BENTLY 3500/15-05-05-00

Description

Detailed parameter table

BENTLY 3500/15-05-05-00

Product introduction

The 3500/15-05-05-00 from Bently Nevada is a reliable power supply module designed as a foundational component of the 3500 Machinery Protection System, delivering stable and regulated power to connected monitoring modules in industrial environments. This 2-slot rack-mounted module represents a standard-duty power solution within Bently’s lineup, offering balanced performance characteristics suitable for general-purpose 3500 system configurations where extreme environmental conditions or maximum power capacity are not primary requirements.

Unlike specialized high-power variants like the 3500/15 106M1079-0, 3500/15-05-05-00 is optimized for cost-effective operation in standard industrial settings, providing the essential voltage rails required by 3500 monitoring components without the extended features needed for harsh environments. It maintains seamless integration with system management modules like 3500/92 136188-02, enabling basic power status monitoring while supporting the core functionality of process monitors, vibration sensors, and communication interfaces.

In industrial monitoring setups, 3500/15-05-05-00 plays a critical role in ensuring consistent power delivery to 3500 system components, where voltage stability directly impacts measurement accuracy and alarm reliability. Its robust design and essential protection features make it suitable for deployment in controlled industrial environments across power generation, manufacturing, and medium-duty oil and gas applications.

Core advantages and technical highlights

Balanced power delivery: 3500/15-05-05-00 provides a maximum output power of 120 W, with well-matched current ratings for typical 3500 system requirements (10 A for 5 VDC, 3.5 A for ±15 VDC). This balanced power distribution supports standard system configurations with multiple modules, including communication interfaces and process monitors, without the higher capacity features of premium models like 3500/15 106M1079-0. This makes it an economical choice for applications with moderate power demands.

Reliable voltage regulation: The module maintains precise voltage regulation across all output rails, ensuring stable operation of sensitive monitoring equipment like vibration analyzers and temperature sensors. This regulation is critical for maintaining measurement accuracy in 3500 systems, where small voltage fluctuations could introduce errors in vibration or process variable readings. The module’s design prioritizes consistent performance under typical operating conditions.

Essential protection features: 3500/15-05-05-00 incorporates fundamental safeguards including overvoltage, overcurrent, and short circuit protection, preventing damage to both the power supply and connected modules during common electrical anomalies. While it lacks some advanced protections of higher-tier models, these essential features provide adequate protection for standard industrial environments, balancing safety with cost-effectiveness.

Basic system integration: The module communicates key power status data to the 3500/92 136188-02 rack interface via the 3500 backplane, providing visibility into primary voltage levels and critical fault conditions. This integration enables basic centralized monitoring of power system health and automated alerts for major issues, supporting essential system management without the advanced diagnostics of premium power supply models.

Typical application scenarios

In mid-sized power generation facilities with standard turbine monitoring systems, 3500/15-05-05-00 modules provide reliable power to 3500 racks containing vibration monitors, process parameter modules, and basic communication interfaces. The power supply’s 120 W capacity supports these configurations adequately, while its AC-only input works well with the stable electrical infrastructure typically found in power plants. Integration with 3500/92 136188-02 enables basic power status monitoring, helping maintenance teams track system health.

Manufacturing facilities utilize 3500/15-05-05-00 to power machinery protection systems on production lines, where the module delivers consistent power to vibration monitors and temperature sensors tracking equipment health. The module’s reliable operation in controlled factory environments (0°C to +60°C) ensures uninterrupted monitoring of critical production equipment, while its essential protection features prevent damage from electrical anomalies common in manufacturing electrical systems.

Medium-duty oil and gas facilities employ 3500/15-05-05-00 in non-hazardous areas to power pump and compressor monitoring systems. The module provides stable power to 3500 racks containing pressure transducers, vibration sensors, and local communication modules, supporting basic machinery protection functionality. Its cost-effective design makes it suitable for applications where extreme temperature tolerance or maximum power capacity are not required.

BENTLY 3500/15-05-05-00

Related model recommendations

3500/92 136188-02: Rack interface module that monitors this power supply’s status.

3500/33 149986-01: Process variable monitor powered by this supply module.

3500/40M 176449-01: Vibration monitor requiring stable power from this unit.

3500/60 163179-01: Display module receiving regulated power from this supply.

3500/05-01-02-00-00-01: Serial communication module powered by this unit.

3500/53 133388-01: Ethernet communication module integrated with this supply.

177230-01-01-05: Extension cable supporting sensors in systems powered by this module.

3500/15 106M1079-0: Higher-capacity power supply for expanded system configurations.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing 3500/15-05-05-00, verify the 3500 rack has two adjacent slots available and that the input power source matches the module’s AC-only requirements (85-264 VAC, 50/60 Hz). Ensure proper ventilation around the power supply to maintain operating temperatures within the 0°C to +60°C range. Use appropriately sized input wiring (14 AWG recommended) and secure connections to prevent voltage drops. Install a dedicated circuit breaker (5 A recommended) to protect the supply during operation and maintenance.

Maintenance suggestions: Include 3500/15-05-05-00 in quarterly electrical system inspections, verifying all output voltages are within specified tolerances using a calibrated multimeter. Review power status data in the 3500/92 136188-02 interface to monitor for voltage fluctuations or fault conditions. Check for loose connections, unusual noises, or excessive heat during operation. Inspect cooling vents for dust accumulation monthly, cleaning with compressed air if necessary. Coordinate any power supply replacement with scheduled system shutdowns, as it powers all critical monitoring components in the rack.

Service and guarantee commitment

Bently Nevada provides the 3500/15-05-05-00 with a 36-month warranty covering manufacturing defects and performance issues under normal operating conditions, including output regulation, protection functionality, and reliability when powering compatible 3500 series components like 3500/92 136188-02 and 3500/33 149986-01. Our technical support team offers guidance on power system design, basic troubleshooting, and integration with standard 3500 configurations.

We offer training on 3500 power system basics, including proper installation practices and maintenance procedures specific to this standard-duty power supply module. Beyond the warranty period, our service agreements include performance verification, technical support, and replacement services to minimize system downtime. Bently Nevada’s commitment to quality ensures reliable power delivery throughout the module’s operational lifecycle, backed by our global network of service professionals dedicated to maintaining the integrity of your machinery protection system.
