Product Core Brief
- Model: 330130-040-01-00
- Brand: BENTLY NEVADA
- Series: 3300 XL 8 mm
- Core Function: Transmits eddy current signals between probe and proximitors.
- Product Type: Armored Extension Cable
- Key Specs: 4.0 m Length | Armored Construction | 50 Ω Impedance
- Condition: New Original (New Surplus)
BENTLY 330130-040-01-00
Product Introduction
The BENTLY 330130-040-01-00 is a 4.0 m armored extension cable for the 3300 XL 8 mm system. It reliably connects proximity probes to proximitors in harsh industrial environments.
This armored variant provides superior mechanical protection against crushing and rodent damage compared to standard cables. It maintains a 50 Ω characteristic impedance to ensure signal integrity over the full 4.0 m length without requiring system recalibration.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Cable Length | 4.0 m (13.1 ft) |
| Cable Type | Armored, Double Shielded |
| Characteristic Impedance | 50 Ω ± 5% |
| Capacitance | ≤ 100 pF/ft |
| Operating Temp | -40°C to +85°C |
| Storage Temp | -40°C to +85°C |
| Protection Rating | IP67 (Armored) |
| Compliance | API 670, ISO 10817-1 |
Quality Control Process (Engineer’s Perspective)
- Incoming Verification: We check source traceability and verify serial numbers against anti-counterfeit databases. Visual inspection confirms no physical damage or connector corrosion.
- Live Functional Test: Power-on self-checks validate basic operation. We run continuous load tests exceeding 24 hours with temperature logging to ensure stability.
- Electrical Parameter Test: Insulation resistance is verified using a 500 V Megger, requiring >10 MΩ. Ground continuity is also strictly checked.
- Firmware Verification: We read and record internal firmware versions. DIP switch and jumper settings are photographed for future reference.
- Final QC & Packaging: The unit is sealed in an anti-static bag. A QC Passed label with the inspection date is applied before shipping.
BENTLY 330130-040-01-00
Replacement Pitfall Guide
❗ Firmware Mismatch: Newer monitor modules may require updated sensor calibration constants. Verify compatibility with your 3500/42M or 1900/65A monitor.
❗ DIP Switch / Jumper Misconfiguration: Factory defaults rarely match field settings. Always check bus termination resistors and sensor type jumpers on the terminal block.
❗ Terminal / Cable Incompatibility: Pin definitions can change between revisions. Always verify shield grounding at the third terminal block to prevent signal noise.
❗ Power Supply Mismatch: Calculate total rack power requirements carefully. Always include a 20% headroom margin for transient loads during startup.
❗ ESD Damage: Use an anti-static mat during installation. Dry environments significantly increase electrostatic discharge risks to sensitive electronics.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
- 330130-040-01-00 → 330130-040-00-00 : Needs Adaptation — non-armored vs. armored construction
- 330130-040-01-00 → 330130-040-01-CN : Direct — same cable, CN certification option
- 330130-040-01-00 → 330130-030-01-00 : Incompatible — different electrical length (3.0 m vs 4.0 m)
- Signal Attenuation: < 0.3 dB over full 4.0 m length
- Noise Immunity: > 70 dB rejection at 100 kHz
Need the matching 330104 probe or 330180 proximitors to complete this sensor loop? I can verify the exact electrical length requirements for your rack.
