sensors, ensuring accurate data for maintaining process parameters within strict regulatory limits. The module’s compact design allows installation in the tight spaces of hygienic control cabinets, common in food processing environments.
In HVAC systems for large commercial buildings, the 1701/10 24В processes signals from temperature, humidity, and air flow sensors. It provides standardized outputs to the building management system, enabling efficient control of heating, cooling, and ventilation systems. Its reliable performance ensures comfortable indoor environments while optimizing energy consumption.
BENTLY 1701/10 24В
Related model recommendations
1701/04 24В: A 4-channel version of the 1701/10 24В, suitable for smaller monitoring setups with fewer sensors, offering the same precision in a more compact form.
330730-080-00-00: An accelerometer that pairs with the 1701/10 24В, providing vibration signals that the module conditions for accurate measurement.
3500/33-01-00 149986-01: A vibration monitor module that can work with the 1701/10 24В in complex monitoring systems, where additional processing of conditioned signals is required.
149992-01: A shielded cable assembly used to connect sensors to the 1701/10 24В, minimizing signal interference in noisy environments.
1702/10 24В: An upgraded version of the 1701/10 24В with digital communication capabilities (Modbus RTU), enabling remote configuration and data logging.
3500/15: A power supply module that can provide stable 24V DC to the 1701/10 24В in larger monitoring systems with multiple components.
1701/10 12В: A 12V DC variant of the 1701/10 24В, designed for applications where lower voltage power supplies are available.
Installation, commissioning and maintenance instructions
Installation preparation: Before installing the 1701/10 24В, ensure the control cabinet is powered off and properly grounded. Check that the DIN rail is securely mounted and level. Required tools include a screwdriver, wire strippers, and a torque wrench (set to 0.5Nm for terminal blocks). Verify that the installation environment meets temperature and humidity specifications. Mount the module on the DIN rail using the integrated clips, ensuring a secure fit to prevent movement during operation.
Maintenance suggestions: Perform quarterly visual inspections of the 1701/10 24В to check for loose connections, dust accumulation, or signs of overheating. Clean the module surface with a dry, lint-free cloth. Calibrate the module annually using BENTLY NEVADA’s calibration tools to maintain ±0.1% linearity. If output signals are unstable, check sensor wiring and input connections for corrosion or damage. Replace damaged components with genuine BENTLY NEVADA parts only. Keep a maintenance log recording calibration results, wiring changes, and any performance issues to track the module’s long-term reliability.
Service and guarantee commitment
The 1701/10 24В comes with a 12-month warranty covering manufacturing defects. During this period, we offer free repair or replacement for faulty units. Our technical support team provides expert assistance for installation, configuration, and troubleshooting via phone and email. We supply detailed user manuals and calibration guides to ensure optimal performance. For critical applications, optional extended warranties (up to 3 years) are available, including priority technical support and on-site assistance if needed. Backed by BENTLY NEVADA’s reputation for quality, the 1701/10 24В is guaranteed to deliver reliable signal conditioning, ensuring the accuracy and integrity of your industrial monitoring systems.
