ABB 1TGE106170M4200

Product Introduction

The ABB 1TGE106170M4200 is a high-quality rotary handle mechanism designed for ABB’s Tmax XT series of molded case circuit breakers. This essential accessory enables remote manual operation of circuit breakers installed in switchboards or enclosures, providing a safe and convenient way to control power distribution without direct access to the breaker itself.

Engineered for reliability and durability, the 1TGE106170M4200 features a robust thermoplastic construction that withstands the rigors of industrial environments. Its ergonomic design allows for smooth operation, while the clear ON/OFF indicators provide immediate visual confirmation of breaker status. This accessory is particularly valuable in applications where breakers are mounted behind panels or in hard-to-reach locations.

Core Advantages and Technical Highlights

Safe remote operation:

The ABB 1TGE106170M4200 enables operators to safely control circuit breakers from outside electrical enclosures, reducing exposure to live components. The mechanism provides positive operation feedback through distinct tactile positions for ON and OFF states.

Durable construction:

Manufactured from UL94 V0 flame-retardant thermoplastic, the handle mechanism resists mechanical stress and environmental factors. Its 10,000-operation mechanical life ensures long-term reliability in demanding applications.

Easy installation:

The front-mounting design simplifies installation on enclosure doors or panels. The mechanism features universal compatibility across Tmax XT breaker sizes (XT1-XT4), reducing inventory requirements.

Clear status indication:

Bright color-coded indicators (green for ON, red for OFF) provide unambiguous breaker status visibility, even in low-light conditions. The positive position detents prevent ambiguous intermediate states.

Versatile applications:

Suitable for use in industrial control panels, power distribution cabinets, and machine electrical compartments. The mechanism maintains the breaker’s original IP protection rating when properly installed.

Typical Application Scenarios

Industrial control panels:

The ABB 1TGE106170M4200 is widely used in factory automation systems where multiple circuit breakers need centralized, safe operation from a control panel door.

Power distribution cabinets:

In electrical rooms and substations, the handle mechanism allows maintenance personnel to safely control breakers without opening energized enclosures.

Machine tools:

The accessory provides convenient local control for machine-mounted circuit breakers while maintaining operator safety and enclosure integrity.

HVAC systems:

For large commercial HVAC installations, the mechanism enables easy operation of compressor and fan circuit breakers from central control points.

Water treatment plants:

The 1TGE106170M4200 is used in control panels managing pump and motor circuits, allowing safe operation in wet or corrosive environments.

ABB 1TGE106170M4200

Related Model Recommendations

ABB 1TGE106170M4100: Shaft extension kit for deep panels

ABB 1TGE106170M4300: Padlockable version for safety isolation

ABB 1TGE106170M4400: Extended handle version

ABB 2CDS271001R0484: Breaker position indicator

ABB 1TGE106170M4500: Handle mechanism with emergency stop

ABB 1TGE106170M4600: Dust-proof version for harsh environments

Installation and Commissioning

Installation preparation:

Verify compatibility with the specific Tmax XT breaker model. Ensure the mounting panel has proper cutout dimensions (68.5×68.5 mm) and adequate clearance behind the panel for mechanism operation.

Commissioning steps:

Mount the mechanism on the panel door

Connect to the breaker using the provided coupling

Verify smooth operation through full travel

Check alignment of position indicators

Test locking functionality (if applicable)

Maintenance recommendations:

Regularly inspect for smooth operation and proper alignment. Clean the mechanism during routine panel maintenance. Check for wear after extensive use (10,000 operations). Verify position indicators remain clearly visible.

Service and Guarantee Commitment

ABB provides a 2-year warranty for the 1TGE106170M4200, covering material and workmanship defects. Our global support network offers:

Technical documentation and installation guides

Product selection assistance

Replacement parts availability

Expert technical support

The ABB 1TGE106170M4200 is designed and manufactured to meet stringent quality standards, ensuring reliable performance throughout its service life. ABB’s commitment to product excellence is backed by decades of experience in electrical distribution solutions.
