Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3BHB009884R5211 |
| Manufacturer | ABB |
| Product Category | Industrial Control Module |
| Series | AC800PEC High Voltage Inverter |
| Input Voltage Range | 24V DC or 120/240V AC |
| Output Voltage Range | 5-24 VDC |
| Output Current Range | 0-10 A |
| Maximum Power Output | 240 W |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (W×H×D) | 263 mm × 58 mm × 28 mm |
| Weight | 4.3 kg |
| Certifications | CE, RoHS |
| Communication Protocols | Modbus, Profibus, Ethernet |
| Isolation Voltage | 2 kV |
| Measurement Accuracy | ±0.5% |
| Response Time | <2 ms |
| Explosion-proof Class | Ex ia IIB T4 |
3BHB009884R5211
Product Introduction
The ABB 3BHB009884R5211 is a high-performance phase module designed for the AC800PEC high voltage inverter system. It efficiently converts input alternating current or direct current into specific voltage and current outputs to power other circuits or devices.
Core Advantages and Technical Highlights
High Reliability and Precision: The 3BHB009884R5211 features advanced electronic components and materials, ensuring high precision and reliability in harsh industrial environments.
Wide Operating Range: The module operates reliably within a temperature range of -20°C to +60°C and a humidity range of 5% to 95% non-condensing.
Advanced Communication Protocols: The 3BHB009884R5211 supports various communication protocols, including Modbus, Profibus, and Ethernet, enabling seamless integration with existing systems.
User-Friendly Interface: The module features a user-friendly interface that facilitates easy setup and operation, minimizing the learning curve for new users.
Modular Design: The high voltage inverter features a modular design, making the structure compact, easy to maintain, and enhancing the interchangeability of the product.
High Efficiency and Energy Saving: The module uses advanced power electronics technology to achieve high efficiency and energy savings.
3BHB009884R5211
Typical Application Scenarios
The ABB 3BHB009884R5211 is widely used in various industrial sectors, including:
-
Industrial Automation: For process control and machine control applications.
-
Power Plants: For monitoring and controlling power generation processes.
-
Water Treatment Facilities: For managing pumps and valves in water treatment systems.
-
Oil & Gas Industry: For high-precision control and monitoring of industrial processes.
Related Model Recommendations
-
ABB 70BV05A-ES: Known for its robust I/O capabilities.
-
ABB 70EA2a-ES: A reliable choice for general control tasks.
-
ABB 70EA01B-ES: Ideal for communication-intensive applications.
-
ABB 70EB0lb-E: Designed for motion control.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation: Ensure the installation environment is clean and free of interference. Prepare the necessary tools and follow the installation manual carefully.
Maintenance Suggestions: Regularly inspect the module for physical damage, monitor output voltages using a multimeter, and check for abnormal heat generation or noises. Clean the module’s surface periodically to prevent dust accumulation, which can affect heat dissipation.
Service and Guarantee Commitment
The ABB 3BHB009884R5211 comes with a comprehensive warranty, ensuring customer satisfaction and peace of mind. ABB provides technical support and service to assist with installation, troubleshooting, and maintenance.
