Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | AMAT 0100-77037 |
| Manufacturer | Applied Materials (AMAT) |
| Product category | Industrial Input/Output Module |
| Input voltage range | 24V DC ±10% |
| Operating frequency | 47-63 Hz |
| Output voltage | +5V, +15V, -15V, +24V regulated DC |
| Number of channels | 16 channels |
| Input signal type | 4 to 20 mA |
| Communication protocols | Modbus/TCP, Modbus/RTU, EtherNet/IP, CC-Link family SLMP |
| Interface | Standard Ethernet |
| Operating temperature | -40°C to +85°C |
| Storage temperature | -40°C to +85°C |
| Humidity | 10 to 90% RH, non-condensing |
| Protection class | IP54 |
| Dimensions | 25 cm x 15 cm x 3 cm |
| Weight | 1 kg |
| Certifications | CE, RoHS, UL compliant |
AMAT 0100-77037
Product Introduction
The AMAT 0100-77037 is a high-performance industrial input/output (I/O) module designed for demanding automation applications. It is part of Applied Materials’ extensive lineup of automation products, known for their reliability and advanced technology. This module is used in semiconductor manufacturing processes, particularly in the Centura/Endura series machines.
Core Advantages and Technical Highlights
Integrated Tank Management: The module features integrated tank management with access to trend and performance monitoring data, ensuring that all critical information can be securely captured and displayed for further analysis.
Intrinsically Safe Design: The 0100-77037 module is an intrinsically secure distributed bus I/O unit. It is configured with redundant industrial fieldbuses or communication networks capable of scheduling individual I/O modules.
Direct Connection to Hazardous Side Transmitter: The module can directly connect with the hazardous side transmitter, transmit the sensing signal generated by the transmitter after isolation from the hazardous side, and provide isolated power for the hazardous side transmitter.
Robust Communication: The module supports multiple communication protocols, including Modbus/TCP, Modbus/RTU, EtherNet/IP, and CC-Link family SLMP, facilitating integration with existing industrial networks.
User-Friendly Design: The rear-mounted design of the AMAT 0100-77037 allows for easy integration into standard industrial control cabinets, simplifying installation and maintenance.
AMAT 0100-77037
Typical Application Scenarios
The AMAT 0100-77037 is widely used in various industrial sectors, including:
-
Semiconductor Manufacturing: Used in CVD equipment for real-time control and data processing.
-
Automotive Welding Line: Installed on tooling boards to collect welding process status and verify the matching of the body VIN code and production plan.
-
Semiconductor Wafer Transmission: Integrated into robot arms to monitor the flow path of wafer carriers in etching/CVD chambers.
Related Model Recommendations
-
AMAT 0100-71271: A related module with similar control capabilities.
-
AMAT 0100-71311: Another module suitable for similar applications.
Installation, Commissioning and Maintenance Instructions
Installation Preparation
Before installing the AMAT 0100-77037, ensure that the environment meets the specified requirements, including an operating temperature range of -40°C to +85°C. The installation location should be free from excessive dust, moisture, and corrosive gases to ensure long-term reliability. Use a standard 483 mm (19-in.) cabinet for secure installation.
Maintenance Suggestions
To maintain the AMAT 0100-77037, perform regular inspections of the unit and its connections to ensure they are secure and free from corrosion. Clean the unit regularly with a soft, dry cloth to remove dust and debris. If any issues arise, refer to the troubleshooting guide in the user manual for common solutions. Replace any worn or damaged parts promptly to ensure continued performance.
