Description
Detailed Parameter Table
| Parameter Name | Specification |
| Product Model | ABB SDCS-CON-4-COAT-ROHS |
| Manufacturer | ABB |
| Product Category | Drive System Connection Module |
| Connection Type | 4-channel coated terminal block |
| Wire Size | 0.5-2.5 mm² (AWG 20-14) |
| Voltage Rating | 600V AC/DC |
| Current Rating | 10A per channel |
| Operating Temperature | -25°C to +70°C |
| Protection Rating | IP20 (module), IP2X (terminals) |
| Material | ROHS-compliant thermoplastic |
| Flammability Rating | UL94 V-0 |
| Dimensions | 45 × 75 × 60 mm |
| Weight | 120 g |
| Compliance | CE, UL, RoHS |
ABB SDCS-CON-4-COAT-ROHS
Product Introduction
The ABB SDCS-CON-4-COAT-ROHS is a high-quality connection module designed specifically for ABB drive systems, providing secure and reliable wiring termination points. This 4-channel terminal block module features a special protective coating that enhances corrosion resistance, making it ideal for use in harsh industrial environments where moisture, chemicals, or temperature fluctuations are present.
As part of ABB’s SDCS (System Drive Control System) family, this ROHS-compliant connection module ensures environmental compliance while maintaining the high electrical and mechanical standards expected from ABB products. The module’s compact design and color-coded terminals simplify installation and maintenance while reducing wiring errors in complex drive configurations.
Core Advantages and Technical Highlights
Enhanced Durability:
The protective coating on the SDCS-CON-4-COAT-ROHS provides superior resistance to industrial contaminants including oils, coolants, and cleaning chemicals. This extends service life in challenging environments like metal processing or food production facilities.
Superior Electrical Performance:
With 600V AC/DC voltage rating and 10A current capacity per channel, the module handles demanding drive applications. The screw-type terminals maintain consistent contact pressure, preventing loosening from vibration.
Environmentally Compliant:
Fully compliant with RoHS directives, the module contains no hazardous substances while maintaining ABB’s high performance standards. The UL94 V-0 flammability rating ensures safety in electrical installations.
User-Friendly Design:
Color-coded terminals and clear channel markings simplify wiring and reduce installation errors. The compact size saves panel space while allowing adequate finger room for wiring.
System Integration:
Designed specifically for ABB drive systems, the module ensures perfect compatibility with ACS880, ACS800 and other ABB drive families. The uniform connection system reduces inventory requirements.
Typical Application Scenarios
The ABB SDCS-CON-4-COAT-ROHS is essential in various industrial drive applications:
Manufacturing Automation:
Motor control cabinet wiring
Drive-to-drive communication links
I/O signal distribution
Process Industries:
Pump and fan drive systems
Conveyor control panels
Mixer drive installations
Marine and Offshore:
Ship propulsion control systems
Deck machinery panels
Offshore platform drives
Food and Beverage:
Hygienic production line drives
Washdown area motor controls
Packaging machine wiring
Renewable Energy:
Wind turbine pitch control
Solar tracking systems
Hydroelectric plant controls
ABB SDCS-CON-4-COAT-ROHS
Related Model Recommendations
ABB SDCS-CON-2: 2-channel version for simpler applications
ABB SDCS-CON-8: 8-channel expanded version
ABB SDCS-POW-1: Power distribution module
ABB SDCS-IOB-1: I/O extension module
ABB SDCS-FIB-1: Fiber optic interface module
ABB SDCS-COM-1: Communication gateway module
ABB SDCS-CON-4-UNCOAT: Standard uncoated version
Installation, Commissioning and Maintenance Instructions
Installation Preparation:
Before installing the SDCS-CON-4-COAT-ROHS, ensure proper clearance (minimum 50mm above/below) for wiring access. Verify all conductors meet specified size requirements and are properly stripped. Have appropriate torque tools available for terminal tightening (recommended 0.5 N·m).
Maintenance Suggestions:
Periodically inspect terminals for signs of corrosion or overheating (recommended every 6 months in harsh environments). Check terminal tightness during routine maintenance (annual recommended). Clean only with approved, non-abrasive cleaners to preserve the protective coating. Always de-energize before servicing.
Service and Guarantee Commitment
ABB provides a 36-month warranty for the SDCS-CON-4-COAT-ROHS, demonstrating confidence in its durable design. Our global service network offers:
Technical documentation and support
Replacement parts availability
Customized service agreements
Environmental compliance verification
Product training programs
The module is included in ABB’s long-term availability program, with guaranteed spare parts availability for minimum 10 years after order discontinuation.
