BENTLY 330901-05-32-05-02-00

Product introduction

The 330901-05-32-05-02-00 from Bently Nevada is a high-performance piezoelectric accelerometer sensor assembly designed for precision vibration monitoring in industrial machinery applications. As a key component of the 3300 XL monitoring system, this accelerometer captures dynamic vibration signals across a broad frequency range, providing critical data for assessing machinery health and detecting early-stage faults. Bently Nevada’s 330901-05-32-05-02-00 is engineered to deliver reliable performance in harsh industrial environments, complementing proximity sensor systems like the 330100-90-01 by monitoring vibration patterns that indicate bearing defects, imbalance, and misalignment in rotating equipment.

Bently Nevada’s 330901-05-32-05-02-00 addresses the need for accurate vibration measurement in applications where traditional proximity sensors may not be feasible. Its integrated 5-meter cable ensures seamless signal transmission to monitoring systems, maintaining data integrity from sensor to analyzer. This accelerometer plays a vital role in comprehensive machinery protection strategies, working alongside components like the 330104-00-05-10-02-00 extension cable to form a complete vibration monitoring solution that delivers actionable insights to operators and control systems.

Core advantages and technical highlights

Broad measurement capabilities: The 330901-05-32-05-02-00 offers a ±50 g measurement range and 0.5 Hz to 10,000 Hz frequency response, enabling it to capture both low-frequency structural vibration and high-frequency bearing fault signatures. This versatility makes it suitable for monitoring diverse machinery types, from slow-speed pumps to high-speed turbines, providing comprehensive vibration data that complements proximity sensor measurements.

Extreme environment durability: Constructed with 316L stainless steel housing and an IP68 protection rating, the 330901-05-32-05-02-00 withstands harsh industrial conditions including exposure to water, dust, chemicals, and extreme temperatures (-55°C to +121°C). This rugged design ensures reliable operation in offshore platforms, chemical plants, and other demanding environments where sensor failure could compromise machinery protection.

Integrated cable design: The accelerometer features an integral 5-meter shielded cable that minimizes signal loss and electromagnetic interference (EMI) during transmission—similar to the 330104-00-05-10-02-00 extension cable’s design but optimized for accelerometer signals. This integrated approach reduces connection points, minimizing potential failure points and ensuring consistent signal quality from sensor to monitoring equipment.

System compatibility: Designed for seamless integration with 3300 XL monitoring systems, the 330901-05-32-05-02-00 works with 133819-01 signal conditioners and 1900/27 controllers to form a complete vibration monitoring solution. Its 100 mV/g sensitivity ensures compatibility with standard monitoring equipment, while its differential output provides additional noise immunity in electrically noisy environments.

Typical application scenarios

In power generation facilities, the 330901-05-32-05-02-00 is installed on turbine bearings, generator end bells, and auxiliary equipment to monitor vibration levels that indicate mechanical degradation. Its broad frequency response captures both low-frequency rotor vibration and high-frequency bearing defects, providing early warning of issues that could lead to unplanned outages. The accelerometer’s high-temperature rating allows installation in turbine enclosures, where it works alongside 330100-90-01 proximity sensors to provide comprehensive machinery health data.

Oil and gas processing plants utilize the 330901-05-32-05-02-00 on reciprocating and centrifugal compressors, where its rugged construction withstands hydrocarbon exposure and vibration. The accelerometer monitors cylinder vibration, gear mesh frequencies, and bearing condition, helping operators detect valve issues, imbalance, and misalignment before they cause unscheduled downtime. Its IP68 rating makes it suitable for washdown environments and offshore installations where moisture exposure is common.

Manufacturing facilities deploy the 330901-05-32-05-02-00 on production line motors, pumps, and gearboxes to support predictive maintenance programs. The accelerometer’s ability to capture high-frequency vibration allows early detection of bearing wear and lubrication issues, while its integrated cable simplifies installation in tight machine spaces. Data from the 330901-05-32-05-02-00 is transmitted to 1900/55-0Z-01-01-01 HMIs, providing operators with real-time vibration trends and alerting them to developing problems.

BENTLY 330901-05-32-05-02-00

Related model recommendations

133819-01 (Bently Nevada): Signal conditioner that processes output from the 330901-05-32-05-02-00.

330104-00-05-10-02-00 (Bently Nevada): Extension cable for system expansion with the 330901-05-32-05-02-00.

1900/27 (Bently Nevada): Controller that analyzes vibration data from the 330901-05-32-05-02-00.

330130-085-00-00 (Bently Nevada): Calibration tool compatible with systems using the 330901-05-32-05-02-00.

330901-05-32-10-02-00 (Bently Nevada): 10-meter variant of the 330901-05-32-05-02-00 for longer cable runs.

330902-05-32-05-02-00 (Bently Nevada): Triaxial version of the 330901-05-32-05-02-00 for 3D vibration measurement.

60M100-00 (Bently Nevada): Display unit that visualizes data from the 330901-05-32-05-02-00.

330100-90-01 (Bently Nevada): Proximity sensor housing that complements the 330901-05-32-05-02-00 in comprehensive systems.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the 330901-05-32-05-02-00, select a mounting location on the machinery that provides a direct path to vibration sources (typically bearing housings). Ensure the mounting surface is clean, flat, and free of paint or corrosion. Required tools include a torque wrench for the 1/4-28 UNF stud, thread-locking compound, and a calibration shaker for verification. Inspect the accelerometer and cable for damage, checking for kinks in the cable, connector issues, or housing damage that could affect performance.

Maintenance suggestions: To ensure reliable operation of the 330901-05-32-05-02-00, conduct quarterly visual inspections to verify secure mounting and check for cable damage or corrosion. During scheduled shutdowns, verify calibration using a portable vibration calibrator, comparing readings to established baselines. Inspect cable routing to ensure it isn’t subjected to excessive bending or mechanical stress that could exceed its flex life. Clean the sensor housing with a soft cloth and mild detergent if necessary, avoiding abrasive materials that could damage the housing. If vibration data appears 异常，check mounting torque first before suspecting sensor failure.

Service and guarantee commitment

Bently Nevada provides the 330901-05-32-05-02-00 with a 24-month warranty covering manufacturing defects and material failures, ensuring consistent performance under normal operating conditions. Our technical support team offers expert guidance on proper installation techniques, mounting location selection, and system integration with components like the 133819-01 signal conditioner.

We offer specialized training on accelerometer calibration, installation best practices, and vibration analysis for systems using the 330901-05-32-05-02-00. Beyond the warranty period, our service agreements include calibration verification, performance testing, and expedited replacement services to minimize downtime. Bently Nevada’s commitment to quality ensures the 330901-05-32-05-02-00 delivers reliable vibration measurement throughout its operational lifecycle, backed by our global network of service professionals.
