Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB PPC907BE 3BHE024577R0101 |
| Manufacturer | ABB |
| Product Category | Industrial Operator Panel (800xA System) |
| Display | 15.6″ TFT LCD, 1366×768 px, 250 cd/m² brightness |
| Touch Technology | Projected Capacitive (Multi-touch) |
| Processor | Intel® Atom™ E3845 Quad-core 1.91 GHz |
| Memory | 4 GB DDR3L RAM, 64 GB SSD |
| Operating System | Windows 10 IoT Enterprise LTSC |
| Interfaces | 2x Ethernet (Gigabit), 4x USB 3.0, 1x RS-232/485, 1x DVI-I |
| Protection Rating | IP65 Front / IP20 Rear |
| Operating Temperature | 0°C to +50°C |
| Safety Certification | SIL 2 (IEC 61508), UL Class I Div 2 |
| Power Supply | 24 V DC ±10% (Redundant Inputs) |
| Power Consumption | 65 W (max) |
| Dimensions (W x H x D) | 409 mm x 311 mm x 63 mm |
| Mounting | Panel Mount (Front) |
ABB PPC907BE 3BHE024577R0101
Product Introduction
The ABB PPC907BE 3BHE024577R0101 is an advanced industrial operator panel integral to ABB’s Ability™ 800xA Distributed Control System. Designed for mission-critical control rooms, this high-performance HMI delivers intuitive visualization and robust data interaction for complex process automation. As the primary human-machine interface in hazardous environments, the PPC907BE combines multi-touch control with SIL 2 safety compliance, enabling operators to monitor safety instrumented functions (SIFs) while managing standard process operations.
Engineered for 24/7 reliability, this panel runs Windows 10 IoT Enterprise on industrial-grade hardware, supporting real-time data visualization, alarm management, and historical trend analysis. Its seamless integration with 800xA controllers allows unified access to plant-wide data, reducing operator workload while enhancing situational awareness. The ABB PPC907BE 3BHE024577R0101 significantly elevates operational efficiency by merging ergonomic design with fail-safe architecture for industries where human error prevention is paramount.
Core Advantages and Technical Highlights
The ABB PPC907BE 3BHE024577R0101 redefines industrial HMI standards through these innovations:
Ruggedized Operational Integrity: IP65-rated front panel resists water jets, oils, and chemical splashes. Reinforced glass survives 50g mechanical shock and 5g vibration (IEC 60068-2). UL Class I Div 2 certification permits deployment in explosive atmospheres.
Enhanced Situational Awareness: Projected capacitive touch supports 10-finger gestures and gloved operation (up to 5mm thickness). Automatic brightness adjustment (50-250 cd/m²) ensures readability in direct sunlight or low-light conditions.
Safety-Integrated Visualization: SIL 2 certification enables direct display of safety system statuses (ESD/PSD) with password-protected access levels. Tamper-proof audit trails comply with FDA 21 CFR Part 11.
Deterministic Performance: Intel Atom quad-core processor handles 100+ dynamic process displays with <1s screen refresh rates. Dual Gigabit Ethernet ports support redundant networks with <10ms failover.
Cyber Security by Design: TPM 2.0 hardware encryption, secure boot, and application whitelisting enforce IEC 62443-3-3 SL2 requirements.
Typical Application Scenarios
The ABB PPC907BE 3BHE024577R0101 excels in high-risk continuous processes:
Chemical Plant Control Rooms: Centralized monitoring of reactor pressures/temperatures with SIL 2-alarmed safety interlocks. Glove-compatible touch prevents contamination in sterile zones.
Offshore Oil Platforms: Hurricane-resistant operation in salty environments. Displays subsea ESD valve statuses and fire/gas detection systems with redundant network failover.
Pharmaceutical Cleanrooms: FDA-compliant batch reporting with electronic signatures. IP65 rating withstands high-pressure washdowns.
Power Substations: Visualizes grid protection relays via IEC 61850 communication. Capacitive touch works through arc-flash protective gloves.
In each scenario, the PPC907BE reduces operator cognitive load while maintaining safety compliance during abnormal situations.
ABB PPC907BE 3BHE024577R0101
Related Model Recommendations
ABB PPC922BE – 22″ High-brightness variant (1,000 cd/m²) for outdoor installations.
ABB TU847 – Managed Ethernet switch for redundant network connectivity.
ABB CP635-T – Thin-client terminal for distributed visualization.
ABB SD832 – I/O module for local device integration near PPC907BE.
ABB 3HNA024765-001 – Mounting kit for vibration-dampened installation.
Installation, Commissioning and Maintenance Instructions
Installation Preparation: Verify panel cutout dimensions (386×288 mm ±0.5mm). Ensure ambient temperature (0-50°C) and humidity (<85% RH non-condensing). Disconnect power before mounting. Secure the PPC907BE using front-panel clamps (35 N·m torque). Route cables through bottom conduits with IP65 cable glands. Maintain 50mm clearance for rear ventilation.
Maintenance Suggestions: Clean the screen monthly using isopropyl alcohol (70%) and microfiber cloth. Calibrate touch every 12 months via ABB Diagnostic Tool. Monitor SSD health using built-in S.M.A.R.T. diagnostics. Replace internal backup battery (CR2032) every 5 years to preserve BIOS settings. For SIL 2 systems, validate safety graphics annually per safety validation plan.
Service and Guarantee Commitment
ABB warrants the PPC907BE 3BHE024577R0101 for 36 months against defects. Our commitment includes:
Global 24/7 Support: On-site response within 8 hours for critical process failures
Lifecycle Management: Minimum 10-year hardware availability with migration services
Security Updates: Quarterly patches for Windows IoT OS and ABB applications
SIL 2 Compliance: Provision of Safety Requirements Specifications (SRS) and validation kits
Extended Service Packages: Includes predictive analytics, spare part stocking, and priority firmware upgrades
Pre-configured replacement units with cloned software are available for ≤4-hour mean repair time (MTTR).
