Description
Bently Nevada 125800-01 Proximity Transducer System
Technical Specifications
| Parameter | Specification |
| Model Number | Bently Nevada 125800-01 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Type | Proximity Transducer System |
| Measurement Range | 0.08 to 0.236 in (2 to 6 mm) |
| Output Signal | -2 to -18 VDC |
| Frequency Response | 0 to 10 kHz |
| Temperature Range | -40°C to +120°C |
| Power Requirement | 18-30 VDC, 10 mA typical |
| Probe Diameter | 8 mm |
| Cable Length | 20 ft (6 m) standard |
| Sensitivity | 200 mV/mil (7.87 V/mm) |
| Environmental Rating | IP67 |
| Compliance | API 670, ISO 10816 |
BENTLY 125800-01
Product Overview
The Bently Nevada 125800-01 is a high-precision proximity transducer system designed for critical machinery monitoring in industrial applications. This complete system includes a durable probe, extension cable, and driver to provide accurate measurement of shaft vibration and position.
Engineered for reliability in harsh environments, the Bently Nevada 125800-01 features robust construction with stainless steel components and high-temperature rated cables. Its compact design allows for installation in space-constrained locations while maintaining excellent measurement accuracy.
Key Features
High Accuracy Measurement: Provides precise vibration and position data with 200 mV/mil sensitivity
Wide Temperature Range: Operates reliably from -40°C to +120°C
Durable Construction: Stainless steel probe housing resists corrosion and mechanical stress
Flexible Installation: Standard 20 ft cable length with options for custom lengths
Industry Compliance: Meets API 670 and ISO 10816 standards for machinery protection
Typical Applications
Turbine and compressor monitoring in power generation
Critical pump vibration measurement in oil & gas facilities
Motor and gearbox protection in heavy industry
Rotating equipment monitoring in petrochemical plants
BENTLY 125800-01
Related Products
Bently Nevada 125800-02: Extended range version (0.08 to 0.5 in)
Bently Nevada 125800-03: Hazardous area certified variant
Bently Nevada 3300 XL 8mm: Proximity probe with integrated electronics
Bently Nevada 3500/42: Vibration monitor for system integration
Installation & Maintenance
Requires proper grounding and shielded cables
Mount in vibration-free locations within specified temperature limits
Regular inspection of cables and connections recommended
Annual calibration advised for optimal performance
Warranty & Support
24-month manufacturer warranty
Global technical support network
On-site service options available
Comprehensive documentation and training resources
