Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB CP800 |
| Manufacturer | ABB |
| Product Category | Control Panel HMI |
| Display Type | TFT LCD with LED Backlight |
| Screen Size | 7-inch (800×480 resolution) |
| Touch Technology | Resistive (Analog) |
| Processor | 400 MHz ARM Cortex-A8 |
| Memory | 128MB RAM, 512MB Flash |
| Operating System | Windows CE 6.0 |
| Communication Ports | 1× Ethernet, 2× USB, 1× RS-232/485 |
| Power Supply | 24V DC (±10%) |
| Protection Rating | IP65 (front panel) |
| Operating Temperature | 0°C to +50°C |
| Dimensions (W×H×D) | 226×170×52 mm |
| Certifications | CE, UL, cUL |
ABB CP800
Product Introduction
The ABB CP800 is a compact and robust Human-Machine Interface (HMI) panel designed for industrial automation applications. Part of ABB’s control panel portfolio, this 7-inch operator terminal provides reliable visualization and control capabilities for monitoring and operating industrial processes. The CP800 combines an intuitive user interface with rugged industrial construction, making it suitable for harsh factory environments.
Featuring a bright 800×480 resolution display with resistive touchscreen, the ABB CP800 delivers clear process visualization even in high-ambient-light conditions. Its Windows CE 6.0 operating system ensures stable performance while supporting a wide range of industrial communication protocols. The panel’s IP65-rated front protects against dust and water jets, enabling installation in demanding industrial settings.
Core Advantages and Technical Highlights
High-visibility display:
The ABB CP800 features a 7-inch TFT LCD with LED backlight that provides excellent readability in various lighting conditions. The 800×480 WVGA resolution ensures crisp display of process graphics and data. The resistive touchscreen supports operation with gloves, making it practical for industrial environments.
Robust industrial design:
Built for 24/7 operation, the CP800 boasts an IP65 front panel rating that protects against dust and water jets. The aluminum front bezel provides mechanical durability, while the wide operating temperature range (0°C to +50°C) ensures reliable performance in most industrial environments.
Flexible connectivity:
With Ethernet, USB, and serial ports, the ABB CP800 offers multiple options for connecting to PLCs, drives, and other automation components. The panel supports Modbus RTU/TCP, PROFIBUS DP (with optional module), and OPC communication for seamless system integration.
User-friendly development:
The CP800 is programmed with ABB’s Panel Builder 800 software, which offers intuitive tools for creating customized operator interfaces. The development environment includes pre-configured faceplates, alarm management tools, and data logging capabilities to streamline project implementation.
Reliable performance:
Powered by a 400 MHz ARM Cortex-A8 processor, the ABB CP800 delivers responsive operation for most industrial applications. The 128MB RAM and 512MB Flash memory provide sufficient capacity for typical HMI applications, while ensuring fast boot times and stable operation.
Typical Application Scenarios
The ABB CP800 is widely used in:
Manufacturing automation:
Machine control panels for CNC equipment
Production line monitoring stations
Robotic cell operator interfaces
Process industries:
Small-scale process visualization
Batch operation control panels
Equipment status monitoring
Building automation:
HVAC system control interfaces
Energy management displays
Elevator control panels
Water and wastewater:
Pump station control interfaces
Filtration system monitoring
Chemical dosing control
Food and beverage:
Processing equipment control
Packaging machine interfaces
Clean-in-place system monitoring
ABB CP800
Related Model Recommendations
ABB CP600: 5.7-inch basic HMI panel
ABB CP900: 9-inch advanced HMI panel
ABB CP400: 4.3-inch compact HMI
ABB AC500: Compatible PLC for automation
ABB ACS350: Drive with HMI connectivity
ABB S800 I/O: Remote I/O for system expansion
ABB COM600: Communication gateway
Installation and Commissioning
Installation preparation:
Mount the ABB CP800 using the integrated mounting clips or optional VESA mount. Ensure proper clearance for ventilation and cable routing. Verify the 24V DC power supply meets specifications before connection.
Commissioning steps:
Install Panel Builder 800 software
Develop the HMI application
Transfer the project to the panel
Configure communication settings
Test all operator functions
Secure the final installation
Maintenance recommendations:
Regularly clean the display with approved cleaners
Check cable connections periodically
Backup application files regularly
Monitor available memory for data logging
Update firmware as recommended
Service and Guarantee Commitment
ABB provides:
2-year standard warranty
Global technical support
Software updates and patches
Repair and replacement services
Comprehensive documentation
The ABB CP800 is backed by ABB’s commitment to quality and reliability, with long-term product support and availability. Our experienced automation specialists are available to assist with installation, configuration, and troubleshooting to ensure optimal performance throughout the product lifecycle.
