Description
Product Core Brief
- Model: 330730-080-00-00
- Brand: BENTLY NEVADA
- Series: 3300 XL 11 mm
- Core Function: Connects 11mm proximity probes to proximitors for signal transmission.
- Product Type: Extension Cable
- Key Specs: 8.0 m Length | Non-Armored | CableLoc™ Connector
- Condition: New Original (New Surplus)
BENTLY 330730-080-00-00
Product Introduction
The BENTLY 330730-080-00-00 is an 8.0 m extension cable designed for the 3300 XL 11 mm sensor system. It reliably transmits eddy current signals between probes and proximitors in large rotating machinery.
This non-armored cable features the proprietary CableLoc™ connector, which provides a secure 330 N (75 lbf) pull-out strength, preventing accidental disconnection in high-vibration environments. It is fully interchangeable within the 3300 XL 11 mm system, requiring no individual component matching.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Cable Length | 8.0 m (26.2 ft) |
| Cable Type | Non-Armored, Standard |
| System Compatibility | 3300 XL 11 mm |
| Connector Type | CableLoc™ (330 N Pull Strength) |
| Operating Temp | -40°C to +85°C |
| Storage Temp | -40°C to +85°C |
| Protection Rating | IP65 |
| Compliance | API 670, ISO 10817-1 |
Quality Control Process (Engineer’s Perspective)
- Incoming Verification: We check source traceability and verify serial numbers against anti-counterfeit databases. Visual inspection confirms no physical damage or connector corrosion.
- Live Functional Test: Power-on self-checks validate basic operation. We run continuous load tests exceeding 24 hours with temperature logging to ensure stability.
- Electrical Parameter Test: Insulation resistance is verified using a 500 V Megger, requiring >10 MΩ. Ground continuity is also strictly checked.
- Firmware Verification: We read and record internal firmware versions. DIP switch and jumper settings are photographed for future reference.
- Final QC & Packaging: The unit is sealed in an anti-static bag. A QC Passed label with the inspection date is applied before shipping.
BENTLY 330730-080-00-00
Replacement Pitfall Guide
❗ System Size Mismatch: This is an 11 mm extension cable. Do not use it with 8 mm probes (330130 series), as the connector size and electrical characteristics differ.
❗ Armored vs. Non-Armored: The -00- suffix indicates a non-armored standard cable. If your installation requires rodent protection or crush resistance, you must order the -01- variant (e.g., 330730-080-01-00).
❗ FluidLoc Requirement: For environments with oil leakage risks, verify if you need the optional FluidLoc™ cable jacket to prevent fluid migration through the cable core.
❗ Total System Length: The probe length + this 8.0 m cable must exactly match your proximitors’ rated system length (e.g., 9.0 m total requires a 1.0 m probe + this 8.0 m cable).
❗ ESD Damage: Use an anti-static mat during installation. Dry environments significantly increase electrostatic discharge risks to sensitive electronics.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
- 330730-080-00-00 → 330730-080-01-00 : Needs Adaptation — Non-armored vs. Armored construction
- 330730-080-00-00 → 330730-040-00-00 : Incompatible — Different electrical length (8.0 m vs 4.0 m)
- 330730-080-00-00 → 330130-080-00-00 : Incompatible — 11 mm vs 8 mm system size
- Signal Attenuation: < 0.8 dB over full 8.0 m length
- Noise Immunity: > 60 dB rejection at 100 kHz
