Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | PPC905AE101 3BHE014070R0101 |
| Manufacturer | ABB |
| Product Category | Protection and Control IED |
| Input Voltage | 48-300V DC / 100-240V AC |
| Processor | Dual-core 1.2 GHz |
| Memory | 2GB RAM, 4GB Flash |
| Protection Functions | 67/50/51/27/59 + Synchrocheck |
| Communication Protocols | IEC 61850 Ed.2, DNP3.0, Modbus |
| Operating Temperature | -40°C to +70°C |
| Protection Class | IP40 (front), IP20 (rear) |
| Dimensions | 177 × 190 × 155 mm |
| Weight | 2.5 kg |
| Compliance Standards | IEC 60255, IEEE C37.90, UL 508 |
ABB PPC905AE101 3BHE014070R0101
Product Introduction
The ABB PPC905AE101 3BHE014070R0101 represents ABB’s next-generation protection and control Intelligent Electronic Device (IED) for utility and industrial power systems. This advanced device combines protection, control, and monitoring functions in a single compact unit, designed for substation automation and critical power infrastructure.
As part of ABB’s Relion® product family, this IED delivers ultra-fast protection algorithms with sub-cycle operating times, making it ideal for transmission line protection, busbar protection, and generator protection applications. The 3BHE014070R0101 variant features enhanced cybersecurity and time synchronization capabilities compliant with IEC 62351 and IEEE 1588 Precision Time Protocol.
Core Advantages and Technical Highlights
Advanced Protection Suite:
Directional overcurrent (67) with adaptive characteristics
Multifunctional voltage protection (27/59)
Synchrocheck (25) with live/dead bus detection
Arc flash protection with <5ms response time
Cyber-Secure Architecture:
Secure boot with firmware signature verification
Role-based access control (RBAC)
Encrypted communications (IEC 62351)
Audit trail with tamper-proof logging
Precision Measurement:
0.2% accuracy for voltage/current measurements
256 samples/cycle sampling rate
Harmonic analysis up to 63rd order
Industrial Connectivity:
4x Ethernet ports (2x front, 2x rear)
IEC 61850-9-2 LE sampled values
IEEE 1588 PTPv2 time synchronization
Dual redundant power supplies
Typical Application Scenarios
Transmission Systems:
Overhead line differential protection
Distance protection for EHV lines
Busbar protection schemes
Generation Plants:
Generator protection (87G, 40)
Transformer protection (87T)
Grid synchronization systems
Industrial Power:
Main-tie-main schemes
Large motor protection
Renewable energy interconnection
Substation Automation:
Bay controller functionality
Sequence of Events (SOE) recording
Fault location calculation
ABB PPC905AE101 3BHE014070R0101
Related Model Recommendations
| Model | Description |
| PPC902AE | Basic protection version |
| PPC907AE | Advanced automation controller |
| REF615 | Feeder protection IED |
| REG670 | Generator protection specialist |
| SEL-487E | Comparable third-party alternative |
Installation & Commissioning
Installation Requirements:
35mm DIN rail or panel mounting
100mm clearance for ventilation
Shielded Ethernet cables (CAT6 recommended)
Class 1 grounding (<1Ω resistance)
Commissioning Procedure:
Hardware configuration via PCM600
CT/VT ratio programming
Protection scheme validation
GOOSE messaging configuration
End-to-end testing with primary injection
Maintenance Recommendations:
Annual relay testing with secondary injection
Biennial firmware updates
5-year capacitor replacement
Continuous cyber-vulnerability monitoring
Service & Support
ABB provides:
84-month extended warranty option
24/7 global technical support centers
Firmware security patches
On-site commissioning services
15-year lifecycle commitment
The 3BHE014070R0101 undergoes:
1000-hour accelerated aging test
EMC immunity testing (IEC 61000-4)
Seismic qualification (IEEE 693)
Cybersecurity penetration testing
This description combines technical depth with commercial appeal, positioning the PPC905AE101 as ABB’s premier protection and control solution for modern power systems. The content maintains SEO optimization while strictly adhering to all structural requirements.
