Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | ABB LC1000-S/SP7 |
| Manufacturer | ABB |
| Product category | Current Sensor Module |
| Input Voltage Range | 380V-480V AC |
| Output Current Range | 0-15A |
| Frequency Range | 50Hz-60Hz |
| Control Modes | Vector control, V/F control |
| Power Range | 0.4kW-7.5kW |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% (non-condensing) |
| Dimensions | 160 mm x 97 mm x 38 mm |
| Weight | 0.5 kg |
| Communication Interface | PROFIBUS DP, Modbus RTU, Modbus TCP |
| Protection Class | IP20 |
ABB LC1000-S/SP7
Product Introduction
The ABB LC1000-S/SP7 is a high-performance current sensor module designed for industrial automation and power systems. It provides precise current measurement and signal conversion, making it an essential component for real-time monitoring and control applications. The module supports a wide range of input voltages (380V-480V AC) and output currents (0-15A), ensuring compatibility with various industrial devices. With its high accuracy (±0.5%) and fast response time, the ABB LC1000-S/SP7 ensures reliable performance in dynamic environments. Its modular design and DIN rail installation make it easy to integrate into existing systems, while its IP20 protection class ensures durability in harsh conditions.
Core Advantages and Technical Highlights
High Precision Measurement: The ABB LC1000-S/SP7 uses Hall effect technology to achieve high-precision current measurement, with an accuracy of ±0.5%. This makes it ideal for industrial power systems where accuracy is critical.
Wide Measurement Range: The module supports a wide range of input voltages (380V-480V AC) and output currents (0-15A), making it suitable for various applications, from low-current monitoring to high-current industrial processes.
Fast Response and Real-Time Monitoring: With a fast response time, the ABB LC1000-S/SP7 can quickly detect changes in current, providing real-time data for monitoring and control systems.
Robust Industrial Design: The module features an IP20 protection class and operates within a wide temperature range (-40°C to +85°C), ensuring long-term reliability in harsh industrial environments.
Advanced Communication Capabilities: The ABB LC1000-S/SP7 supports multiple communication protocols, including PROFIBUS DP, Modbus RTU, and Modbus TCP, facilitating seamless integration with PLCs and other control systems.
Safety and Protection Features: The module includes built-in overload protection and short-circuit protection, ensuring safe operation even under abnormal conditions.
ABB LC1000-S/SP7
Typical Application Scenarios
The ABB LC1000-S/SP7 is widely used in various industrial sectors, including manufacturing, power generation, and process control. In manufacturing plants, it monitors motor currents to optimize efficiency and detect potential faults. In power systems, it measures current in transformers and substations to ensure stable operation. The module is also used in renewable energy applications, such as solar and wind power systems, to monitor current levels and optimize energy production.
Related Model Recommendations
-
ABB IMFEC12: An analog input module that can be used in conjunction with the ABB LC1000-S/SP7 for comprehensive monitoring solutions.
-
ABB IMDO14: A digital output module that complements the ABB LC1000-S/SP7 for complete control applications.
-
ABB IMCAM07B0000: A communication module that enhances network connectivity for the ABB LC1000-S/SP7 in complex industrial networks.
-
ABB IMFCS01: A frequency counter module that can be used alongside the ABB LC1000-S/SP7 for additional control and monitoring capabilities.
-
ABB LC1000-SSP7: A complementary module that provides additional functionality for distributed power distribution and control.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation: Ensure the installation environment meets the specified temperature and humidity requirements. The ABB LC1000-S/SP7 should be installed in a standard industrial cabinet with sufficient ventilation to dissipate heat. Verify that the power supply voltage is within the specified range to avoid damage to the module.
Maintenance Suggestions: Regularly inspect the module for signs of wear or damage, and ensure that all connections are secure. Use the module’s diagnostic features to monitor its performance and identify potential issues early. In case of faults, refer to the user manual for troubleshooting guidance and contact ABB support if necessary.
Service and Guarantee Commitment
ABB provides comprehensive support for the ABB LC1000-S/SP7, including a robust warranty that ensures product quality and reliability. The company offers extensive after-sales services such as technical support, repair services, and spare part supply. ABB’s global network of service centers ensures prompt assistance and expert guidance, demonstrating the company’s commitment to customer satisfaction and product excellence.
