Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB UFC760BE142 3BHE004573R0142 |
| Manufacturer | ABB |
| Product Category | Field Control Unit (FCU) |
| Input Voltage | 24V DC (±10%) |
| Communication | PROFIBUS DP, Modbus RTU |
| Operating Temp. | -25°C to +70°C |
| Protection Rating | IP20 |
| Mounting Type | DIN Rail |
| Dimensions (WxHxD) | 120mm x 110mm x 75mm |
| Certifications | CE, UL, IEC 61131-2 |
| Compatibility | ABB AC 800M, 800xA DCS |
ABB UFC760BE142 3BHE004573R0142
Product Introduction
The ABB UFC760BE142 3BHE004573R0142 is a high-performance Field Control Unit (FCU) designed for seamless integration within ABB’s Automation System 800xA and AC 800M controller environments. This robust device serves as a critical interface between field-level instrumentation and higher-level control systems, ensuring reliable data acquisition and real-time process control.
Engineered for industrial automation, the ABB UFC760BE142 3BHE004573R0142 supports PROFIBUS DP and Modbus RTU communication protocols, enabling flexible connectivity with sensors, actuators, and other field devices. Its rugged design ensures stable operation in harsh industrial environments, making it ideal for applications in power generation, oil & gas, and chemical processing.
Core Advantages and Technical Highlights
High Reliability & Industrial Durability: The ABB UFC760BE142 3BHE004573R0142 is built to withstand extreme temperatures (-25°C to +70°C) and electrical noise, ensuring uninterrupted performance in demanding conditions. Its IP20-rated enclosure provides basic protection against dust and accidental contact.
Seamless System Integration: Designed for ABB’s 800xA DCS, this FCU ensures plug-and-play compatibility with AC 800M controllers, reducing engineering effort and minimizing downtime during system upgrades.
Flexible Communication: With dual support for PROFIBUS DP (for high-speed industrial networks) and Modbus RTU (for legacy device connectivity), the UFC760BE142 offers versatile interfacing options.
Compact & Modular Design: The DIN rail-mountable form factor allows space-efficient installation in control cabinets, while modular expansion capabilities support scalable system configurations.
Typical Application Scenarios
The ABB UFC760BE142 3BHE004573R0142 is widely used in industries requiring robust field-level control and data acquisition:
Power Plants: Acts as an interface for turbine control, boiler management, and substation automation.
Oil & Gas: Facilitates remote monitoring of pumps, valves, and flow meters in upstream and downstream operations.
Chemical Processing: Ensures precise control of batch processes, reactor systems, and safety interlocks.
Water & Wastewater: Integrates with SCADA systems for pump station control and filtration monitoring.
Its ability to operate in extreme environments makes it a preferred choice for mission-critical automation systems.
ABB UFC760BE142 3BHE004573R0142
Related Model Recommendations
ABB UFC762AE01 – Enhanced FCU with Ethernet/IP support for modern industrial networks.
ABB UFC721A – Compact FCU with basic I/O for small-scale automation.
ABB UFC718AE01 – Cost-effective alternative with Modbus TCP support.
ABB AC 800M PM864AK01 – High-end controller compatible with UFC760BE142.
ABB CI854A – Communication interface module for redundant PROFIBUS networks.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation:
Before installing the ABB UFC760BE142 3BHE004573R0142, ensure the environment is free from excessive vibration, moisture, and EMI sources. Use a 24V DC power supply with proper grounding and verify wiring according to ABB’s documentation.
Maintenance Suggestions:
Regularly inspect terminal connections for corrosion or looseness. Firmware updates should be performed via Automation Builder to ensure optimal functionality. Replace the unit if physical damage or communication failures persist.
Service and Guarantee Commitment
ABB provides a 24-month warranty for the UFC760BE142 3BHE004573R0142, covering manufacturing defects. Global technical support is available for troubleshooting, and replacement units can be sourced through ABB’s certified distributors. Preventive maintenance services, including firmware upgrades and system diagnostics, are offered to extend product lifespan.
