Description
Detailed parameter table
| Parameter name | Parameter value |
| Product model | 3500/60 163179-01 |
| Manufacturer | Bently Nevada |
| Product category | Machinery Protection System Display Interface Module |
| Display type | 8.4-inch color LCD (800×600 resolution) |
| User interface | Touchscreen with membrane keypad backup |
| Data visualization | Real-time trends, alarm lists, diagnostic plots, digital readouts |
| Alarm capabilities | Multi-level visual/audio alerts, configurable priority levels |
| Communication ports | 1× Ethernet (10/100BASE-T), 3500 system backplane interface |
| Supported protocols | Bently Nevada proprietary protocol, compatible with 3500/40M protocols |
| Operating voltage | 5 VDC, ±15 VDC (from 3500 system power supply) |
| Power consumption | 12 W typical, 15 W maximum |
| Operating temperature | 0°C to +55°C (32°F to +131°F) |
| Form factor | 3500 system rack mount (2 slot width) |
| Dimensions | 266 mm (H) × 72 mm (W) × 229 mm (D) (10.5″ × 2.8″ × 9.0″) |
| Compatibility | 3500/40M modules, 176449-01 cables, all 3500 monitoring modules |
| Certification | UL, CE, RoHS compliant, IEC 61010-1 approved |
BENTLY 3500/60 163179-01
Product introduction
The 3500/60 163179-01 from Bently Nevada is a sophisticated display interface module designed as the primary operator interface for 3500 Machinery Protection Systems. This rack-mount display serves as the visual command center where critical machinery health data is transformed into actionable insights, providing operators with immediate access to real-time measurements, historical trends, and alarm statuses from across the protection system. Bently Nevada’s 3500/60 163179-01 acts as the human-machine interface (HMI) bridge, translating complex sensor data—transmitted through components like the 3500/40M communication module and 176449-01 cables—into intuitive visualizations that drive operational decisions.
Bently Nevada’s 3500/60 163179-01 addresses the critical need for clear, immediate machinery health information in industrial environments. Its high-resolution display and user-friendly interface enable operators to quickly identify abnormal conditions, track performance trends, and access diagnostic information without specialized training. By consolidating data from connected sensors and monitors, this module ensures that critical alerts and performance metrics are always visible, supporting timely interventions that prevent machinery damage and unplanned downtime across various industrial applications.
Core advantages and technical highlights
Intuitive data visualization: The 3500/60 163179-01 features an 8.4-inch color LCD display with 800×600 resolution that presents machinery data in multiple formats—from real-time digital readouts to historical trend graphs and alarm annunciators. This versatility allows operators to quickly transition between overview monitoring and detailed diagnostic analysis, with customizable screen layouts that can be tailored to specific machinery types or operational preferences.
Dual interface redundancy: Equipped with both touchscreen and membrane keypad controls, the 3500/60 163179-01 ensures reliable operation even in harsh industrial environments where touchscreen functionality might be temporarily impaired. This dual interface design guarantees access to critical system functions regardless of environmental conditions, enhancing operational reliability.
Seamless system integration: The module connects directly to the 3500 system backplane and via Ethernet to 3500/40M communication modules, enabling it to aggregate data from all system components. This integration ensures that measurements from sensors connected via 176449-01 cables appear in real-time alongside data from other monitoring points, providing a comprehensive view of machinery health status.
Advanced alarm management: The 3500/60 163179-01 features multi-level alarm capabilities with visual and audible indicators that prioritize alerts by severity. Alarms include detailed context such as affected parameter, timestamp, and current value, helping operators quickly distinguish between routine notifications and critical conditions requiring immediate action. The system logs all alarm events for compliance and post-incident analysis.
Typical application scenarios
In power generation control rooms, the 3500/60 163179-01 serves as the primary monitoring interface for turbine and generator protection systems. It displays real-time vibration data from sensors connected via 176449-01 cables, alongside temperature and position measurements, with data aggregated through 3500/40M modules. Operators use its trend analysis tools to compare current performance against historical baselines, identifying subtle degradation patterns during normal operation and receiving immediate alerts when parameters approach critical thresholds.
Oil refineries utilize the 3500/60 163179-01 in compressor control stations, where it provides a centralized view of multiple rotating machinery assets. The module’s customizable screens display vibration spectra, bearing condition indicators, and process parameters for each compressor unit, with color-coded status indicators highlighting any equipment requiring attention. Its integration with 3500/40M modules ensures data consistency between local displays and remote monitoring systems.
Manufacturing facilities deploy the 3500/60 163179-01 on plant floors near critical production machinery, providing operators with immediate visibility of equipment health. The module displays vibration, temperature, and operational data from motors, pumps, and gearboxes, with simplified screens for quick status checks and detailed diagnostic views for maintenance personnel. Its rugged design withstands the environmental conditions of manufacturing environments while providing essential machinery health information at the point of operation.
BENTLY 3500/60 163179-01
Related model recommendations
3500/40M: Communication module that provides data to the 3500/60 163179-01 from distributed sensors.
176449-01: Seismic sensor cable whose measurements are displayed on the 3500/60 163179-01.
3500/70M: Reciprocating machinery monitor whose data is visualized by the 3500/60 163179-01.
3500/22M: Power supply module that provides operating power to the 3500/60 163179-01.
3500/15: Relay module whose status is monitored and displayed by the 3500/60 163179-01.
125720-01: Temperature transmitter whose measurements appear on the 3500/60 163179-01 display.
3500/34: Redundant communication gateway that enhances data flow to the 3500/60 163179-01.
Installation, commissioning and maintenance instructions
Installation preparation: Before installing the 3500/60 163179-01, verify compatibility with the target 3500/20 rack and ensure system firmware supports the display module. Confirm the system power supply can accommodate the additional load. Gather required tools including a torque screwdriver, Ethernet cable tester, and laptop with 3500 configuration software. Inspect the module for shipping damage, particularly checking the display screen, touch interface, and backplane connectors. Plan cable routing for Ethernet connections to 3500/40M modules.
Maintenance suggestions: Include the 3500/60 163179-01 in monthly system inspections, verifying display clarity, touchscreen responsiveness, and keypad functionality. Check Ethernet connectivity and data synchronization with the 3500/40M and other system components. Clean the display screen regularly with a soft, lint-free cloth and approved cleaning solution—avoid harsh chemicals or abrasive materials. Back up configuration settings quarterly to preserve custom screen layouts. During scheduled maintenance, verify firmware compatibility with other system components and update if necessary to ensure optimal performance.
Service and guarantee commitment
Bently Nevada provides the 3500/60 163179-01 with a 36-month warranty covering manufacturing defects and performance issues under normal operating conditions, including display functionality, touch interface operation, and communication capabilities. Our technical support team offers expert guidance on configuration, screen customization, and integration with 3500/40M modules, 176449-01 cables, and other 3500 system components.
We offer specialized training on display module operation, alarm management, and advanced visualization features specific to the 3500/60 163179-01. Beyond the warranty period, our service agreements include technical support, configuration assistance, and expedited replacement services to minimize downtime. Bently Nevada’s commitment to quality ensures reliable performance throughout its operational lifecycle, backed by our global network of service professionals.
