Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB VBS01 |
| Manufacturer | ABB |
| Product Category | Vibration Monitoring Module |
| Measurement Type | Vibration velocity |
| Measuring Range | 0.1-20 mm/s RMS |
| Frequency Range | 10Hz-1kHz |
| Accuracy | ±5% of reading |
| Output Signal | 4-20mA (2-wire) |
| Power Supply | 18-30V DC loop powered |
| Operating Temperature | -40°C to +85°C |
| Enclosure Rating | IP66/NEMA 4X |
| Electrical Connection | M20 cable gland |
| Dimensions | 120mm × 90mm × 60mm |
| Weight | 450g |
| Certifications | ATEX, IECEx (optional) |
ABB VBS01
Product Introduction
The ABB VBS01 is a rugged vibration monitoring module designed for continuous condition monitoring of rotating machinery in industrial environments. This specialized device provides reliable measurement of vibration velocity, offering early warning of mechanical problems in pumps, motors, fans, and other critical equipment.
As part of ABB’s comprehensive condition monitoring portfolio, the VBS01 converts mechanical vibration into a standardized 4-20mA signal for integration with control systems and predictive maintenance solutions. Its robust IP66/NEMA 4X enclosure makes it suitable for installation in harsh environments where dust, moisture, and vibration are present.
The module’s wide operating temperature range and optional hazardous area certifications make the ABB VBS01 particularly valuable in oil & gas, power generation, and heavy industrial applications where equipment reliability is paramount.
Core Advantages and Technical Highlights
Precision Vibration Monitoring:
With ±5% accuracy across a wide 10Hz-1kHz frequency range, the module detects early-stage mechanical faults including imbalance, misalignment, and bearing wear.
Rugged Industrial Design:
Constructed for demanding environments, featuring corrosion-resistant housing and wide temperature tolerance (-40°C to +85°C).
Simplified Integration:
Standard 4-20mA output connects directly to most control systems without additional signal conditioning.
Low Maintenance Operation:
Solid-state design with no moving parts ensures long service life with minimal maintenance requirements.
Flexible Mounting:
Versatile mounting options accommodate various machine configurations and orientations.
Hazardous Area Certified:
Available with ATEX and IECEx certifications for use in explosive atmospheres (optional versions).
ABB VBS01
Typical Application Scenarios
The ABB VBS01 is extensively used in:
Oil & Gas:
Pump vibration monitoring in refineries
Compressor condition monitoring
Offshore platform machinery surveillance
Power Generation:
Turbine auxiliary equipment monitoring
Cooling tower fan vibration
Bearing condition assessment
Water/Wastewater:
Pump station condition monitoring
Aeration equipment surveillance
Large motor vibration tracking
Mining & Minerals:
Crusher vibration monitoring
Conveyor drive systems
Large fan installations
Related Model Recommendations
ABB VBS02: Extended range version (0.1-50 mm/s)
ABB VBA01: Acceleration measurement module
ABB VBD01: Displacement measurement module
ABB VBM01: Multi-parameter vibration monitor
ABB CMS100: Compact condition monitoring system
ABB CMS200: Advanced vibration monitoring system
ABB CMS300: Wireless vibration monitoring solution
ABB MACHsense: Comprehensive machine health system
Installation and Commissioning
Installation Preparation:
Select mounting location on machine surface (preferably near bearings). Clean mounting surface thoroughly. Ensure proper cable routing away from moving parts.
Commissioning Procedure:
Securely mount sensor using provided hardware
Connect power and signal wiring
Verify baseline vibration readings
Set alarm thresholds in monitoring system
Document initial vibration signature
Maintenance Best Practices:
Annual inspection of mounting integrity
Periodic verification against portable vibrometer
Regular cleaning of sensor surface
Check cable condition and connections
Recalibrate every 3-5 years
Service and Warranty Information
ABB provides a standard 24-month warranty for the VBS01, covering:
Defects in materials and workmanship
Performance below specified parameters
Premature failure under normal conditions
Extended service options include:
On-site calibration services
Technical support for system integration
Repair and recalibration services
Extended warranty programs
All modules undergo comprehensive testing before shipment, including:
Vibration sensitivity verification
Environmental stress testing
Electrical performance validation
Mechanical durability testing
