Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | ABB CI541V1 3BSE014666R1 |
| Manufacturer | ABB |
| Product category | Communication Interface Module |
| Communication Protocol | Profibus DP |
| Data Transfer Rate | 960 kbps |
| Operating Voltage | 24V DC |
| Operating Temperature | -20°C to +60°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Protection Rating | IP20 (standard installation) |
| Dimensions (W x H x D) | 125 mm x 20 mm x 255 mm |
| Weight | 0.17 kg |
| Installation Method | DIN rail installation (EN 50022 NS35/7.5), supports vertical or horizontal installation |
ABB CI541V1 3BSE014666R1
Product Introduction
The ABB CI541V1 3BSE014666R1 is a high-performance Profibus DP interface module designed for industrial automation applications. It is part of ABB’s Advant OCS and S100 I/O system series and is used to facilitate efficient data exchange between control systems and field devices. This module supports both master and slave modes, providing flexibility for various industrial applications.
Core Advantages and Technical Highlights
High-Speed Communication: The CI541V1 3BSE014666R1 supports Profibus DP protocol with a data transfer rate of up to 960 kbps, ensuring fast and reliable communication.
Redundant Communication: The module supports redundant communication, enhancing system reliability and availability.
Robust Design: Built for industrial environments, the CI541V1 3BSE014666R1 operates efficiently within a wide temperature range of -20°C to +60°C and offers IP20 protection for standard installations.
User-Friendly Configuration: The module features built-in LED indicators for real-time status monitoring and error detection, simplifying maintenance and troubleshooting.
ABB CI541V1 3BSE014666R1
Typical Application Scenarios
The ABB CI541V1 3BSE014666R1 is widely used in various industrial sectors:
-
Manufacturing Plants: For real-time control and monitoring of production lines.
-
Power Generation Facilities: To monitor and control power plants and substations.
-
Process Control: In chemical, oil, and gas industries for process monitoring and regulation.
-
Water Treatment Plants: For controlling pumps and valves in water treatment processes.
Related Model Recommendations
-
ABB AC800M: A powerful PLC controller that integrates seamlessly with the CI541V1 for advanced automation control.
-
ABB AI810: An analog input module for precise data acquisition, suitable for monitoring drive systems.
-
ABB DI810: A digital input module that can be used alongside the CI541V1 to provide a complete I/O solution.
Installation, Commissioning and Maintenance Instructions
Installation Preparation: Ensure the environment meets the specified temperature and humidity requirements (-20°C to +60°C, 5% to 95% RH non-condensing). Use shielded cables and proper grounding to minimize electromagnetic interference. Follow ABB’s guidelines for DIN rail mounting, ensuring proper ventilation and protection from dust.
Maintenance Suggestions: Regularly inspect connections for wear and clean the module with a static-free cloth to ensure optimal heat dissipation. Use ABB’s dedicated software for module configuration and firmware updates. Follow ABB’s guidelines for handling sensitive components, including anti-static measures during maintenance.
Service and Guarantee Commitment
ABB stands behind the quality and reliability of the CI541V1 3BSE014666R1, offering a comprehensive warranty that covers manufacturing defects and performance issues for a specified period. Our dedicated after-sales support team is available to assist with technical inquiries and provide prompt solutions to ensure minimal disruption to your operations.
