Description
Bently Nevada 136188-01 – Technical Product Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | Bently Nevada 136188-01 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Category | Proximity Transducer Extension Cable |
| Cable Type | Triaxial, shielded |
| Length | 3 meters (9.8 ft) |
| Connector A | Male, military-style threaded |
| Connector B | Female, military-style threaded |
| Temperature Range | -40°C to +150°C |
| Insulation Material | PTFE (Teflon) |
| Shielding | Dual shielding (foil + braid) |
| Outer Jacket | PVC, oil-resistant |
| Certifications | API 670, ATEX (optional) |
BENTLY 136188-01
Product Introduction
The Bently Nevada 136188-01 is a premium-quality triaxial extension cable designed specifically for Bently Nevada’s 3300 XL and 3500 series proximity transducer systems. This 3-meter cable provides the critical link between proximity probes and monitoring equipment in demanding industrial environments.
Engineered to maintain signal integrity, the 136188-01 features military-grade connectors and PTFE insulation that ensure reliable performance in extreme temperature conditions and electrically noisy environments. Its robust construction meets the stringent requirements of power generation, oil & gas, and heavy industrial applications.
Core Advantages and Technical Highlights
Superior Signal Transmission:
Triaxial design with dual shielding provides exceptional EMI/RFI protection
PTFE insulation maintains stable electrical characteristics across the full temperature range
Precision-machined connectors ensure minimal signal loss
100% tested for proper capacitance and resistance values
Industrial Durability:
-40°C to +150°C operating range for extreme environments
Oil-resistant PVC outer jacket withstands harsh refinery conditions
Military-style threaded connectors resist vibration loosening
Strain relief features at both connection points
System Compatibility:
Direct replacement for OEM Bently Nevada cables
Seamless integration with 3300 XL and 3500 monitoring systems
API 670 compliant for critical machinery applications
ATEX option available for hazardous area installations
Installation Advantages:
Optimal 3m length for common machine configurations
Flexible yet durable construction for easy routing
Color-coded connectors for foolproof installation
Pre-tested dielectric strength (1500V AC for 1 minute)
Typical Application Scenarios
Power Generation:
Steam turbine shaft vibration monitoring
Generator air gap measurement systems
Gas turbine bearing vibration monitoring
Oil & Gas:
Centrifugal compressor shaft position monitoring
Offshore platform machinery protection systems
Pipeline compressor vibration monitoring
Petrochemical:
Turbine-driven pump vibration systems
FCC unit expander monitoring
Critical reactor feed compressor protection
Heavy Industry:
Rolling mill drive train monitoring
Large motor vibration systems
Mine hoist machinery protection
BENTLY 136188-01
Related Model Recommendations
Bently Nevada 136188-02: 5-meter version
Bently Nevada 136188-03: 7-meter version
Bently Nevada 330130-040-00-00: Field-installable connector kit
Bently Nevada 330180-91-05: Complete proximity probe system
Bently Nevada 3500/42M: Vibration monitor module
Bently Nevada 3300/20: Proximitor power supply
Installation and Commissioning
Installation Preparation:
Verify proper cable routing path
Ensure minimum bend radius of 5x cable diameter
Prepare appropriate tools for connector tightening
Check for proper grounding of monitoring system
Commissioning Steps:
Inspect connectors for damage before installation
Hand-tighten connectors, then torque to 7-9 Nm
Install cable supports every 1-1.5 meters
Perform continuity and insulation resistance tests
Document cable installation in maintenance records
Maintenance Recommendations:
Annual dielectric strength testing
Regular inspection for jacket damage
Monitoring of vibration signal quality
Connector cleaning during planned outages
Replacement at first signs of insulation breakdown
Service and Guarantee Commitment
Baker Hughes provides:
24-month warranty against manufacturing defects
Global technical support network
NIST-traceable replacement cables
On-site troubleshooting assistance
Repair and recalibration services
The Bently Nevada 136188-01 is backed by Baker Hughes’ Machine Health Center with lifetime product support. All cables are 100% tested before shipment and include complete documentation of electrical characteristics. Custom lengths and configurations are available for special applications.
