Product Core Brief
- Model: Bently Nevada 18745-03
- Brand: Bently Nevada
- Series: 3500 Machinery Protection System
- Core Function: Interfaces proximity probes with the 3500 rack for vibration monitoring.
- Product Type: Proximitor / Sensor Interface Module
- Key Specs: 24 Vdc | Modbus RTU | Single Channel
- Condition: New Original (New Surplus) ⚠️ EOL — limited stock remaining
BENTLY 18745-03BENTLY 18745-03
Product Introduction
Bently Nevada 18745-03 serves as a critical interface between proximity probes and the 3500 rack. This unit conditions signals for accurate vibration and position monitoring.
Unlike newer 3500/42M modules, the Bently Nevada 18745-03 lacks internal auto-calibration. Field engineers must manually set gap voltages using a digital multimeter during installation. Verify signal linearity across the full 2 mm range before commissioning.
Key Technical Specifications
- Supply Voltage: 24 Vdc ±10%
- Power Consumption: 1.5 W typical
- Input Impedance: 50 Ω (RF)
- Output Signal: -24 Vdc to 0 Vdc
- Frequency Response: 0 Hz to 10 kHz
- Operating Temp: -40 °C to +85 °C
- Isolation: 500 Vrms channel-to-ground
- Dimensions: 24.1 mm x 124.5 mm x 117.3 mm
Quality Control Process (Engineer’s Perspective)
- Incoming Verification: Trace source via serial number. Inspect PCB for flux residue or pin corrosion.
- Live Functional Test: Power-on self-check. Run Modbus handshake test. Log temperature during 24 hr load.
- Electrical Parameter Test: Measure insulation resistance (500 V Megger, >10 MΩ). Verify ground continuity.
- Firmware Verification: Read firmware version. Photograph DIP switch positions.
- Final QC & Packaging: Seal in anti-static bag. Apply QC Passed label with date.
BENTLY 18745-03
Replacement Pitfall Guide
❗ Firmware Mismatch: Older Bently Nevada 18745-03 units may lack protocol support found in newer revisions. Check the System 1 software compatibility list first.
❗ DIP Switch Misconfiguration: Factory defaults rarely match field settings. Verify bus termination resistor positions. Well, technically it supports Modbus TCP, but only on firmware v3.2+ (most 18745-03 are RTU only).
❗ Terminal Incompatibility: Pin definitions changed between revisions. Check shield grounding at the third terminal block.
❗ Power Supply Mismatch: Calculate total rack power with 20% headroom. This module draws 65 mA at 24 Vdc.
❗ ESD Damage: Use anti-static mat. Dry environments increase failure risk during handling.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
- Bently Nevada 18745-03 → 3500/42M : Needs Adaptation — requires config change in System 1
- Bently Nevada 18745-03 → 3300 XL NSv : Incompatible — different form factor
- Bently Nevada 18745-03 → 18745-04 : Direct — check probe cable length spec
