ABB YT399001-AN YPH 105 E Digital Speed Input Board for Steam/Gas Turbines in Power Plants

  • Model: YT399001-AN (ABB YPH 105 E Digital Speed Input Board)
  • Alt. P/N: YT399001AN, YPH105E, 3BSE000742R1 (compatible variant)
  • Series: ABB YT Series Turbine Control Modules / YPH Speed Input Boards
  • Type: High-Precision Digital Speed Input Module for Industrial Turbines, Motors, and Compressors
  • Key Feature: 0-10kHz frequency input range, 16-bit resolution, optical isolation (2500VAC), 24VDC redundant power, 4-20mA analog output, speed trip setpoints, LED status indicators
  • Primary Use: Speed monitoring, protection, and control for steam turbines, gas turbines, and large industrial motors in power plants, refineries, and petrochemical facilities
Get a Quote
In Stock
Manufacturer:
Part number: ABB YT399001-AN
Our extensive catalogue, including : ABB YT399001-AN , is available now for dispatch to the worldwide. Brand:

Description

Key Technical Specifications

  • Model Number: YT399001-AN (YPH 105 E Digital Speed Input Board)
  • Manufacturer: ABB Process Automation Division (Turbine Control Systems)
  • Product Type: Digital Speed Input Module for Turbine & Motor Control
  • System Compatibility: ABB Symphony Harmony DCS, ABB Turbine Control Systems (TCS), ABB AC800M Controllers
  • Input Specifications:
    • Frequency Range: 0-10kHz (compatible with magnetic pickup sensors)
    • Input Channels: 2 redundant speed input channels (for reliability)
    • Input Type: Magnetic pickup (proximity sensor) signals (10-24VDC)
    • Isolation Rating: 2500VAC (channel-to-channel, power-to-signal)
  • Output Specifications:
    • Analog Output: 1 x 4-20mA (proportional to speed, 0-100% of rated speed)
    • Digital Outputs: 2 x speed trip relays (SPDT, 250VAC/5A) for overspeed protection
    • Communication Interface: MODBUS RTU, PROFIBUS DP (optional)
  • Power Supply: 24VDC ±10% (redundant inputs, 5W typical, 8W max)
  • Operating Temperature: -20°C to +60°C (ambient, derate >55°C)
  • Vibration Resistance: Up to 3g (10-500Hz, IEC 60068-2-6)
  • Mounting Type: 19″ rack mount (3U height), DIN rail compatible
  • Diagnostics: 4 LED status indicators (power, speed input 1, speed input 2, trip status), fault logging
  • Certifications: CE, UL, ATEX, IEC 61508 (SIL 2), API 670 compliant
ABB IMDSO14

ABB IMDSO14

Field Application & Problem Solved

In power generation and petrochemical industries, inaccurate speed monitoring is the #1 cause of turbine failures. At a coal-fired power plant in Pennsylvania, a failed legacy speed input module caused a 3-hour shutdown of a steam turbine ($380k in lost generation). At a Texas refinery, an overspeed event due to a faulty speed sensor interface destroyed a gas turbine ($2.1M in repair costs).
The YT399001-AN solves these critical issues by delivering:
  1. High Precision Speed Measurement: 16-bit resolution provides 0.001% accuracy, enabling precise turbine control
  2. Redundant Input Channels: Dual speed inputs eliminate single-point failures, ensuring reliable overspeed protection
  3. Optical Isolation: 2500VAC isolation blocks EMI/RFI interference common in power plant/refinery environments
  4. Integrated Speed Trip: Built-in trip relays with adjustable setpoints (105-120% of rated speed) provide fast overspeed protection (≤10ms response)
  5. Analog Output: 4-20mA signal enables integration with DCS systems for remote monitoring and control
Typical deployments:
  1. Power Plants: Steam turbine speed control for generator sets, boiler feedwater pump motor speed monitoring
  2. Refineries: Gas turbine speed control for compressor trains, crude distillation unit motor speed protection
  3. Petrochemical Plants: Centrifugal compressor speed monitoring, ethylene cracker turbine control
  4. Steel Mills: Blast furnace blower motor speed control, rolling mill drive speed monitoring
ABB IMDSO14

ABB IMDSO14

Installation & Maintenance Pitfalls (Expert Tips)

  1. Sensor Wiring Must Follow Isolation Standards: A technician at a Florida power plant used non-shielded cable for magnetic pickup sensors, causing speed signal noise and false trips. Use double-shielded twisted-pair cable (22AWG minimum) for speed inputs, and separate from power cables by ≥30cm.
  2. Speed Trip Setpoints Require Calibration: At a Louisiana refinery, a technician installed the module without calibrating the speed trip setpoints, leading to a 2-hour shutdown during startup. Use ABB Turbine Control Studio to set trip points (typically 110% of rated speed) and test with a frequency generator.
  3. Redundant Power is Mandatory: Skipping redundant power at a Texas chemical plant caused the module to fail during a power surge, halting production for 4 hours. Always connect both 24VDC power inputs to separate power supplies.
  4. EMI Filter Installation Prevents Signal Corruption: A technician at an Illinois refinery didn’t install an EMI filter on the speed input lines, causing erratic speed readings. Install ABB-recommended EMI filters (e.g., 1MRK000000-AA) on all speed input channels.
  5. Grounding is Critical for Accuracy: Poor grounding at a Michigan power plant caused a 0.5% speed measurement error, affecting turbine efficiency. Ground the module to the cabinet chassis using a dedicated ground wire (16AWG minimum) and ensure the magnetic pickup sensor is grounded at only one end.
  6. Firmware Update Prevents Compatibility Issues: At a Pennsylvania refinery, mixing YT399001-AN firmware v1.2 with Symphony DCS v7.0 caused communication errors. Always update the module firmware to v2.0+ using ABB ServicePort software.

Technical Deep Dive & Overview

The YT399001-AN (YPH 105 E) is a digital speed input board from ABB, designed for precise speed monitoring and protection of industrial turbines and motors. It features two redundant speed input channels that accept signals from magnetic pickup sensors (0-10kHz frequency range), providing reliable speed measurement even in harsh industrial environments.
Internally, it uses a 16-bit microcontroller with a high-speed frequency counter to process speed signals with 0.001% accuracy. The optical isolation (2500VAC) between input channels and the module’s internal circuitry blocks EMI/RFI interference from nearby power equipment, ensuring stable operation in power plants and refineries.
The module’s key feature is its integrated speed trip functionality, which provides two adjustable speed trip relays for overspeed protection. These relays have a response time of ≤10ms, fast enough to protect turbines from catastrophic damage. The 4-20mA analog output provides a proportional speed signal to the DCS, enabling remote monitoring and control.
What makes it field-tough is its robust design with redundant 24VDC power inputs, wide operating temperature range (-20°C to +60°C), and vibration tolerance up to 3g. The LED status indicators (power, speed input 1, speed input 2, trip status) provide quick visual diagnostics, reducing troubleshooting time.
For field teams, it’s the go-to module for turbine speed control in power generation and petrochemical industries. At a Midwestern power plant, retrofitting legacy turbine control systems with YT399001-AN modules reduced speed-related failures by 85% and extended maintenance intervals from 6 to 12 months. In a Louisiana refinery, its high-precision speed measurement improved turbine efficiency by 2.3%, saving $420k in annual energy costs.
This module is the backbone of turbine speed control in critical industrial processes—delivering the reliability, accuracy, and protection needed to keep power plants and refineries running safely and efficiently.
