Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB TU830V1 |
| Manufacturer | ABB |
| Product Category | Terminal Unit Module |
| Compatibility | S800 I/O System |
| Input Voltage | 24V DC (18-30V range) |
| Power Consumption | 1.5W typical |
| Operating Temp | -25°C to +70°C |
| Connection Type | Screw terminals |
| Isolation Voltage | 500V AC |
| Dimensions | 60 × 120 × 25 mm |
| Weight | 150g |
| Certifications | CE, UL, cUL |
ABB TU830V1
Product Introduction
The ABB TU830V1 is a high-quality terminal unit module designed for ABB’s S800 I/O System, providing reliable signal termination and distribution in industrial automation applications. This compact module serves as an interface between field devices and control systems, ensuring secure and organized wiring connections.
Engineered for flexibility, the TU830V1 features robust screw terminals that accommodate a wide range of wire sizes (0.2-2.5mm²). Its 500V AC isolation between channels prevents signal interference, while the durable construction withstands harsh industrial environments. The module’s plug-and-play design simplifies installation and maintenance in control panels and automation cabinets.
As part of ABB’s comprehensive I/O solution, the ABB TU830V1 enables efficient wiring management for digital and analog signals, reducing installation time and improving system reliability in process control and factory automation applications.
Core Advantages and Technical Highlights
Reliable Signal Termination:
The ABB TU830V1 provides secure screw terminal connections with excellent vibration resistance. The terminals are designed for repeated use without degradation, ensuring long-term reliability in industrial environments.
Flexible Installation:
With its compact dimensions and DIN rail mounting, the TU830V1 enables space-efficient panel designs. The module supports both horizontal and vertical mounting orientations to accommodate various cabinet layouts.
Enhanced Safety:
Featuring 500V AC channel-to-channel isolation, the terminal unit prevents cross-talk and signal interference between connected devices. The clear terminal labeling reduces wiring errors during installation and maintenance.
Durable Construction:
The TU830V1 is built with high-quality materials that withstand industrial temperature ranges (-25°C to +70°C) and resist common environmental contaminants like dust and moisture.
System Integration:
Designed specifically for ABB’s S800 I/O System, the module ensures seamless compatibility with ABB’s automation controllers, including AC 800M and System 800xA platforms.
Typical Application Scenarios
Process Industries:
In oil refineries and chemical plants, the ABB TU830V1 organizes wiring for field instruments, ensuring reliable signal transmission between sensors and control systems.
Power Generation:
Power plants utilize the terminal unit for clean termination of I/O signals in turbine control systems and switchgear monitoring applications.
Manufacturing:
Automotive production lines employ the TU830V1 for organized wiring of sensors and actuators in robotic workcells and assembly stations.
Water Treatment:
Municipal facilities use the module for signal distribution in pump control panels, benefiting from its moisture-resistant design.
Discrete Automation:
The terminal unit serves in machine control panels, providing reliable connections for limit switches, pushbuttons, and other field devices.
ABB TU830V1
Related Model Recommendations
ABB TU810V1: Basic terminal unit for standard applications
ABB TU850V1: Enhanced terminal unit with higher density
ABB TB820: Terminal base unit for S800 I/O
ABB PFEA113: Digital input module
ABB PFEA112: Digital output module
ABB PFTL101: Temperature input module
ABB CI854: Communication interface module
Installation & Commissioning
Installation Guidelines:
Mount the ABB TU830V1 on a standard 35mm DIN rail, ensuring proper alignment with adjacent modules. Use appropriate wire stripping tools to prepare conductors (0.2-2.5mm²). Maintain minimum bending radius for cables and provide strain relief for field wiring.
Commissioning:
Verify all terminal connections are secure and properly torqued (0.5Nm). Check for proper isolation between channels using a megohmmeter. Label all wiring according to plant documentation standards before energizing the system.
Maintenance:
Periodically inspect terminals for tightness (recommended torque: 0.5Nm). Clean dust accumulation using compressed air. Check for signs of overheating or corrosion during routine system inspections.
Service & Warranty
ABB provides a 24-month warranty for the TU830V1, covering manufacturing defects. Global technical support is available through ABB’s network of automation specialists. The product is supported by ABB’s lifecycle management program, with spare parts availability guaranteed for 10 years after product discontinuation.
