Product Introduction

The ABB CI867K01 3BSE043660R1 is a high-performance PROFINET IO communication interface designed for ABB’s AC 800M programmable automation controller. This industrial-grade module enables seamless integration of AC 800M controllers into PROFINET networks, providing deterministic real-time communication for industrial automation systems.

As part of ABB’s comprehensive communication portfolio, the CI867K01 supports PROFINET IO Class A with 100 Mbps Fast Ethernet connectivity. Its rugged design ensures reliable operation in demanding industrial environments, making it ideal for applications in power generation, process industries, and manufacturing automation where robust network performance is critical.

Core Advantages and Technical Highlights

High-Performance PROFINET Connectivity:

PROFINET IO Class A support for real-time communication

100 Mbps Fast Ethernet with auto-negotiation

Dual RJ45 ports with auto-MDI/MDIX for flexible cabling

Media Redundancy Protocol (MRP) support for network reliability

Robust Industrial Design:

Wide operating temperature range (0°C to +60°C)

Compact form factor (45×130×115 mm) for space-efficient installation

Electrical isolation for noise immunity

Hot-swappable in redundant configurations

Advanced Diagnostics:

LED status indicators for quick fault identification

Comprehensive diagnostic data accessible via controller

Web-based configuration interface for easy setup

SNMP support for network management

Seamless Integration:

Direct compatibility with AC 800M controllers

Easy configuration through ABB’s Control Builder

Support for PROFINET IO devices up to 256 bytes per device

GSDML file available for easy device integration

Typical Application Scenarios

The ABB CI867K01 3BSE043660R1 is widely used in:

Automotive Manufacturing:

Robot cell control networks

Assembly line synchronization

Vision system integration

Food & Beverage Processing:

Packaging machine control

Batch process automation

CIP (Clean-in-Place) system monitoring

Pharmaceutical Production:

Process equipment networking

Batch record keeping systems

Environmental monitoring

Material Handling:

Conveyor control systems

Automated storage/retrieval

Crane and hoist networks

ABB CI867K01 3BSE043660R1

Related Model Recommendations

ABB CI867K02: Enhanced version with PROFINET IRT support

ABB CI854: PROFIBUS DP communication interface

ABB CMA120: Ethernet communication module

ABB PM861AK01: Compatible processor module

ABB S800 I/O: Remote I/O system

ABB COM600: Communication gateway

Installation and Commissioning

Installation Guidelines:

Mount in designated slot of AC 800M controller rack

Use shielded CAT5e or better Ethernet cables

Maintain proper cable bend radius (>30mm)

Verify network infrastructure meets PROFINET requirements

Commissioning Steps:

Install GSDML file in engineering tool

Configure PROFINET device names

Set up IO data exchange parameters

Verify network connectivity

Test redundancy functionality (if used)

Maintenance Recommendations:

Regularly check network connection status

Monitor PROFINET diagnostics

Keep firmware updated to latest version

Document network topology changes

Service and Guarantee Commitment

ABB provides:

3-year standard warranty

Global 24/7 technical support

Firmware update services

Advanced replacement options

Comprehensive documentation

The ABB CI867K01 3BSE043660R1 represents ABB’s commitment to reliable industrial networking, combining PROFINET expertise with rugged industrial design for demanding automation applications.
