Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | UFC760BE141 3BHE004573R0141 |
| Manufacturer | ABB |
| Product Category | Field Control Module |
| Input Voltage | 24V DC (±15%) |
| Power Consumption | 8W (typical) |
| Processor | 32-bit RISC (400 MHz) |
| Memory | 128MB Flash, 64MB RAM |
| Communication Ports | 2× Ethernet, 1× RS-485, 1× USB 2.0 |
| Protocols Supported | Modbus TCP/RTU, PROFIBUS DP, IEC 61850 |
| Operating Temperature | -25°C to +70°C |
| Protection Class | IP20 |
| Dimensions (W×H×D) | 120 × 100 × 75 mm |
| Weight | 500g |
| Compliance Standards | IEC 61131-2, UL 508, CE, RoHS |
ABB UFC760BE141 3BHE004573R0141
Product Introduction
The ABB UFC760BE141 3BHE004573R0141 is a high-performance field control module designed for industrial automation and distributed control systems (DCS). Part of ABB’s S800 I/O family, this module serves as an intelligent interface between field devices and higher-level control systems, ensuring reliable data acquisition and real-time processing.
The UFC760BE141 is engineered for rugged industrial environments, featuring a 32-bit RISC processor and 128MB Flash memory, enabling efficient execution of complex control algorithms. With dual Ethernet ports, RS-485, and USB connectivity, it supports seamless integration with ABB AC 800M controllers and third-party automation systems. Its wide operating temperature range (-25°C to +70°C) makes it suitable for harsh industrial applications, including oil & gas, power generation, and manufacturing.
Core Advantages and Technical Highlights
High-Speed Processing & Connectivity:
The ABB UFC760BE141 3BHE004573R0141 features a 400 MHz processor and 128MB Flash memory, ensuring fast execution of control logic. Its dual Ethernet ports support Modbus TCP, PROFIBUS DP, and IEC 61850, enabling seamless communication with SCADA and PLC systems.
Robust Industrial Design:
Wide temperature range (-25°C to +70°C) for harsh environments
Conformal coated PCB for protection against humidity and dust
Vibration-resistant (5g) and surge-protected inputs
Hot-swappable design for maintenance without system shutdown
Advanced Diagnostics & Flexibility:
Real-time health monitoring (temperature, power supply, communication status)
LED indicators for quick fault detection
USB port for local configuration and firmware updates
Compatible with ABB’s Automation Builder & 800xA systems
Typical Application Scenarios
The ABB UFC760BE141 3BHE004573R0141 is widely used in:
Oil & Gas:
Monitoring and control of pump stations, compressors, and safety systems
Integration with ABB 800xA DCS for real-time process automation
Power Generation:
Turbine control and protection
Grid synchronization and load management
Manufacturing & Process Industries:
Machine automation in automotive plants
Batch process control in chemical plants
Data acquisition in water treatment facilities
Its rugged design and high-speed communication make it ideal for applications requiring reliable real-time control in extreme conditions.
ABB UFC760BE141 3BHE004573R0141
Related Model Recommendations
| Model | Description |
| UFC760BE142 | Enhanced version with additional I/O capacity |
| UFC760AE141 | Basic model with reduced memory |
| UFC762BE141 | High-speed variant with PROFINET support |
| CI854 | Communication interface module for redundancy |
| S800 I/O Modules | Compatible digital/analog I/O expansion units |
| AC 800M Controller | Primary controller for seamless integration |
Installation, Commissioning & Maintenance
Installation Preparation:
Ensure 24V DC power supply (±15%) is stable and properly grounded.
Mount on DIN rail with minimum 50mm clearance for ventilation.
Use shielded cables for communication ports to prevent EMI interference.
Maintenance Recommendations:
Quarterly inspections of terminal connections and cooling vents.
Monitor LED status indicators for early fault detection.
Update firmware periodically via USB or Automation Builder software.
Replace cooling fans every 5 years (if applicable).
Service & Guarantee Commitment
ABB provides:
36-month standard warranty (extendable options available)
24/7 global technical support
Firmware updates & lifecycle management
On-site commissioning & troubleshooting services
10-year spare parts availability guarantee
The UFC760BE141 3BHE004573R0141 undergoes rigorous testing, including:
1000-hour burn-in test
EMC & vibration resistance validation
Environmental stress screening
ABB’s predictive maintenance services ensure long-term reliability in critical automation systems.
