Product introduction

The 330130-085-00-00 from Bently Nevada is a precision calibration fixture kit designed specifically for the 3300 XL Proximitor Sensor System, essential for ensuring accurate proximity sensor measurements in industrial machinery monitoring. This specialized tool provides a controlled environment for setting and verifying sensor gap distances, which is critical for reliable vibration, position, and displacement measurements. Bently Nevada’s 330130-085-00-00 serves as the gold standard for calibrating 3300 XL series sensors, including compatibility with the 330100-90-01 sensor housing, ensuring that machinery protection systems operate with maximum accuracy.

Bently Nevada’s 330130-085-00-00 bridges the gap between sensor manufacturing specifications and real-world installation accuracy. Its precision-engineered components allow technicians to establish known gap distances during sensor setup and periodic calibration, directly impacting the reliability of data processed by systems like the 1900/27 controller and displayed on interfaces such as the 1900/55-0Z-01-01-01. Proper calibration with the 330130-085-00-00 ensures that protection thresholds are correctly set, preventing false alarms and ensuring timely detection of actual machinery faults.

Core advantages and technical highlights

Laboratory-grade precision: The 330130-085-00-00 delivers ±0.01 mm calibration accuracy, ensuring that proximity sensors are set to exact gap specifications. This level of precision is critical because even minor calibration errors can lead to significant measurement inaccuracies in vibration and position monitoring, compromising the effectiveness of machinery protection systems.

System compatibility: Specifically designed for 3300 XL series sensors and 330100-90-01 housings, the 330130-085-00-00 provides a perfect fit during calibration, mimicking actual installation conditions. This ensures that calibration results translate directly to real-world performance, unlike generic calibration tools that may not account for housing geometry.

Durable construction: Built with anodized aluminum and stainless steel components, the 330130-085-00-00 maintains its precision even after repeated use in industrial environments. The materials resist corrosion and wear, ensuring long-term calibration accuracy and reducing the need for frequent tool recalibration.

Traceable certification: Each 330130-085-00-00 kit includes documentation traceable to NIST standards, providing audit-ready calibration records essential for compliance in regulated industries such as nuclear power, oil and gas, and chemical processing. This traceability ensures that sensor measurements can be confidently referenced in quality control and safety audits.

Typical application scenarios

In power generation facilities, the 330130-085-00-00 is used during turbine outages to calibrate proximity sensors monitoring shaft vibration and position. Technicians rely on its precision to set initial sensor gaps, ensuring that the 1900/27 controller receives accurate data for protection logic. Regular recalibration using the 330130-085-00-00 during maintenance outages verifies that sensor performance hasn’t drifted, maintaining the integrity of protection systems for critical turbine assets.

Oil and gas processing plants utilize the 330130-085-00-00 to calibrate sensors on compressors and pumps, where accurate vibration measurement is essential for detecting bearing wear and rotor imbalance. The kit’s portability allows technicians to perform on-site calibrations, ensuring that sensors installed in hazardous areas (protected by 330100-90-01 housings) maintain accuracy despite harsh environmental conditions. Calibration records from the 330130-085-00-00 support compliance with API 670 standards for machinery protection.

Manufacturing facilities employ the 330130-085-00-00 during new sensor installations and periodic maintenance of production line machinery. By calibrating proximity sensors with this precision tool, they ensure that the 1900/55-0Z-01-01-01 interface displays accurate machinery health data, allowing operators to make informed decisions about equipment performance and maintenance scheduling.
