Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | AMAT 0100-71309 |
| Manufacturer | Applied Materials (AMAT) |
| Product category | Industrial Control Module |
| Input voltage range | 24V DC ±15% |
| Operating frequency | 47-63 Hz |
| Output voltage | +5V, +15V, -15V, +24V regulated DC |
| Number of channels | Multiple digital input and output channels |
| Communication protocols | VMEbus compliant, Ethernet, Profibus DP, Modbus TCP/IP |
| Operating temperature | 0 to 50 °C |
| Storage temperature | -20 to 70 °C |
| Humidity | 10 to 90% RH, non-condensing |
| Protection class | IP20 |
| Dimensions | 175 mm (L) × 100 mm (W) × 50 mm (H) |
| Weight | 1.2 kg |
| Certifications | CE, UL, RoHS |
AMAT 0100-71309
Product Introduction
The AMAT 0100-71309 is a high-performance industrial control module designed for demanding automation applications. It is a key component in semiconductor manufacturing equipment, specifically designed for control functions in Applied Materials’ systems. The module is integrated with power modules and nanoboards, playing a crucial role in managing the complex processes involved in chip production.
Core Advantages and Technical Highlights
High Performance and Reliability: The AMAT 0100-71309 offers robust performance and reliability, ensuring stable operation of control modules in various industrial applications.
Flexible Configuration: The unit supports multiple digital input and output channels, providing scalable power distribution and communication capabilities.
Advanced Communication: The unit supports multiple communication protocols, including VMEbus, Ethernet, Profibus DP, and Modbus TCP/IP, facilitating integration with existing industrial networks.
User-Friendly Design: The rear-mounted design of the AMAT 0100-71309 allows for easy integration into standard industrial control cabinets, simplifying installation and maintenance.
AMAT 0100-71309
Typical Application Scenarios
The AMAT 0100-71309 is widely used in various industrial sectors, including:
-
Semiconductor Manufacturing: Used in CVD equipment for real-time control and data processing.
-
Process Automation Systems: Housing modules for control and monitoring in industrial processes.
-
Power Plants: Supporting controllers and I/O modules in power generation environments.
Related Model Recommendations
-
AMAT 0100-71271: A related module with similar control capabilities.
-
AMAT 0190-17964: Another module suitable for similar applications.
Installation, Commissioning and Maintenance Instructions
Installation Preparation
Before installing the AMAT 0100-71309, ensure that the environment meets the specified requirements, including an operating temperature range of 0 to 50 °C. The installation location should be free from excessive dust, moisture, and corrosive gases to ensure long-term reliability. Use a standard 483 mm (19-in.) cabinet for secure installation.
Maintenance Suggestions
